一种改进的多循环油气田产量预测模型

doi:10.7657/XJPG20200407

摘要/Abstract

摘要：

生命旋回模型法是预测油气田产量的主要方法,该方法中生命旋回（产量循环）的个数是影响预测结果的重要因素。以往多是从产量变化曲线的走势或某个时间点发生的重要事件确定循环个数,受主观判断的影响较大,容易造成结果的不准确。为此,以生命旋回模型法中常用的广义翁氏模型为基础模型,建立改进的多循环广义翁氏模型,确定油气田产量预测中的循环个数,以此来改善模型的预测效果。将改进后的模型应用于大庆油田的产量预测,其对年产量的拟合效果明显优于单循环模型和多循环模型,对未来产量变化的预测能力也基本等同于加入更多循环个数后的预测模型,从而有效避免了不必要循环的加入所导致的预测时间的增加,证明了改进模型的有效性,为油气田产量预测提供了新的思路。

关键词: 油气田, 产量预测, 单循环模型, 多循环模型, 广义翁氏模型, 大庆油田

Abstract:

Life-cycle models are the main methods for production prediction in oil and gas fields, and the number of life (production) cycles in these models has significant influences on forecast results. Previous studies usually determine the number of production cycles based on the trend of production curve or important events occurring at a certain time, which tends to result in an inaccurate forecast result. The generalized Weng’s model is chosen as a base model since it is one of the most widely-used life-cycle models, a modified multi-cycle generalized Weng’s model is then established to quantitatively determine the number of cycles in oil and gas fields’ production prediction, aiming at improving the prediction performance of the model. The modified model is used to predict the production of Daqing oilfield and the results show that the modified model can present a better fit than a single-cycle model and conventional multi-cycle models. Meanwhile, the modified model can give similar forecast results to those models with more production cycles, avoiding the addition of forecast time, which has proved the validity of the modified model and provided a new idea for production prediction in oil and gas fields.

Key words: oil and gas field, production prediction, single-cycle model, multi-cycle model, generalized Weng’s model, Daqing oilfield

中图分类号:

王建良, 刘睿, 冯连勇, 于祥春. 一种改进的多循环油气田产量预测模型[J]. 新疆石油地质, 2020, 41(4): 430-434.

WANG Jianliang, LIU Rui, FENG Lianyong, YU Xiangchun. A Modified Multi-Cycle Model for Predicting Productions of Oil and Gas Fields[J]. Xinjiang Petroleum Geology, 2020, 41(4): 430-434.

图/表 7

图1

图2

图3

表1

图4

表2

1959—2019年大庆油田实际年产量与预测年产量对比叠加预测年产量/104 t"

年份	实际年产量/10⁴ t	单循环预测年产量/10⁴ t	2个循环叠加预测年产量/10⁴ t	3个循环叠加预测年产量/10⁴ t	年份	实际年产量/10⁴ t	单循环预测年产量/10⁴ t	2个循环叠加预测年产量/10⁴ t	3个循环叠加预测年产量/10⁴ t
1959	0.11	0.24	1.08	0.12	1990	5 562.24	5 048.37	5 749.66	5 540.09
1960	97.07	2.99	11.20	2.88	1991	5 562.33	5 122.89	5 688.49	5 579.79
1961	274.33	12.52	41.86	17.02	1992	5 565.83	5 180.48	5 609.66	5 618.64
1962	355.49	33.54	103.06	56.46	1993	5 590.19	5 221.61	5 514.99	5 650.99
1963	439.34	70.43	201.78	136.42	1994	5 600.52	5 246.85	5 406.29	5 670.90
1964	625.06	126.75	341.79	269.72	1995	5 600.69	5 256.85	5 285.40	5 672.70
1965	834.24	205.06	523.88	464.37	1996	5 600.86	5 252.33	5 154.18	5 651.53
1966	1 060.90	306.86	746.34	722.48	1997	5 600.92	5 234.10	5 014.64	5 603.83
1967	1 031.99	432.67	1 005.48	1 040.36	1998	5 570.38	5 202.97	4 869.01	5 527.79
1968	1 150.96	582.07	1 296.18	1 409.43	1999	5 450.19	5 159.83	4 719.89	5 423.63
1969	1 580.99	753.87	1 612.39	1 817.43	2000	5 300.09	5 105.54	4 570.45	5 293.78
1970	2 118.37	946.21	1 947.55	2 249.95	2001	5 150.16	5 041.01	4 424.54	5 142.86
1971	2 169.13	1 156.76	2 294.92	2 691.69	2002	5 013.10	4 967.12	4 286.71	4 977.46
1972	3 051.25	1 382.78	2 647.90	3 127.76	2003	4 840.03	4 884.77	4 162.05	4 805.67
1973	3 365.07	1 621.32	3 000.23	3 544.53	2004	4 640.03	4 794.82	4 055.80	4 636.33
1974	4 105.65	1 869.25	3 346.12	3 930.45	2005	4 495.10	4698.12	3 972.65	4 478.19
1975	4 625.97	2 123.45	3 680.43	4 276.46	2006	4 338.10	4 595.50	3 915.86	4 338.80
1976	5 030.31	2 380.82	3 998.66	4 576.30	2007	4 162.61	4 487.75	3 886.40	4 223.53
1977	5 031.40	2 638.37	4 297.01	4 826.65	2008	4 020.01	4 375.64	3 882.16	4 134.73
1978	5 037.53	2 893.28	4 572.40	5 026.99	2009	4 000.03	4 259.87	3 897.62	4 071.22
1979	5 075.30	3 142.94	4 822.42	5 179.53	2010	4 000.03	4 141.15	3 924.03	4 028.23
1980	5 150.11	3 384.97	5 045.30	5 288.74	2011	4 000.04	4 020.10	3 950.21	3 997.87
1981	5 175.27	3 617.25	5 239.89	5 361.00	2012	4 000.00	3 897.35	3 963.84	3 969.97
1982	5 194.15	3 837.91	5 405.57	5 403.96	2013	4 000.00	3 773.45	3 953.07	3 933.37
1983	5 235.46	4 045.37	5 542.21	5 425.94	2014	4 000.00	3 648.92	3 908.09	3 877.26
1984	5 356.41	4 238.32	5 650.12	5 435.23	2015	3 838.60	3 524.26	3 822.47	3 792.48
1985	5 528.88	4 415.68	5 729.95	5 439.41	2016	3 656.00	3 399.89	3 693.88	3 672.61
1986	5 555.24	4 576.66	5 782.67	5 444.82	2017	3 400.00	3 276.23	3 524.24	3 514.64
1987	5 555.32	4 720.68	5 809.51	5 456.08	2018	3 204.40	3 153.63	3 319.21	3 319.11
1988	5 570.29	4 847.37	5 811.89	5 475.74	2019	3 090.00	3 032.44	3 087.22	3 089.96
1989	5 555.56	4 956.59	5 791.37	5 504.28

表2

图5

参考文献 14

[1]	陆家亮, 赵素平, 孙玉平, 等. 中国天然气产量峰值研究及建议[J]. 天然气工业, 2018,38(1):1-9.
	LU Jialiang, ZHAO Suping, SUN Yuping, et al. Natural gas production peaks in China:research and strategic proposals[J]. Natural Gas Industry, 2018,38(1):1-9.
[2]	周鹏. 一种预测水驱油田开发指标的改进型增长曲线[J]. 新疆石油地质, 2020,41(2):243-247.
	ZHOU Peng. An improved growth curve for predicting development indexes in water flooding oilfield[J]. Xinjiang Petroleum Geology, 2020,41(2):243-247.
[3]	李振华, 顾乔元, 张大鹏, 等. 塔里木油田碳酸盐岩油藏产量预测方法[J]. 新疆石油地质, 2019,40(5):583-587.
	LI Zhenhua, GU Qiaoyuan, ZHANG Dapeng, et al. Production prediction methods for carbonate reservoirs in Tarim oilfield[J]. Xinjiang Petroleum Geology, 2019,40(5):583-587.
[4]	周芸, 周福建, 冯连勇. 一种新型油气产量预测模型[J]. 大庆石油地质与开发, 2018,37(5):76-80.
	ZHOU Yun, ZHOU Fujian, FENG Lianyong. A new model for predicting oil and gas production[J]. Petroleum Geology and Oilfield Development in Daqing, 2018,37(5):76-80.
[5]	胡建国, 陈元千, 张盛宗. 预测油气田产量的新模型[J]. 石油学报, 1995,16(1):79-87.
	HU Jianguo, CHEN Yuanqian, ZHANG Shengzong. A new model to predict production rate of oil and gas fields[J]. Acta Petrolei Sinica, 1995,16(1):79-87.
[6]	陈元千. 对翁氏预测模型的推导及应用[J]. 天然气工业, 1996,16(2):22-26.
	CHEN Yuanqian. Derivation and application of Weng’s prediction model[J]. Natural Gas Industry, 1996,16(2):22-26.
[7]	赵林, 冯连勇, 陆祥安, 等. 两种求解广义翁氏模型方法的对比[J]. 新疆石油地质, 2009,30(5):658-660.
	ZHAO Lin, FENG Lianyong, LU Xiang’an, et al. Comparison of two methods for generalized Weng model[J]. Xinjiang Petroleum Geology, 2009,30(5):658-660.
[8]	冯连勇, 王建良, 赵林. 预测天然气产量的多循环模型的构建及应用[J]. 天然气工业, 2010,30(7):114-116.
	FENG Lianyong, WANG Jianliang, ZHAO Lin. Construction and application of a multi-cycle model in the prediction of natural gas production[J]. Natural Gas Industry, 2010,30(7):114-116.
[9]	WANG Jianliang, FENG Lianyong, ZHAO Lin, et al. A comparison of two typical multicyclic models used to forecast the world’s conventional oil production[J]. Energy Policy, 2011,39(12):7 616-7 621.
[10]	NASHAWI I S, MALALLAH A, Al BISHARAH M. Forecasting world crude oil production using multicyclic Hubbert model[J]. Energy & Fuels, 2010,24:1 788-1 800.
[11]	陈元千, 郝明强. HCZ模型在多峰预测中的应用[J]. 石油学报, 2013,34(4):747-752.
	CHEN Yuanqian, HAO Mingqiang. Application of HCZ model to predicting multiple production peaks[J]. Acta Petrolei Sinica, 2013,34(4):747-752.
[12]	WANG Jianliang, FENG Lianyong. Curve-fitting models for fossil fuel production forecasting:key influence factors[J]. Journal of Natural Gas Science and Engineering, 2016,32:138-149.
[13]	ANDERSON K B, CONDER J A. Discussion of multicyclic Hubbert modeling as a method for forecasting future petroleum production[J]. Energy & Fuels, 2011,25:1 578-1 584.
[14]	TANG Xu, ZHANG Baosheng, HÖÖK M, et al. Forecast of oil reserves and production in Daqing oilfield of China[J]. Energy, 2010,35:3 097-3 102.

循环个数/个	均值平方根R	无量纲的均值平方根RD	模型的F 检验值Fm	标准的F 检验值Fs	是否通过
1	1 024.14	0.19
2	396.94	0.07	6.30	1.90	Fm >Fs, 引入第2个循环
3	172.05	0.03	5.02	1.94	Fm >Fs,引入第3个循环
4	121.36	0.02	1.89	1.98	Fm<Fs,拒绝引入第4个循环
5	103.62	0.02	1.28	2.02
