Development Performance and Influencing Factors of Bottom-Water Drive in Fractured-Vuggy Collapse-Packed Reservoirs

doi:10.7657/XJPG20250409

Abstract

Abstract:

To address the challenges of unclear fluid migration patterns and difficulties in predicting displacement efficiency during bottom-water drive development of fractured-vuggy collapse-packed reservoirs, by employing multi-model physical simulations based on similarity criteria, and incorporating reservoir properties, fluid migration patterns and conditions, two conceptual models for collapse-packed reservoirs were established. Physical simulation experiments were conducted under varying conditions, including medium-filling types, flow rate, and initial oil saturation. The variations in liquid production rate, water breakthrough time, water cut, and recovery factor in different models and with different influencing factors were investigated. The results demonstrate that the liquid production rate curve can be used to judge water breakthrough time which is primarily governed by initial oil saturation and flow rate. After water breakthrough, water cut typically exhibits a rapid rise, followed by fluctuations. The recovery factor shows a negative correlation with flow rate.

Key words: fractured-vuggy reservoir, collapse-packed reservoir, bottom-water drive, physical simulation, liquid production rate, water breakthrough time, water cut, recovery factor

CLC Number:

TE341

YANG Debin, YU Tengfei, GUO Chuan, ZHONG Wei, ZHAO Yuan. Development Performance and Influencing Factors of Bottom-Water Drive in Fractured-Vuggy Collapse-Packed Reservoirs[J]. Xinjiang Petroleum Geology, 2025, 46(4): 465-469.

Figures/Tables 6

Fig. 1.

Fig. 2.

Table 1.

Fig. 3.

Fig. 4.

Fig. 5.

References 18

[1]	胡文革. 塔河碳酸盐岩缝洞型油藏开发技术及攻关方向[J]. 油气藏评价与开发, 2020, 10(2):1-10.
	HU Wenge. Development technology and research direction of fractured-vuggy carbonate reservoirs in Tahe oilfield[J]. Reservoir Evaluation and Development, 2020, 10(2):1-10.
[2]	徐勤琪, 张黎, 李斌, 等. 塔河油田下寒武统烃源岩生排烃史差异演化及成藏效应[J]. 特种油气藏, 2024, 31(1):20-30. doi: 10.3969/j.issn.1006-6535.2024.01.003
	XU Qinqi, ZHANG Li, LI Bin, et al. Differential evolutions of hydrocarbon generation and expulsion history of Lower Cambrian source rocks in Tahe oilfield and accumulation effects[J]. Special Oil & Gas Reservoirs, 2024, 31(1):20-30.
[3]	伍家和, 李宗宇. 缝洞型碳酸盐岩油藏溶洞描述技术研究[J]. 石油地质与工程, 2010, 24(4):34-39.
	WU Jiahe, LI Zongyu. Technical research of karst cave description in fracture-cavity carbonate reservoir[J]. Petroleum Geology and Engineering, 2010, 24(4):34-39.
[4]	巫波, 杨文东, 吕晶, 等. 塔河油田缝洞型储集层类型综合识别[J]. 新疆石油地质, 2023, 44(2):238-244.
	WU Bo, YANG Wendong, LYU Jing, et al. Comprehensive identification of fractured-vuggy reservoirs in Tahe oilfield[J]. Xinjiang Petroleum Geology, 2023, 44(2):238-244.
[5]	李阳. 塔河油田碳酸盐岩缝洞型油藏开发理论及方法[J]. 石油学报, 2013, 34(1):115-121.
	LI Yang. The theory and method for development of carbonate fractured-cavity reservoirs in Tahe oilfield[J]. Acta Petrolei Sinica, 2013, 34(1):115-121. doi: 10.7623/syxb201301013
[6]	胡文革, 李小波, 杨敏, 等. 塔河油田碳酸盐岩缝洞型油藏井网优化[J]. 新疆石油地质, 2023, 44(4):429-434.
	HU Wenge, LI Xiaobo, YANG Min, et al. Well pattern optimization for fractured-vuggy carbonate reservoirs in Tahe oilfield[J]. Xinjiang Petroleum Geology, 2023, 44(4):429-434.
[7]	胡向阳, 权莲顺, 齐得山, 等. 塔河油田缝洞型碳酸盐岩油藏溶洞充填特征[J]. 特种油气藏, 2014, 21(1):18-21.
	HU Xiangyang, QUAN Lianshun, QI Deshan, et al. Featrues of cavern filling in fractured/vuggy carbonate oil reservoirs,Tahe oilfield[J]. Special Oil & Gas Reservoirs, 2014, 21(1):18-21.
[8]	田飞. 塔河油田碳酸盐岩岩溶缝洞结构和充填模式研究[D]. 山东青岛: 中国石油大学(华东), 2014.
	TIAN Fei. Investigation on construction and filling model of carbonate paleokarst fracture-caves in the Tahe oilfield[D]. Qingdao,Shandong: China University of Petroleum(East China), 2014.
[9]	张长建, 吕艳萍, 马海陇, 等. 塔河油田岩溶峡谷区伏流坍塌型古暗河缝洞系统[J]. 新疆石油地质, 2023, 44(1):9-17.
	ZHANG Changjian, LYU Yanping, MA Hailong, et al. Fracture-cave system in collapsed underground paleo-river with subterranean flow in karst canyon area,Tahe oilfield[J]. Xinjiang Petroleum Geology, 2023, 44(1):9-17.
[10]	牛玉静. 缝洞型碳酸盐岩油藏溶洞储集体岩溶塌陷结构特征研究[D]. 北京: 中国地质大学(北京), 2012.
	NIU Yujing. Study on the structural and characteristics of karst collapse in fractured & cave carbonate reservoir[D]. Beijing: China University of Geosciences(Beijing), 2012.
[11]	王建峰, 邓光校, 李涛, 等. 塔河油田奥陶系碳酸盐岩古岩溶垮塌体特征及成因[J]. 新疆石油地质, 2017, 38(4):385-391.
	WANG Jianfeng, DENG Guangxiao, LI Tao, et al. Characteristics and genesis of paleo-karst collapses in Ordovician carbonate rocks,Tahe oilfield[J]. Xinjiang Petroleum Geology, 2017, 38(4):385-391.
[12]	荣元帅, 黄咏梅, 刘学利, 等. 塔河油田缝洞型油藏单井注水替油技术研究[J]. 石油钻探技术, 2008, 36(4):57-60.
	RONG Yuanshuai, HUANG Yongmei, LIU Xueli, et al. Single well water injection production in Tahe fracture-vuggy reservoir[J]. Petroleum Drilling Techniques, 2008, 36(4):57-60.
[13]	明瑞卿, 贺会群, 胡强法. 底水凝析气藏见水时间预测新方法[J]. 特种油气藏, 2018, 25(5):99-103.
	MING Ruiqing, HE Huiqun, HU Qiangfa. A new method to predict water breakthrough time in condense gas reservoir with bottom-aquifer[J]. Special Oil & Gas Reservoirs, 2018, 25(5):99-103.
[14]	程晓军. 塔河油田缝洞型油藏水驱后气驱提高采收率可视化实验[J]. 新疆石油地质, 2018, 39(4):473-479.
	CHENG Xiaojun. Visualized gas drive EOR experiments in fractured-vuggy reservoirs after waterflooding in Tahe oilfield[J]. Xinjiang Petroleum Geology, 2018, 39(4):473-479.
[15]	张辉, 彭小东, 刘鑫, 等. 底水油藏含水上升规律研究:以 Y2 油藏西北区为例[J]. 科学技术与工程, 2012, 12(35):9470-9474.
	ZHANG Hui, PENG Xiaodong, LIU Xin, et al. The study on the bottom water reservoir water cut rising characteristics:Take the northwest block of Y2 reservoir as an example[J]. Science Technology and Engineering, 2012, 12(35):9470-9474.
[16]	王敬, 刘慧卿, 宁正福, 等. 缝洞型油藏溶洞-裂缝组合体内水驱油模型及实验[J]. 石油勘探与开发, 2014, 41(1):67-73.
	WANG Jing, LIU Huiqing, NING Zhengfu, et al. Experiments on water flooding in fractured-vuggy cells in fractured-vuggy reservoirs[J]. Petroleum Exploration and Development, 2014, 41(1):67-73.
[17]	郑松青, 杨敏, 康志江, 等. 塔河油田缝洞型碳酸盐岩油藏水驱后剩余油分布主控因素与提高采收率途径[J]. 石油勘探与开发, 2019, 46(4):746-754. doi: 10.11698/PED.2019.04.13
	ZHENG Songqing, YANG Min, KANG Zhijiang, et al. Controlling factors of remaining oil distribution after water flooding and enhanced oil recovery methods for fracture-cavity carbonate reservoirs in Tahe oilfield[J]. Petroleum Exploration and Development, 2019, 46(4):746-754.
[18]	隋宏光, 王殿生, 刘金玉, 等. 缝洞型介质结构对水驱油采收率影响的物理模型实验研究[J]. 西安石油大学学报(自然科学版), 2011, 26(6):52-56.
	SUI Hongguang, WANG Diansheng, LIU Jinyu, et al. Experimental study on the effect of the structure of fracture-vuggy media on oil recovery factor of water flooding[J]. Journal of Xi’an Shiyou University(Natural Science Edition), 2011, 26(6):52-56.

实验方案	模型	原始含油量/g	流速/ （mL·min^-1）	见水时间/min
实验方案	模型	原始含油量/g	流速/ （mL·min^-1）	产液速度曲线判断	压力曲线判断
A1	基本模型	2 185.63	60	35		不明显
A2	基本模型	2 919.01	60	45		48
A3	基本模型	3 807.50	60	59		不明显
B1	均匀模型	2 786.86	15	181		不明显
B2	均匀模型	2 564.52	30	91		不明显
B3	均匀模型	2 570.89	60	35		34
C1	封隔模型	2 306.57	15	144		不明显
C2	封隔模型	2 512.17	30	76		88
C3	封隔模型	2 502.15	60	35		38
