台北凹陷下侏罗统致密砂岩气成藏条件与勘探方向

doi:10.7657/XJPG20220501

摘要/Abstract

摘要：

吐哈盆地下侏罗统油气资源潜力大,剩余资源量多,已发现的油气藏主要分布于台北凹陷胜北洼陷和丘东洼陷周边的正向构造带,以构造油气藏为主,洼陷腹部油气勘探研究程度低。基于对已知油气藏的解剖,对台北凹陷三大富烃洼陷的沉积体系、烃源岩、储集层和成藏条件开展系统研究。结果表明,台北凹陷水西沟群煤系烃源岩广泛发育,与辫状河三角洲砂岩大面积接触,利于形成近源致密砂岩气藏。下侏罗统发育圈闭型和连续型2类致密砂岩气藏,其中洼陷腹部是连续型致密砂岩气成藏的有利区,勘探应由源边正向构造转向富烃洼陷,由源上常规油藏向近源（源内）致密砂岩气藏转变,胜北洼陷和丘东洼陷腹部具备形成大气藏的条件,是下侏罗统近源大面积致密砂岩气藏勘探的有利区域。

关键词: 吐哈盆地, 台北凹陷, 致密砂岩气藏, 生烃洼陷, 下侏罗统, 油气成藏条件, 勘探潜力

Abstract:

The Turpan-Hami basin has great potential of oil and gas resources in the Lower Jurassic strata, with a large quantity of remaining resources. The discovered oil and gas reservoirs are mainly distributed in the positive structural belts around the Shengbei and Qiudong subsags in the Taibei sag, and they are primarily structural reservoirs. Less researches on the oil and gas resources in the hinterland of the subsags have been performed. Based on the dissection of known reservoirs, a systematic study was carried out on the depositional system, source rock, reservoir rock and accumulation conditions of three major hydrocarbon-rich subsags in the Taibei sag. The results show that the coal-measure source rocks are widely developed in the Shuixigou group in the Taibei sag and are in broad contact with the braided river delta sandstones, which is conducive to the formation of near-source tight sandstone gas reservoirs. There are two types of tight sandstone gas reservoirs in the Lower Jurassic, namely, trap-type and continuous-type. The hinterlands of the subsags are favorable areas for the formation of continuous-type tight sandstone gas reservoirs. Therefore, the exploration should be switched from the source-edge positive structure to the hydrocarbon-rich subsag, and from the above-source conventional oil reservoirs to the in/near-source tight sandstone gas reservoirs. The hinterlands of the Shengbei and Qiudong subsags have the conditions to form large gas reservoirs, so they are favorable areas for exploring near-source tight sandstone gas reservoirs in the lower Jurassic.

Key words: Turpan-Hami basin, Taibei sag, tight sandstone gas reservoir, hydrocarbon-generating subsag, Lower Jurassic, hydrocarbon accumulation condition, exploration potential

中图分类号:

TE122.1

陈旋, 王居峰, 肖冬生, 刘俊田, 苟红光, 张华, 林霖, 李宏伟. 台北凹陷下侏罗统致密砂岩气成藏条件与勘探方向[J]. 新疆石油地质, 2022, 43(5): 505-512.

CHEN Xuan, WANG Jufeng, XIAO Dongsheng, LIU Juntian, GOU Hongguang, ZHANG Hua, LIN Lin, LI Hongwei. Accumulation Conditions and Exploration Direction of Lower Jurassic Tight Sandstone Gas Reservoirs in Taibei Sag[J]. Xinjiang Petroleum Geology, 2022, 43(5): 505-512.

图/表 7

图1

图2

表1

图3

图4

图5

图6

参考文献 18

[1]	翟光明, 胡见义, 赵文智, 等. 科学探索井历程、成效及意义:纪念科学探索井项目实践30周年[J]. 石油勘探与开发, 2016, 43(2):153-165.
	ZHAI Guangming, HU Jianyi, ZHAO Wenzhi, et al. History,achievements and significance of scientific exploration wells:for the 30^th anniversary of the “scientific exploration well” program[J]. Petroleum Exploration and Development, 2016, 43(2):153-165.
[2]	李伟, 梁世君, 姜均伟, 等. 吐鲁番坳陷鲁克沁稠油油藏形成及演化特征[J]. 石油学报, 2006, 27(6):14-18. doi: 10.7623/syxb200606003
	LI Wei, LIANG Shijun, JIANG Junwei, et al. Special migration and accumulation of heavy oil reservoir in Lukeqin area of Turpan depression[J]. Acta Petrolei Sinica, 2006, 27(6):14-18. doi: 10.7623/syxb200606003
[3]	戴金星. 中国煤成气研究二十年的重大进展[J]. 石油勘探与开发, 1999, 26(3):1-10.
	DAI Jinxing. Significant advancement in research on coal-formed gas in China[J]. Petroleum Exploration and Development, 1999, 26(3):1-10.
[4]	赵长毅, 程克明, 王飞宇. 吐哈盆地煤成烃主要贡献组分剖析[J]. 沉积学报, 1997, 15(2):95-99.
	ZHAO Changyi, CHENG Keming, WANG Feiyu. Analyses of the macerals contributing mainly to hydrocarbons derived from coals of the Turpan-Hami basin[J]. Acta Sedimentologica Sinica, 1997, 15(2):95-99.
[5]	戴金星, 宋岩, 孙永祥. 吐鲁番-哈密盆地的煤成气[J]. 石油勘探与开发, 1993, 20(2):6-10.
	DAI Jinxing, SONG Yan, SUN Yongxiang. Coal-formed gas in Turpan-Hami basin[J]. Petroleum Exploration and Development, 1993, 20(2):6-10.
[6]	梁世君. 吐哈探区油气勘探成果及潜力[J]. 新疆石油地质, 2020, 41(6):631-641.
	LIANG Shijun. Achievements and potential of petroleum exploration in Tuha oil and gas province[J]. Xinjiang Petroleum Geology, 2020, 41(6):631-641.
[7]	王国亭, 李易隆, 何东博, 等. “改造型”致密砂岩气藏特征:以吐哈盆地巴喀气田下侏罗统八道湾组为例[J]. 地质科技情报, 2014, 33(3):118-125.
	WANG Guoting, LI Yilong, HE Dongbo, et al. Characteristics of “subsequent” tight gas accumulation:a case from Badaowan formation of Lower Jurassic in Baka gas field,Tuha basin[J]. Geological Science and Technology Information, 2014, 33(3):118-125.
[8]	李光云, 赖富强, 何加成, 等. 吐哈盆地丘东洼陷下侏罗统致密砂岩储层特征及物性主控因素[J]. 天然气地球科学, 2013, 24(2):310-319.
	LI Guangyun, LAI Fuqiang, HE Jiacheng, et al. Reservoir characteristic and controlling factors on physical properties of Lower Jurassic tight sandstone in the Qiudong sub-sag,Turpan-Hami basin[J]. Natural Gas Geoscience, 2013, 24(2):310-319.
[9]	杨升宇, 张金川, 黄卫东, 等. 吐哈盆地柯柯亚地区致密砂岩气储层“甜点”类型及成因[J]. 石油学报, 2013, 34(2):272-282. doi: 10.7623/syxb201302009
	YANG Shengyu, ZHANG Jinchuan, HUANG Weidong, et al. “Sweet spot”types of reservoirs and genesis of tight sandstone gas in Kekeya area,Turpan-Hami basin[J]. Acta Petrolei Sinica, 2013, 34(2):272-282. doi: 10.7623/syxb201302009
[10]	范谭广. 吐哈盆地台北凹陷水西沟群致密砂岩气成藏条件[J]. 天然气工业, 2011, 31(7):21-23.
	FAN Tanguang. Gas accumulation conditions of the Shuixigou tight sand formations in the Taibei trough Turpan-Hami basin[J]. Natural Gas Industry, 2011, 31(7):21-23.
[11]	柳波, 黄志龙, 罗权生, 等. 吐哈盆地北部山前带下侏罗统天然气气源与成藏模式[J]. 中南大学学报(自然科学版), 2012, 43(1):258-264.
	LIU Bo, HUANG Zhilong, LUO Quansheng, et al. Accumulation mode and resource of Lower Jurassic gas reservoir of northern foothill belt,Turpan-Hami basin[J]. Journal of Central South University (Science and Technology), 2012, 43(1):258-264.
[12]	王劲松. 巴喀气藏特征与吐哈盆地致密砂岩气勘探前景[J]. 石油天然气学报, 2010, 32(6):373-375.
	WANG Jinsong. Characteristics of gas reservoirs in Baka area and exploration prospect of tight sandstone gas in Turpan-Hami basin[J]. Journal of Oil and Gas Technology, 2010, 32(6):373-375.
[13]	王震亮, 陈荷立. 台北凹陷侏罗系油气运聚成藏历史分析[J]. 石油勘探与开发, 2002, 29(3):1-4.
	WANG Zhenliang, CHEN Heli. An analysis for oil and gas migration and accumulation history in Jurassic system,Taibei sag,Turpan-Hami basin[J]. Petroleum Exploration and Development, 2002, 29(3):1-4.
[14]	李华明. 吐哈盆地中、下侏罗统煤系沉积环境与煤沼有机相[J]. 新疆石油地质, 2000, 21(4):301-303.
	LI Huaming. Sedimentary environment of coal measures strata and coal swamp organic phase of Middle-Lower Jurassic in Turpan-Hami basin[J]. Xinjiang Petroleum Geology, 2000, 21(4):301-303.
[15]	郭小波, 王海富, 黄志龙, 等. 吐哈盆地丘东洼陷致密砂岩气地球化学特征[J]. 特种油气藏, 2016, 23(4):33-36.
	GUO Xiaobo, WANG Haifu, HUANG Zhilong, et al. Geochemical analysis of tight sandstone gas in Qiudong subsag of Tuha basin[J]. Special Oil & Gas Reservoirs, 2016, 23(4):33-36.
[16]	杨镱婷, 张金川, 黄卫东, 等. 吐哈盆地致密砂岩气成藏条件与分布预测[J]. 断块油气田, 2012, 19(4):440-444.
	YANG Yiting, ZHANG Jinchuan, HUANG Weidong, et al. Accumulation conditions and distribution prediction of tight sandstone gas in Turpan-Hami basin[J]. Fault-Block Oil & Gas Field, 2012, 19(4):440-444.
[17]	王伟明, 卢双舫, 陈旋, 等. 致密砂岩气资源分级评价新方法:以吐哈盆地下侏罗统水西沟群为例[J]. 石油勘探与开发, 2015, 42(1):60-67.
	WANG Weiming, LU Shuangfang, CHEN Xuan, et al. A new method for grading and assessing the potential of tight sand gas resources:a case study of the Lower Jurassic Shuixigou group in the Turpan-Hami basin[J]. Petroleum Exploration and Development, 2015, 42(1):60-67.
[18]	张品, 苟红光, 龙飞, 等. 吐哈盆地天然气地质条件、资源潜力及勘探方向[J]. 天然气地球科学, 2018, 29(10):1 531-1 541.
	ZHANG Pin, GOU Hongguang, LONG Fei, et al. Natural gas geological conditions,resource potential and exploration direction in Turpan-Hami basin[J]. Natural Gas Geoscience, 2018, 29(10):1 531-1 541.

层位	洼陷	岩性	有机质丰度	总有机碳含量/%	生烃潜量/（mg·g^-1）	氢指数/（mg·g^-1）	干酪根类型	最大热解温度/℃	镜质体反射率/%
三工河组	胜北	暗色泥岩	较高	（0.76~3.19）/ 1.45（12）	（1.84~6.37）/ 3.35（12）	（60~329）/ 203（12）	Ⅱ₂型—Ⅲ型	（423~532）/ 446（25）	（0.64~0.83）/ 0.73（12）
三工河组	丘东	暗色泥岩	较高	（0.57~6.70）/ 1.35（16）	（0.59~10.56）/ 1.99（16）	（95~392）/ 175（16）	Ⅱ₂型—Ⅲ型	（423~532）/ 449（33）	（0.50~1.10）/ 0.82（73）
八道湾组	胜北	暗色泥岩	高	（0.88~11.96）/ 4.16（13）	（1.80~34.10）/ 8.50（13）	（38~603）/ 206（13）	Ⅱ₂型—Ⅲ型	（439~460）/ 450（27）	（0.70~0.97）/ 0.82（10）
	丘东	暗色泥岩	高	（1.20~12.95）/ 3.94（18）	（1.04~30.82）/ 6.65（18）	（122~249）/ 131（26）	Ⅱ₂型—Ⅲ型	（439~471）/ 455（26）	（0.67~1.30）/ 1.10（8）
	丘东	煤	高	（50.00~79.88）/ 65.30（3）	（102.80~221.60）/ 169.00（3）	（187~270）/ 241（3）	Ⅲ型	（440~468）/ 452（3）
