Efficient Development Strategy for Ultra-Deep Fault-Controlled Volatile Reservoirs in Shunbei Oilfield

doi:10.7657/XJPG20250407

Abstract

Abstract:

The ultra-deep fault-controlled volatile reservoirs in Shunbei oilfield are characterized by great burial depth, significant thickness, and tabular distribution, with weak natural energy and rapid decline in both pressure and production during development. Early practice revealed that rapid water injection and high-rate gas injection tend to induce channeling through high-conductivity pathways between wells, compromising displacement efficiency and sweep volume. This paper presents a 3D composite gas-water injection-production strategy. To be specific, water injection is supplemented with gas injection for energy replenishment, so that injector-producer patterns are established with injecting water at lower position and producing oil from higher position, and injecting gas into higher position and producing oil from lower position, forming a 3D well pattern for composite gas-water injection and production. Water injection targets the unswept oil between wells and in middle-lower zones around wellbores, while gas injection displaces the oil at the top, thereby enhancing displacement efficiency and expanding sweep volume to ensure a long-term energy stability of the reservoir. Guided by this strategy, a typical composite gas-water drive unit is projected to enhance oil recovery by 26.0%, restore reservoir pressure by 9.0 MPa, reduce the gas-oil ratio to 820 m3/t, and increase flowing pressure to 45 MPa.

Key words: Shunbei oilfield, carbonate rock, fault-controlled, volatile reservoir, composite gas-water injection and production, development strategy

CLC Number:

TE344

REN Wenbo, LIU Diren, LI Xiaobo, CAO Fei, LIU Xueli, DAI Jincheng. Efficient Development Strategy for Ultra-Deep Fault-Controlled Volatile Reservoirs in Shunbei Oilfield[J]. Xinjiang Petroleum Geology, 2025, 46(4): 448-456.

Figures/Tables 11

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Table 1.

Fig. 5.

Fig. 6.

Fig. 7.

Table 2.

Fig. 8.

Fig. 9.

References 15

[1]	刘宝增. 塔里木盆地顺北地区油气差异聚集主控因素分析:以顺北1号、顺北5号走滑断裂带为例[J]. 中国石油勘探, 2020, 25(3):83-95. doi: 10.3969/j.issn.1672-7703.2020.03.008
	LIU Baozeng. Analysis on main controlling factors of oil and gas differential accumulation in Shunbei area,Tarim Basin:Taking Shunbei No.1 and No.5 strike slip fault zones as examples[J]. China Petroleum Exploration, 2020, 25(3):83-95. doi: 10.3969/j.issn.1672-7703.2020.03.008
[2]	王清华, 蔡振忠, 张银涛, 等. 塔里木盆地超深层走滑断控油气藏研究进展与趋势[J]. 新疆石油地质, 2024, 45(4):379-386.
	WANG Qinghua, CAI Zhenzhong, ZHANG Yintao, et al. Research progress and trend of ultra-deep strike-slip fault-controlled hydro- carbon reservoirs in Tarim Basin[J]. Xinjiang Petroleum Geology, 2024, 45(4):379-386.
[3]	段太忠, 张文彪, 何治亮, 等. 塔里木盆地顺北油田超深断溶体深度学习地质建模方法[J]. 石油与天然气地质, 2023, 44(1):203-212.
	DUAN Taizhong, ZHANG Wenbiao, HE Zhiliang, et al. Deep learning-based geological modeling of ultra-deep fault-karst reservoirs in Shunbei oilfield,Tarim Basin[J]. Oil & Gas Geology, 2023, 44(1):203-212.
[4]	王轲, 慈兴华, 杜焕福, 等. 塔里木盆地顺北碳酸盐岩元素地球化学特征与油气富集机制[J]. 世界石油工业, 2024, 31(2):55-64.
	WANG Ke, CI Xinghua, DU Huanfu, et al. Geochemical characteristics and oil & gas enrichment mechanisms of carbonate rocks in Shunbei area of Tarim Basin[J]. World Petroleum Industry, 2024, 31(2):55-64.
[5]	方俊伟, 董晓强, 李雄, 等. 顺北油田断溶体储集层特征及损害预防[J]. 新疆石油地质, 2021, 42(2):201-205.
	FANG Junwei, DONG Xiaoqiang, LI Xiong, et al. Characteristics and damage prevention of fault-karst reservoirs in Shunbei oilfield[J]. Xinjiang Petroleum Geology, 2021, 42(2):201-205.
[6]	杨学文, 汪如军, 邓兴梁, 等. 超深断控缝洞型碳酸盐岩油藏注水重力驱油理论探索[J]. 石油勘探与开发, 2022, 49(1):116-124. doi: 10.11698/PED.2022.01.10
	YANG Xuewen, WANG Rujun, DENG Xingliang, et al. Theoretical exploration of water injection gravity oil displacement in ultra-deep fault-controlled fractured-cavity carbonate reservoirs[J]. Petroleum Exploration and Development, 2022, 49(1):116-124.
[7]	陈杰, 王文训, 赵向国, 等. 利用水平井注水提高碳酸盐岩油藏开发水平:以阿曼D油田为例[R]. 北京:2016油气田勘探与开发国际会议, 2016.
	CHEN Jie, WANG Wenxun, ZHAO Xiangguo, et al. Increasing recovery in carbonate reservoir by horizontal producer/injector patterns:A case study in D oilfield,Oman[R]. Beijing:2016 International Field Exploration and Development Conference,2016.
[8]	王永兰, 文光耀, 李俊. 叙利亚Gbeibe油田裂缝性碳酸盐岩长岩心驱替实验研究[J]. 钻采工艺, 2015, 38(3):95-97.
	WANG Yonglan, WEN Guangyao, LI Jun. Long core displacement experiments for fractured carbonate reservoir of Gbeibe oilfield in Syria[J]. Drilling & Production Technology, 2015, 38(3):95-97.
[9]	郭秀英. Ekofisk油田及其注气、注水开采[J]. 国外油田工程, 1996(3):34-37.
	GUO Xiuying. Ekofisk oilfield and its gas injection and water injection production[J]. Foreign Oilfield Engineering, 1996(3):34-37.
[10]	许大钊. 顺北地区奥陶系储层成因机制研究[D]. 成都: 西南石油大学, 2018.
	XU Dazhao. Study on genetic mechanism of Ordovician reservoir in Shunbei area[D]. Chengdu: Southwest Petroleum University, 2018.
[11]	隋欢, 张哨楠. 塔里木盆地顺北一号断裂带奥陶系一间房组碳酸盐岩储集层主控因素研究[R]. 成都: 第十五届全国古地理学及沉积学学术会议, 2018.
	SUI Huan, ZHANG Shaonan. Study on the main controlling factors of Ordovician Yijianfang formation carbonate reservoir in Shunbei No.1 fault zone of Tarim Basin[R]. Chengdu:The 15th National Academic Conference on Paleogeography and Sedimentology, 2018.
[12]	胡文革. 塔里木盆地顺北地区不同断裂带油气充注能力表征研究与实践[J]. 石油与天然气地质, 2022, 43(3):528-541.
	HU Wenge. Study and practice of characterizing hydrocarbon charging capacity of different fault zones,Shunbei area,Tarim Basin[J]. Oil & Gas Geology, 2022, 43(3):528-541.
[13]	李小波, 魏学刚, 刘学利, 等. 顺北油田超深断控缝洞型油藏注水开发实践[J]. 新疆石油地质, 2023, 44(6):702-710.
	LI Xiaobo, WEI Xuegang, LIU Xueli, et al. Practice of water injection development in ultra-deep fault-controlled fractured-vuggy reservoirs in Shunbei oilfield[J]. Xinjiang Petroleum Geology, 2023, 44(6):702-710.
[14]	刘学利, 李小波, 谭涛, 等. 超深断溶体油藏注天然气混相驱数值模拟研究[J]. 非常规油气, 2024, 11(6):44-51.
	LIU Xueli, LI Xiaobo, TAN Tao, et al. Numerical simulation of miscible flooding with natural gas injection in ultra-deep fault-karst reservoir[J]. Unconventional Oil & Gas, 2024, 11(6):44-51.
[15]	鲁新便, 荣元帅, 李小波, 等. 碳酸盐岩缝洞型油藏注采井网构建及开发意义:以塔河油田为例[J]. 石油与天然气地质, 2017, 38(4):658-664.
	LU Xinbian, RONG Yuanshuai, LI Xiaobo, et al. Construction of injection-production well pattern in fractured-vuggy carbonate reservoir and its development significance:A case study from Tahe oilfield in Tarim Basin[J]. Petroleum & Natural Gas Geology, 2017, 38(4):658-664.

剩余油类型	补能方式	注采高度差/m	注采关系	驱替机理
高部位阁楼型剩余油	注气驱替、注气吞吐	>150	高注低采	天然气气顶驱天然气混相驱
井间注水未波及剩余油	人工底水驱+注气驱替	<150	等高注采	气水复合驱
井周中—下部未动用剩余油	人工底水驱	>150	低注高采	注水重力驱

阶段	注采参数	参数界限	作用机理
注水	注水时机	饱和压力之上压力保持程度大于55%	注水补充能量、油水置换和驱替作用
	注水方式	温和连续注水
	注水速度/（m³·d^-1）	挤压背景：250~300 拉分背景：500~600
注气	注气时机	最小混相压力+15%	混相驱替、气顶驱、补能和驱替作用
	注气方式	周期注气
	注气速度/（10⁴ m³·d^-1）	8~10
	气水周期	气水异步交替：注水3月注气2月
采油	注采比	1.5∶1.0~2.0∶1.0	均衡高效驱替
采油	总注入量/PV	0.2	均衡高效驱替
