Lithological Differences of Chang 7 Mud-Shale System and Their Controls on Shale Oil Content in Ansai Area, Ordos Basin

doi:10.7657/XJPG20250307

Abstract

Abstract:

Affected by source input and sedimentary cycles, continental mud-shale systems are lithologically complex and diverse. To elucidate the lithological differences of these systems and their controls on shale oil content, the mud-shale system in the 7th member of the Yanchang formation (Chang 7 member) in the Ansai area of Ordos Basin was selected for detailed analysis. By comparing petrological and geochemical characteristics, the development features of mudstone, shale, sandstone, and sand-laminated shale in the study area were identified. Through quantitative evaluation of shale oil content and analysis of geological parameters, the differences in shale oil content between different lithologies and the controlling factors were revealed. The results indicate that shale has the highest content of shale oil, with a poor mobility; sandstone and sand-laminated shale contain moderate content of shale oil, with a good mobility; and mudstone has the lowest content of shale oil, with the poorest mobility. For shale, mudstone, and sand-laminated shale, the higher the total organic carbon content and pyrolysis peak temperature, the higher the shale oil content; the better the organic matter types, the higher the shale oil content. For sandstone, the higher the porosity and permeability, the higher the shale oil content.

Key words: Ansai area, Yanchang formation, lithological difference, shale oil, quantitative evaluation, geological parameter

CLC Number:

P618.12

SHI Liang, ZHANG Yaxiong. Lithological Differences of Chang 7 Mud-Shale System and Their Controls on Shale Oil Content in Ansai Area, Ordos Basin[J]. Xinjiang Petroleum Geology, 2025, 46(3): 308-317.

Figures/Tables 14

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Table 1.

Fig. 6.

Fig. 7.

Fig. 8.

Fig. 9.

Fig. 10.

Table 2.

Fig. 11.

Fig. 12.

References 27

[1]	MOGHADDAM R N, JAMIOLAHMADY M. Fluid transport in shale gas reservoirs:Simultaneous effects of stress and slippage on matrix permeability[J]. International Journal of Coal Geology, 2016, 163:87-99.
[2]	王晓梅, 张水昌, 王华建, 等. 烃源岩非均质性及其意义:以中国元古界下马岭组页岩为例[J]. 石油勘探与开发, 2017, 44(1):32-39. doi: 10.11698/PED.2017.01.04
	WANG Xiaomei, ZHANG Shuichang, WANG Huajian, et al. Significance of source rock heterogeneities:A case study of Mesoproterozoic Xiamaling formation shale in north China[J]. Petroleum Exploration and Development, 2017, 44(1):32-39. doi: 10.11698/PED.2017.01.04
[3]	邹才能, 朱如凯, 白斌, 等. 致密油与页岩油内涵、特征、潜力及挑战[J]. 矿物岩石地球化学通报, 2015, 34(1):3-17.
	ZOU Caineng, ZHU Rukai, BAI Bin, et al. Significance,geologic characteristics,resource potential and future challenges of tight oil and shale oil[J]. Bulletin of Mineralogy,Petrology and Geochemistry, 2015, 34(1):3-17.
[4]	邹才能, 陶士振, 白斌, 等. 论非常规油气与常规油气的区别和联系[J]. 中国石油勘探, 2015, 20(1):1-16.
	ZOU Caineng, TAO Shizhen, BAI Bin, et al. Differences and relations between unconventional and conventional oil and gas[J]. China Petroleum Exploration, 2015, 20(1):1-16.
[5]	范柏江, 晋月, 师良, 等. 鄂尔多斯盆地中部三叠系延长组7段湖相页岩油勘探潜力[J]. 石油与天然气地质, 2021, 42(5):1078-1088.
	FAN Bojiang, JIN Yue, SHI Liang, et al. Shale oil exploration potential in central Ordos Basin:A case study of Chang 7 lacustrine shale[J]. Oil & Gas Geology, 2021, 42(5):1078-1088.
[6]	黄彦杰, 白玉彬, 孙兵华, 等. 鄂尔多斯盆地富县地区延长组长7烃源岩特征及评价[J]. 岩性油气藏, 2020, 32(1):66-75. doi: 10.12108/yxyqc.20200107
	HUANG Yanjie, BAI Yubin, SUN Binghua, et al. Characteristics and evaluation of Chang 7 source rock of Yanchang formation in Fuxian area,Ordos Basin[J]. Lithologic Reservoirs, 2020, 32(1):66-75. doi: 10.12108/yxyqc.20200107
[7]	肖晖, 赵靖舟, 熊涛, 等. 鄂尔多斯盆地古隆起西侧奥陶系烃源岩评价及成藏模式[J]. 石油与天然气地质, 2017, 38(6):1087-1097.
	XIAO Hui, ZHAO Jingzhou, XIONG Tao, et al. Evaluation of Ordovician source rocks and natural gas accumulation patterns in west flank of a paleo-uplift,Ordos Basin[J]. Oil & Gas Geology, 2017, 38(6):1087-1097.
[8]	高波, 武晓玲, 张英, 等. 鄂尔多斯盆地南部张家滩油页岩生烃演化特征[J]. 石油实验地质, 2022, 44(1):24-32.
	GAO Bo, WU Xiaoling, ZHANG Ying, et al. Hydrocarbon generation and evolution characteristics of Triassic Zhangjiatan oil shale in southern Ordos Basin[J]. Petroleum Geology & Experiment, 2022, 44(1):24-32.
[9]	范柏江, 梅启亮, 王小军, 等. 泥岩与页岩地化特征对比:以鄂尔多斯盆地安塞地区延长组7段为例[J]. 石油与天然气地质, 2020, 41(6):1119-1128.
	FAN Bojiang, MEI Qiliang, WANG Xiaojun, et al. Geochemical comparison of mudstone and shale:A case study of the 7th member of Yanchang formation in Ansai area,Ordos Basin[J]. Oil & Gas Geology, 2020, 41(6):1119-1128.
[10]	师良, 王香增, 范柏江, 等. 鄂尔多斯盆地延长组砂质纹层发育特征与油气成藏[J]. 石油与天然气地质, 2018, 39(3):522-530.
	SHI Liang, WANG Xiangzeng, FAN Bojiang, et al. Characteristics of sandy lamination and its hydrocarbon accumulation,Yanchang formation,Ordos Basin[J]. Oil & Gas Geology, 2018, 39(3):522-530.
[11]	朱日房, 张林晔, 李政, 等. 陆相断陷盆地页岩油资源潜力评价:以东营凹陷沙三段下亚段为例[J]. 油气地质与采收率, 2019, 26(1):129-136.
	ZHU Rifang, ZHANG Linye, LI Zheng, et al. Evaluation of shale oil resource potential in continental rift basin:A case study of lower Es₃ member in Dongying sag[J]. Petroleum Geology and Recovery Efficiency, 2019, 26(1):129-136.
[12]	薛海涛, 田善思, 王伟明, 等. 页岩油资源评价关键参数:含油率的校正[J]. 石油与天然气地质, 2016, 37(1):15-22.
	XUE Haitao, TIAN Shansi, WANG Weiming, et al. Correction of oil content:One key parameter in shale oil resource assessment[J]. Oil & Gas Geology, 2016, 37(1):15-22.
[13]	钱门辉, 黎茂稳, 蒋启贵, 等. 页岩岩心样品烃类散失特征与地质意义[J]. 石油实验地质, 2022, 44(3):497-504.
	QIAN Menhui, LI Maowen, JIANG Qigui, et al. Evaluation of evaporative loss of hydrocarbon in shale samples and its geological implications[J]. Petroleum Geology & Experiment, 2022, 44(3):497-504.
[14]	谌卓恒, 黎茂稳, 姜春庆, 等. 页岩油的资源潜力及流动性评价方法:以西加拿大盆地上泥盆统Duvernay页岩为例[J]. 石油与天然气地质, 2019, 40(3):459-468.
	CHEN Zhuoheng, LI Maowen, JIANG Chunqing, et al. Shale oil resource potential and its mobility assessment:A case study of Upper Devonian Duvernay shale in Western Canada Sedimentary Basin[J]. Oil & Gas Geology, 2019, 40(3):459-468.
[15]	刘岩. 鄂尔多斯盆地南部镇泾油田长8段储层特征研究[D]. 成都: 成都理工大学, 2008.
	LIU Yan. Research on the reservoir characteristics of the Chang-8 member of the Yanchang formation in Zhenjing oilfield,Ordos Basin[D]. Chengdu: Chengdu University of Technology, 2008.
[16]	邵才瑞, 张鹏飞, 张福明, 等. 用J函数提高致密砂岩气层饱和度测井评价精度[J]. 中国石油大学学报(自然科学版), 2016, 40(4):57-65.
	SHAO Cairui, ZHANG Pengfei, ZHANG Fuming, et al. Improving well log evaluation accuracy of tight sandstone gas saturation using J function[J]. Journal of China University of Petroleum (Edition of Natural Science), 2016, 40(4):57-65.
[17]	BEHAR F, EAUMONT V B, PENTEADO H L D B. Rock-Eval 6 technology:Performances and developments[J]. Oil & Gas Science and Technology, 2001, 2:56.
[18]	JARVIE D M. Shale resource systems for oil and gas:Part 2:shale-oil resource systems[J]. AAPG Memoir, 2012, 97:89-119.
[19]	HU Tao, PANG Xiongqi, JIANG Shu, et al. Oil content evaluation of lacustrine organic-rich shale with strong heterogeneity:A case study of the Middle Permian Lucaogou formation in Jimusaer sag,Junggar Basin,NW China[J]. Fuel, 2018, 221:196-205.
[20]	孙建博, 石彬, 郭超, 等. 鄂尔多斯盆地富县地区三叠系延长组长7₃亚段页岩油储层特征与勘探前景[J]. 中国石油勘探, 2023, 28(4):79-91. doi: 10.3969/j.issn.1672-7703.2023.04.008
	SUN Jianbo, SHI Bin, GUO Chao, et al. Characteristics of shale oil reservoir and exploration prospects in the third sub-member of the seventh member of the Triassic Yanchang formation in Fuxian area,Ordos Basin[J]. China Petroleum Exploration, 2023, 28(4):79-91. doi: 10.3969/j.issn.1672-7703.2023.04.008
[21]	黄振凯, 郝运轻, 李双建, 等. 鄂尔多斯盆地长7段泥页岩层系含油气性与页岩油可动性评价:以H317井为例[J]. 中国地质, 2020, 47(1):210-219.
	HUANG Zhenkai, HAO Yunqing, LI Shuangjian, et al. Oil-bearing potential,mobility evaluation and significance of shale oil in Chang 7 shale system in the Ordos Basin:A case study of Well H317[J]. Geology in China, 2020, 47(1):210-219.
[22]	潘松圻, 郭秋雷, 邹才能, 等. 页岩型与粉砂岩型“页岩油系统”甜点段判识:以鄂尔多斯盆地长7段为例[J]. 中国科学:地球科学, 2023, 53(7):1663-1678.
	PAN Songqi, GUO Qiulei, ZOU Caineng, et al. Identification of sweet spots in shale-type and siltstone-type “shale oil systems”:A case study of the Chang 7 member in Ordos Basin[J]. Science China:Earth Sciences, 2023, 53(7):1663-1678.
[23]	王艺帆, 刚文哲, 朱传真, 等. 歧口凹陷沙三段烃源岩评价及生排烃特征[J]. 油气地质与采收率, 2023, 30(3):11-27.
	WANG Yifan, GANG Wenzhe, ZHU Chuanzhen, et al. Source rock evaluation and hydrocarbon generation and expulsion characteristics in Es₃ in Qikou sag[J]. Petroleum Geology and Recovery Efficiency, 2023, 30(3):11-27.
[24]	宋海强, 刘慧卿, 王敬, 等. 鄂尔多斯盆地东南部长7段页岩油气富集主控因素[J]. 新疆石油地质, 2024, 45(1):27-34.
	SONG Haiqiang, LIU Huiqing, WANG Jing, et al. Main controlling factors of shale oil and gas enrichment in Chang 7 member,southeastern Ordos Basin[J]. Xinjiang Petroleum Geology, 2024, 45(1):27-34.
[25]	王剑, 刘金, 潘晓慧, 等. 吉木萨尔凹陷芦草沟组页岩油生烃母质及其生烃机理[J]. 新疆石油地质, 2024, 45(3):253-261.
	WANG Jian, LIU Jin, PAN Xiaohui, et al. Precursor and mechanism of hydrocarbon generation for shale oil in Lucaogou formation, Jimsar sag[J]. Xinjiang Petroleum Geology, 2024, 45(3):253-261.
[26]	陈掌星, 冯东, 吴克柳, 等. 页岩气有机质和无机质吸附能力定量表征[J]. 中国石油大学学报(自然科学版), 2023, 47(5):65-75.
	CHEN Zhangxing, FENG Dong, WU Keliu, et al. Quantificational determination of methane adsorption in organic matter and inorganic matter of shale rocks[J]. Journal of China University of Petroleum (Edition of Natural Science), 2023, 47(5):65-75.
[27]	付金华, 牛小兵, 淡卫东, 等. 鄂尔多斯盆地中生界延长组长7段页岩油地质特征及勘探开发进展[J]. 中国石油勘探, 2019, 24(5):601-614. doi: 10.3969/j.issn.1672-7703.2019.05.007
	FU Jinhua, NIU Xiaobing, DAN Weidong, et al. The geological characteristics and the progress on exploration and development of shale oil in Chang 7 member of Mesozoic Yanchang formation,Ordos Basin[J]. China Petroleum Exploration, 2019, 24(5):601-614. doi: 10.3969/j.issn.1672-7703.2019.05.007

赋存岩性	大量页岩油散失时间/min	散失速度	评价方法	页岩油含量	页岩油可动性
页岩	>45	慢	地球化学法	最高	最差
泥岩	>45	慢	地球化学法	适中	差
砂纹层页岩	30~40	较慢	地球化学法	适中	好
砂岩	<20	快	基于压汞实验的J函数法	最低	最好

有机质类型	岩性	页岩油含量/（mg·g^-1）
有机质类型	岩性	最大值	最小值	平均值
Ⅰ型	页岩	36.8	12.8	21.7
	泥岩	44.7	8.2	26.4
	砂纹层页岩	24.9	7.5	16.1
Ⅱ₁型	页岩	17.7	2.7	11.0
	泥岩	8.4	1.4	4.9
	砂纹层页岩	34.1	10.5	18.1
Ⅱ₂型	页岩	18.5	18.5	18.5
	泥岩	19.6	1.1	9.9
	砂纹层页岩	13.0	7.0	10.0
Ⅲ型	砂纹层页岩	6.2	6.2	6.2
