基于XGBoost算法的地震多数据体识别含油河道砂体

doi:10.7657/XJPG20200414

新疆石油地质 ›› 2020, Vol. 41 ›› Issue (4): 477-482.doi: 10.7657/XJPG20200414

基于XGBoost算法的地震多数据体识别含油河道砂体

张艺山¹(), 徐怀宝^2a, 齐洪岩^2a, 谢天寿^2a, 杨远峰^2b, 杨邦伟^2b

1.北京大学地球与空间科学学院,北京 100871;
2.中国石油新疆油田分公司 a.勘探开发研究院;b.百口泉采油厂,新疆克拉玛依 834000

收稿日期:2020-04-29 修回日期:2020-05-06 出版日期:2020-08-01 发布日期:2020-08-05
作者简介:张艺山（1992-）,男,山东青岛人,博士研究生,应用数学,（Tel）17301120037（E-mail）ys_zhang@pku.edu.cn
基金资助:
国家科技重大专项(2017ZX05001-004);中国石油科技重大专项(2017E-0401)

Using Multiple Seismic Data Volume to Identify Oil-Bearing Channel Sandbodies Based on XGBoost Algorithm

ZHANG Yishan¹(), XU Huaibao^2a, QI Hongyan^2a, XIE Tianshou^2a, YANG Yuanfeng^2b, YANG Bangwei^2b

1. School of Earth and Space Sciences, Peking University, Beijing 100871, China;
2. PetroChina Xinjiang Oilfield Company, a.Research Institute of Exploration and Development; b.Baikouquan Oil Production Plant, Karamay, Xinjiang 834000, China

Received:2020-04-29 Revised:2020-05-06 Online:2020-08-01 Published:2020-08-05

摘要/Abstract

摘要：

准噶尔盆地东部侏罗系多发育陆相河道砂体,砂体厚度小且横向连续性差,具有“一砂一藏”的特征,油水关系复杂,油气预测难度大,单一的地球物理信息难以准确确定河道砂体的分布特征和孔隙流体性质。为此,提出采用XGBoost算法从叠后地震剖面、叠后纵波阻抗和叠前纵横波速度比3种地震数据体中提取含油河道砂体的特征,以有效描述这类河道砂体含油性的空间展布特征,降低了利用常规单一地震属性对含不同流体砂岩储集层预测的多解性。通过模型测试证明了该方法在识别陆相河道砂体的含油气性方面的可行性,并在实际应用中取得了较好的效果。

关键词: 准噶尔盆地, 头屯河组, 河道砂体, XGBoost算法, 叠后纵波阻抗, 叠前纵横波速度比, 含油砂体预测, 模型测试

Abstract:

Continental channel sandbodies are usually developed in the Jurassic strata of the eastern Junggar basin, which are characterized by poor lateral continuity, thin thickness and one reservoir in one sandbody, leading to difficulties in hydrocarbon prediction. It is hard to accurately determine the channel sandbody distribution and pore fluid properties by using single geophysical information. Therefore, XGBoost algorithm is presented, by which the characteristics about the oil-bearing channel sandbody can be identified from several seismic data volume such as post-stack seismic section, post-stack P-wave impedance and pre-stack wave velocity ratio, and the distribution of the kind of oil-bearing channel sandbodies can be effectively described and multi-solution of the prediction of sandstone reservoirs containing multiple fluids by using conventional profiles of a single seismic attribute can be solved. The test of the model proves the feasibility of using the method to identify the oil-bearing properties of continental channel sandbodies and good effects have been gained in field application.

Key words: Junggar basin, Toutunhe formation, channel sandbody, XGBoost algorithm, post-stack P-wave impedance, pre-stack wave velocity ratio, oil-bearing sandbody prediction, model test

中图分类号:

P618.13

张艺山, 徐怀宝, 齐洪岩, 谢天寿, 杨远峰, 杨邦伟. 基于XGBoost算法的地震多数据体识别含油河道砂体[J]. 新疆石油地质, 2020, 41(4): 477-482.

ZHANG Yishan, XU Huaibao, QI Hongyan, XIE Tianshou, YANG Yuanfeng, YANG Bangwei. Using Multiple Seismic Data Volume to Identify Oil-Bearing Channel Sandbodies Based on XGBoost Algorithm[J]. Xinjiang Petroleum Geology, 2020, 41(4): 477-482.

图/表 6

图1

图2

图3

图4

图5

图6

参考文献 19

[1]	柳妮, 王磊, 于景维, 等. 阜东斜坡区头屯河组短期旋回不同结构类型内储层非均质性研究[J]. 地质与勘探, 2017,53(6):1 208-1 218.
	LIU Ni, WANG Lei, YU Jingwei, et al. Heterogeneity of reservoirs of different compositional types of short-term cycles in the Toutunhe formation of the Fudong slope area[J]. Geology and Exploration, 2017,53(6):1 208-1 218.
[2]	陈洪, 顾绍富, 张顺存, 等. 准噶尔盆地阜东斜坡区侏罗系石树沟群储层主控因素[J]. 天然气地球科学, 2015,26(增刊2):33-43.
	CHEN Hong, GU Shaofu, ZHANG Shuncun, et al. Main controllingfactors of reservoirs of Jurassic Shishugou formation in Fudong slope,Junggar basin[J]. Natural Gas Geoscience, 2015,26(Supp.2):33-43.
[3]	张远银, 孙赞东, 杨海军, 等. 中古8井区孔洞型碳酸盐岩储集层流体地震预测[J]. 新疆石油地质, 2019,40(5):610-614.
	ZHANG Yuanyin, SUN Zandong, YANG Haijun, et al. Seismic fluid prediction in caved carbonate reservoirs in Wellblock ZG8,Tarim basin[J]. Xinjiang Petroleum Geology, 2019,40(5):610-614.
[4]	姜蕾, 张云银, 林中凯. 敏感属性融合技术预测深部薄互层砂岩:以临南地区沙三下亚段河道砂体为例[J]. 新疆石油地质, 2019,40(6):725-730.
	JIANG Lei, ZHANG Yunyin, LIN Zhongkai. Sensitive attribute fusion technology to predict deep thin interbedded reservoir:a case from channel sand bodies in the Lower Sha-3 member of Shahejie formation in Linnan area[J]. Xinjiang Petroleum Geology, 2019,40(6):725-730.
[5]	HUANG Junbin, GAO Lijun, GAO Yong. Side lobes of wavelets impact identification of thin sand bodies[J]. Applied Geophysics, 2007,4(2):111-117.
[6]	ZENG Hongliu. Geologic significance of anomalous instantaneous frequency[J]. Geophysics, 2010,75(3):23-30.
[7]	伊振林. 井震联合窄小河道砂体预测方法研究[J]. 西南石油大学学报(自然科学版), 2012,34(1):19-24.
	YI Zhenlin. Prediction method of narrow channel sand body in well-to-seismic integration[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2012,34(1):19-24.
[8]	HIDALGO R, HARYONO S, SCHNEIDER M, et al. 3-D seismic interpretation of thin gas sandstone reservoirs using multiattribute analysis on poststack and AVO data,offshore SE Sumatra[J]. The Leading Edge, 2001,20(4):364-370.
[9]	HARILAL , RAO C G, SAXENA R C P, et al. Mapping thin sandstone reservoirs:application of 3D visualization and spectral decomposition techniques[J]. The Leading Edge, 2009,28(2):156-167.
[10]	沈加刚, 宋宗平, 关晓巍. 基于地震属性的支持向量机河道砂体厚度预测[J]. 西南石油大学学报(自然科学版), 2014,36(3):75-81.
	SHEN Jiagang, SONG Zongping, GUAN Xiaowei. Application of support vector machine to the prediction of thickness of channel sand based on seismic attributes[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2014,36(3):75-81.
[11]	李诒靖, 郭海湘, 李亚楠, 等. 一种基于Boosting的集成学习算法在不均衡数据中的分类[J]. 系统工程理论与实践, 2016,36(1):189-199.
	LI Yijing, GUO Haixiang, LI Ya’nan, et al. A boosting based ensemble learning algorithm in imbalanced data classification[J]. Systems Engineering—Theory & Practice, 2016,36(1):189-199.
[12]	CRACKNELL M J, READING A M. The upside of uncertainty：identification of lithology contact zones from airborne geophysics and satellite data using random forest and support vector machines[J]. Geophysics, 2013,78(3):WB113-WB126.
[13]	TORLAY L, PERRONE BERTOLOTTI M, THOMAS E, et al. Machine learning-XGBoost analysis of language networks to classify patients with epilepsy[J]. Brain Informatics, 2017,4:159-169. doi: 10.1007/s40708-017-0065-7 pmid: 28434153
[14]	贾文慧, 孙林子, 景英川. 基于XGBoost模型的股骨颈骨折手术预后质量评分预测[J]. 太原理工大学学报, 2018,49(1):174-178.
	JIA Wenhui, SUN Linzi, JING Yingchuan. Surgical prognosis quality score of femoral neck fracture based on XGBoost model[J]. Journal of Taiyuan University of Technology, 2018,49(1):174-178.
[15]	闫星宇, 顾汉明, 肖逸飞, 等. XGBoost算法在致密砂岩气储层测井解释中的应用[J]. 石油地球物理勘探, 2019,54(2):447-455.
	YAN Xingyu, GU Hanming, XIAO Yifei, et al. XGBoost algorithm applied in the interpretation of tight-sand gas reservoir on well logging data[J]. Oil Geophysical Prospecting, 2019,54(2):447-455.
[16]	程志国, 谭佳, 宋永, 等. 阜东地区河道砂体AVO油气预测研究[J]. 新疆石油地质, 2013,34(3):338-340.
	CHENG Zhiguo, TAN Jia, SONG Yong, et al. AVO oil-gas prediction study of channel sands in Fudong area of Junggar basin[J]. Xinjiang Petroleum Geology, 2013,34(3):338-340.
[17]	FRIEDMAN J H. Greedy function approximation:a gradient boosting machine[J]. The Annals of Statistics, 2001,29(5):1 189-1 232.
[18]	宋建国, 杨璐, 高强山, 等. 强容噪性随机森林算法在地震储层预测中的应用[J]. 石油地球物理勘探, 2018,53(5):954-960.
	SONG Jianguo, YANG Lu, GAO Qiangshan, et al. Strong tolerance random forest algorithm in seismic reservoir prediction[J]. Oil Geophysical Prospecting, 2018,53(5):954-960.
[19]	MARTING S, WILEY R, MARFURT K J. Marmousi2:an elastic upgrade for Marmousi[J]. The Leading Edge, 2006,25(2):156-166.
