Dolomitization and Main Controlling Factors of Penglaiba Formation Reservoir in Tarim Basin

doi:10.7657/XJPG20250404

Abstract

Abstract:

The dolomites in the Lower Ordovician Penglaiba formation in the Tarim Basin have undergone a complex diagenetic evolution characterized by multi-stage and multi-genesis. To systematically study their petrological features, dolomitization mechanisms, and main factors governing reservoir quality, investigations were conducted using outcrops, core samples, thin sections, and geochemical tests. The results show the presence of four major dolomite types in the Penglaiba formation, including micritic dolomite, fine- to medium-grained dolomite, coarse-grained dolomite, and porphyritic dolomite, all of which are genetically controlled by penecontemporaneous-shallow burial and burial dolomitizations. Fine- to medium-grained dolomites display abundant intercrystalline pores with high euhedral degree, whereas coarse crystalline dolomites retain some intercrystalline pores and have strong compaction resistance. The dolomites generally formed through replacement or recrystallization under burial conditions, with Early Ordovician seawater serving as the primary dolomitizing fluid, variably modified by deep hydrothermal fluids and evaporite-derived brines. Grain-shoal deposits provide the most favorable sedimentary microfacies for reservoir development because the early intergranular pores not only act as pathways for fluid migration but also serve as initial storage space, thereby accelerating dolomitization. Sea-level fluctuations modulated the physical and chemical conditions of dolomitization by altering hydrodynamic regimes, fluid-migration patterns, and the karstification processes. Palaeogeomorphic highs experienced more intense dolomitization, and well-developed stratiform dissolution pores and vugs provide favorable conditions for high-quality reservoirs. These insights provide a sound basis for deep dolomite exploration in the Ordovician strata of the Tarim Basin, clarify dolomitization mechanisms and main reservoir-controlling factors, and offer practical guidance for future exploration and development.

Key words: Tarim Basin, Penglaiba formation, dolomite, dolomitization, carbon and oxygen isotopes, strontium isotope, controlling factor

CLC Number:

TE122

YAN Bo, LUO Fuwen, CAO Yang, CHENG Linfeng. Dolomitization and Main Controlling Factors of Penglaiba Formation Reservoir in Tarim Basin[J]. Xinjiang Petroleum Geology, 2025, 46(4): 419-428.

Figures/Tables 7

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Fig. 7.

References 28

[1]	何治亮, 马永生, 张军涛, 等. 中国的白云岩与白云岩储层:分布、成因与控制因素[J]. 石油与天然气地质, 2020, 41(1):1-14.
	HE Zhiliang, MA Yongsheng, ZHANG Juntao, et al. Distribution,genetic mechanism and control factors of dolomite and dolomite reservoirs in China[J]. Oil & Gas Geology, 2020, 41(1):1-14.
[2]	尚凯, 吕海涛, 曹自成, 等. 塔里木盆地顺托果勒低隆起一间房组分布及地质意义[J]. 石油实验地质, 2018, 40(3):353-361.
	SHANG Kai, LÜ Haitao, CAO Zicheng, et al. Distribution and significance of Middle Ordovician Yijianfang formation in Shuntuoguole lower uplift,Tarim Basin[J]. Petroleum Geology & Experiment, 2018, 40(3):353-361.
[3]	张杰, 寿建峰, 张天付, 等. 白云石成因研究新方法:白云石晶体结构分析[J]. 沉积学报, 2014, 32(3):550-559.
	ZHANG Jie, SHOU Jianfeng, ZHANG Tianfu, et al. New approach on the study of dolomite origin:The crystal structure analysis of dolomite[J]. Acta Sedimentologica Sinica, 2014, 32(3):550-559.
[4]	曾理, 万茂霞, 彭英. 白云石有序度及其在石油地质中的应用[J]. 天然气勘探与开发, 2004, 27(4):64-66.
	ZENG Li, WAN Maoxia, PENG Ying. Dolomite sequentiality and its application to petroleum geology[J]. Natural Gas Exploration & Development, 2004, 27(4):64-66.
[5]	杨威, 王清华, 刘效曾. 塔里木盆地和田河气田下奥陶统白云岩成因[J]. 沉积学报, 2000, 18(4):544-548.
	YANG Wei, WANG Qinghua, LIU Xiaozeng. Dolomite origin of Lower Ordovician in Hetian River gas field,Tarim Basin[J]. Acta Sedimentologica Sinica, 2000, 18(4):544-548.
[6]	漆立新. 塔里木盆地顺托果勒隆起奥陶系碳酸盐岩超深层油气突破及其意义[J]. 中国石油勘探, 2016, 21(3):38-51.
	QI Lixin. Oil and gas breakthrough in ultra-deep Ordovician carbonate formations in Shuntuoguole uplift,Tarim Basin[J]. China Petroleum Exploration, 2016, 21(3):38-51.
[7]	赵宗举, 吴兴宁, 潘文庆, 等. 塔里木盆地奥陶纪层序岩相古地理[J]. 沉积学报, 2009, 27(5):939-954.
	ZHAO Zongju, WU Xingning, PAN Wenqing, et al. Sequence lithofacies paleogeography of Ordovician in Tarim Basin[J]. Acta Sedimentologica Sinica, 2009, 27(5):939-954.
[8]	吴兴宁, 斯春松, 俞广, 等. 塔里木盆地奥陶纪岩相古地理恢复及其油气勘探意义[J]. 海相油气地质, 2012, 17(3):9-17.
	WU Xingning, SI Chunsong, YU Guang, et al. Reconstruction of Ordovician lithofacies palaeogeography and petroleum prospecting significance in Tarim Basin[J]. Marine Origin Petroleum Geology, 2012, 17(3):9-17.
[9]	冯增昭, 鲍志东, 吴茂炳, 等. 塔里木地区奥陶纪岩相古地理[J]. 古地理学报, 2007, 9(5):447-460.
	FENG Zengzhao, BAO Zhidong, WU Maobing, et al. Lithofacies palaeogeography of the Ordovician in Tarim area[J]. Journal of Palaeogeography, 2007, 9(5):447-460. doi: 10.7605/gdlxb.2007.05.001
[10]	何登发, 贾承造, 李德生, 等. 塔里木多旋回叠合盆地的形成与演化[J]. 石油与天然气地质, 2005, 26(1):64-77.
	HE Dengfa, JIA Chengzao, LI Desheng, et al. Formation and evolution of polycyclic superimposed Tarim Basin[J]. Oil & Gas Geology, 2005, 26(1):64-77.
[11]	熊冉, 张天付, 乔占峰, 等. 塔里木盆地奥陶系蓬莱坝组碳酸盐岩缓坡沉积特征及油气勘探意义[J]. 沉积与特提斯地质, 2019, 39(1):42-49.
	XIONG Ran, ZHANG Tianfu, QIAO Zhanfeng, et al. The carbonate ramp deposits from the Ordovician Penglaiba formation in the Tarim Basin,Xinjiang:Sedimentary characteristics and their implications for petroleum exploration[J]. Sedimentary Geology and Tethyan Geology, 2019, 39(1):42-49.
[12]	王泽宇, 乔占峰, 寿芳漪, 等. 塔里木盆地永安坝剖面蓬莱坝组白云岩成因与形成过程:来自有序度和晶胞参数的证据[J]. 天然气地球科学, 2020, 31(5):602-611. doi: 10.11764/j.issn.1672-1926.2020.04.010
	WANG Zeyu, QIAO Zhanfeng, SHOU Fangyi, et al. Origin and formation mechanism of dolomite in Penglaiba formation of Yonganba outcrop,Tarim Basin:Evidence from ordering degree and unit cell parameters[J]. Natural Gas Geoscience, 2020, 31(5):602-611. doi: 10.11764/j.issn.1672-1926.2020.04.010
[13]	万友利, 王剑, 付修根, 等. 羌塘盆地南坳陷中侏罗统布曲组白云岩储层成因流体同位素地球化学示踪[J]. 石油与天然气地质, 2020, 41(1):189-200.
	WAN Youli, WANG Jian, FU Xiugen, et al. Geochemical tracing of isotopic fluid of dolomite reservoir in the Middle Jurassic Buqu formation in southern depression of Qiangtang Basin[J]. Oil & Gas Geology, 2020, 41(1):189-200.
[14]	沈洪娟, 顾尚义, 赵思凡, 等. 华南南华纪南沱冰期海洋环境的沉积地球化学记录:来自黔东部南华系南沱组白云岩碳氧同位素和微量元素的证据[J]. 地质论评, 2020, 66(1):214-228.
	SHEN Hongjuan, GU Shangyi, ZHAO Sifan, et al. The sedimentary geochemical records of ocean environment during the Nantuo(Marinoan) glaciation in South China:Carbon and oxygen isotopes and trace element compositions of dolostone in Nantuo formation,Nanhuan system,in eastern Guizhou[J]. Geological Review, 2020, 66(1):214-228.
[15]	郭颖, 杜晓峰, 杨波, 等. 下扬子地区上震旦统—下古生界白云岩地球化学特征及成因:以南京地区为例[J]. 地球科学, 2023, 48(12):4558-4574.
	GUO Ying, DU Xiaofeng, YANG Bo, et al. Geochemical characteristics and genesis of Upper Sinian-Lower Paleozoic dolomite in Lower Yangtze region:A case study from Nanjing area[J]. Earth Science, 2023, 48(12):4558-4574.
[16]	郑剑锋, 沈安江, 杨翰轩, 等. 塔里木盆地西北缘震旦系微生物白云岩地球化学、年代学特征及其地质意义[J]. 岩石学报, 2021, 37(7):2189-2202.
	ZHENG Jianfeng, SHEN Anjiang, YANG Hanxuan, et al. Geochemistry and geochronology characteristics and their geological significance of microbial dolomite in Upper Sinian,NW Tarim Basin[J]. Acta Petrologica Sinica, 2021, 37(7):2189-2202.
[17]	田家奇, 李国蓉, 刘永立, 等. 塔北地区鹰山组下段—蓬莱坝组白云岩成因及控储意义[J]. 新疆石油地质, 2024, 45(3):306-316.
	TIAN Jiaqi, LI Guorong, LIU Yongli, et al. Genesis of dolomite and its controls on reservoir spaces in lower Yingshan formation-Penglaiba formation,northern Tarim Basin[J]. Xinjiang Petroleum Geology, 2024, 45(3):306-316.
[18]	黄擎宇, 刘伟, 张艳秋, 等. 塔里木盆地中央隆起区上寒武统—下奥陶统白云岩地球化学特征及白云石化流体演化规律[J]. 古地理学报, 2016, 18(4):661-676. doi: 10.7605/gdlxb.2016.04.049
	HUANG Qingyu, LIU Wei, ZHANG Yanqiu, et al. Geochemistry and evolution of dolomitizing fluids of the Upper Cambrian-Lower Ordovician dolostones in Central uplift,Tarim Basin[J]. Journal of Palaeogeography, 2016, 18(4):661-676. doi: 10.7605/gdlxb.2016.04.049
[19]	王利超, 胡文瑄, 王小林, 等. 白云岩化过程中锶含量变化及锶同位素分馏特征与意义[J]. 石油与天然气地质, 2016, 37(4):464-472.
	WANG Lichao, HU Wenxuan, WANG Xiaolin, et al. Variation of Sr content and ⁸⁷Sr/⁸⁶Sr isotope fractionation during dolomitization and their implications[J]. Oil & Gas Geology, 2016, 37(4):464-472.
[20]	刘策, 曹颖辉, 周波, 等. 古城地区中下奥陶统白云岩碳氧同位素特征及成因[J]. 特种油气藏, 2017, 24(2):30-34.
	LIU Ce, CAO Yinghui, ZHOU Bo, et al. Carbon and oxygen isotope characteristics and genesis of Middle and Lower Ordovician dolomite in Gucheng area[J]. Special Oil & Gas Reservoirs, 2017, 24(2):30-34.
[21]	曹自成, 尤东华, 漆立新, 等. 塔里木盆地塔深1井超深层白云岩储层成因新认识:来自原位碳氧同位素分析的证据[J]. 天然气地球科学, 2020, 31(7):915-922. doi: 10.11764/j.issn.1672-1926.2020.03.005
	CAO Zicheng, YOU Donghua, QI Lixin, et al. New insights of the genesis of ultra-deep dolomite reservoirs in Well TS1,Tarim Basin:Evidence from in situ carbon and oxygen isotope analysis[J]. Natural Gas Geoscience, 2020, 31(7):915-922. doi: 10.11764/j.issn.1672-1926.2020.03.005
[22]	SHIELDS G A, CARDEN G A F, VEIZER J, et al. Sr,C,and O isotope geochemistry of Ordovician brachiopods:A major isotopic event around the Middle-Late Ordovician transition[J]. Geochimica et Cosmochimica Acta, 2003, 67(11):2005-2025.
[23]	黄思静, 黄喻, 兰叶芳, 等. 四川盆地东北部晚二叠世—早三叠世白云岩与同期海水锶同位素组成的对比研究[J]. 岩石学报, 2011, 27(12):3831-3842.
	HUANG Sijing, HUANG Yu, LAN Yefang, et al. A comparative study on strontium isotope composition of dolomites and their coeval seawater in the Late Permian-Early Triassic,NE Sichuan Basin[J]. Acta Petrologica Sinica, 2011, 27(12):3831-3842.
[24]	胡作维, 黄思静, 王春梅, 等. 锶同位素方法在油气储层成岩作用研究中的应用[J]. 地质找矿论丛, 2009, 24(2):160-165.
	HU Zuowei, HUANG Sijing, WANG Chunmei, et al. Application of strontium isotope geochemistry to the oil and gas reservoir diagenesis research[J]. Contributions to Geology and Mineral Resources Research, 2009, 24(2):160-165.
[25]	黄文辉, 杨敏, 于炳松, 等. 塔中地区寒武系—奥陶系碳酸盐岩Sr元素和Sr同位素特征[J]. 地球科学, 2006, 31(6):839-845.
	HUANG Wenhui, YANG Min, YU Bingsong, et al. Strontium isotope composition and its characteristics analysis of Cambrian-Ordovician carbonate in Tazhong district,Tarim Basin[J]. Earth Science, 2006, 31(6):839-845.
[26]	张杰, JONES B, 张建勇. 不同埋藏深度交代白云石晶体结构及其对白云岩储层研究的意义[J]. 中国石油勘探, 2014, 19(3):21-28.
	ZHANG Jie, JONES B, ZHANG Jianyong. Crystal structure of replacement dolomite with different buried depths and its significance to study of dolomite reservoir[J]. China Petroleum Exploration, 2014, 19(3):21-28.
[27]	李茜, 胡安平, 沈安江, 等. 白云岩的成因、储集空间及实验技术研究新进展[J]. 石油与天然气地质, 2024, 45(5):1456-1482.
	LI Xi, HU Anping, SHEN Anjiang, et al. Recent advances in the study of the origin and reservoir space of dolomites and emerging experimental techniques[J]. Oil & Gas Geology, 2024, 45(5):1456-1482.
[28]	向鹏飞, 季汉成, 汪新伟, 等. 冀中坳陷奥陶系深层白云岩储集层成因机制[J]. 新疆石油地质, 2024, 45(6):659-670.
	XIANG Pengfei, JI Hancheng, WANG Xinwei, et al. Genetic mechanisms of deep Ordovician dolomite reservoirs in Jizhong depression[J]. Xinjiang Petroleum Geology, 2024, 45(6):659-670.
