Xinjiang Petroleum Geology ›› 2020, Vol. 41 ›› Issue (4): 464-470.doi: 10.7657/XJPG20200412
• RESERVOIR ENGINEERING • Previous Articles Next Articles
Received:
2019-11-27
Revised:
2020-01-10
Online:
2020-08-01
Published:
2020-08-05
CLC Number:
WANG Dongming. Development of Ultra-Low Permeability and Strong Water Sensitivity Reservoirs in Deep Strata of Shuang229-Wa111 Blocks[J]. Xinjiang Petroleum Geology, 2020, 41(4): 464-470.
Add to citation manager EndNote|Reference Manager|ProCite|BibTeX|RefWorks
Table 1
Designed parameters for grouped fracturing in test wells in the study area"
组别 | 井名 | 生产层位 | 压裂跨度/m | 有效厚度/m | 压裂液总量/m3 | 砂量/m3 | 排量/(m3·min-1) | 砂液比/% | 初期采油强度/[t·(d·m)-1] |
---|---|---|---|---|---|---|---|---|---|
第一组 | 洼 1 井 | $S_1^3$Ⅳ | 43.2 | 10.4 | 488 | 50 | 5.0 | 26.2 | 0.8 |
洼 2 井 | $S_1^3$Ⅳ | 35.9 | 18.0 | 540 | 45 | 7.0 | 21.6 | 0.9 | |
洼 3 井 | $S_1^3$Ⅳ | 14.6 | 8.5 | 439 | 22 | 8.0 | 12.9 | 1.6 | |
第二组 | 洼 4 井 | $S_1^3$Ⅲ | 26.5 | 8.9 | 367 | 21 | 6.2 | 20.1 | 1.5 |
洼 5 井 | $S_1^3$Ⅲ | 24.3 | 15.5 | 458 | 31 | 6.5 | 21.2 | 1.3 | |
第三组 | 洼 7 井 | $S_1^3$Ⅳ | 13.4 | 11.0 | 306 | 28 | 5.0 | 26.0 | 0.9 |
洼8井 | $S_1^3$Ⅳ | 13.8 | 10.8 | 531 | 32 | 5.2 | 22.0 | 0.8 | |
洼9井 | $S_1^3$Ⅳ | 12.5 | 12.4 | 408 | 26 | 5.3 | 23.5 | 1.0 | |
洼 3井 | $S_1^3$Ⅳ | 14.6 | 8.5 | 439 | 22 | 8.0 | 12.9 | 1.6 | |
第四组 | 洼 10井 | $S_1^3$Ⅳ | 50.0 | 17.9 | 448 | 52 | 5.6 | 23.0 | 1.3 |
洼 11井 | $S_1^3$Ⅳ | 48.6 | 25.4 | 410 | 49 | 6.1 | 19.8 | 1.1 |
Table 4
Experimental parameters and measured results of gas injection flooding in long cores with different injection dip angles"
岩心 编号 | 岩心长度/cm | 孔隙体积/cm3 | 气测渗透率/mD | 孔隙度/% | 含油饱和度/% | 地层倾角/(°) | 注入速度/(cm3·min-1) | 驱油效率/% |
---|---|---|---|---|---|---|---|---|
1# | 26.823 | 17.16 | 0.24 | 13.05 | 52.9 | -15 | 0.07 | 69.2 |
2# | 23.145 | 14.55 | 0.32 | 12.83 | 59.4 | -7 | 0.07 | 68.7 |
3# | 26.682 | 18.09 | 1.03 | 13.83 | 57.6 | 0 | 0.07 | 67.2 |
[1] | 王建平, 贾红娟. 缝网压裂技术研究[J]. 石化技术, 2017,24(11):289-290. |
WANG Jianping, JIA Hongjuan. Research on the technology of fracture network fracturing[J]. Petrochemical Industry Technology, 2017,24(11):289-290. | |
[2] | 段春节, 魏旭光, 李小冬, 等. 深层高压低渗透砂岩油藏储层敏感性研究[J]. 地质科学情报, 2013,32(3):2-5. |
DUAN Chunjie, WEI Xuguang, LI Xiaodong, et al. Formation sensitivity of the deep section high pressure and low-permeability sandstone reservior[J]. Geological Science and Technology Information, 2013,32(3):2-5. | |
[3] | 张艳玉, 崔红霞, 韩会军, 等. 低渗透油藏天然气驱提高采收率数值模拟研究[J]. 油气地质与采收率, 2005,12(4):62-63. |
ZHANG Yanyu, CUI Hongxia, HAN Huijun, et al. A study on numerical simulation of enhancing oil recovery using natural gas flooding in the low-permerbility oil reservoirs[J]. Petroleum Geology and Recovery Efficiency, 2005,12(4):62-63. | |
[4] | 史小平. 天然气驱在低渗油藏中适应性研究[J]. 内蒙古石油化工, 2014,5(13):143-144. |
SHI Xiaoping. Natural gas flooding in low permeability reservoir adaptability research[J]. Inner Mongolia Petrochemical Industry, 2014,5(13):143-144. | |
[5] | 张宁. 胜利油田储层敏感性分析[J]. 石化技术, 2017,24(5):129-130. |
ZHANG Ning. Analysis of reservoir sensitivity in Shengli oilfield[J]. Petrochemical Industry Technology, 2017,24(5):129-130. | |
[6] | 盛聪, 吕媛媛, 王丽莉, 等. 厚层块状砂岩油藏天然气驱提高采收率方案研究[J]. 油气藏评价与开发, 2018,8(1):24-28. |
SHENG Cong, LÜ Yuanyuan, WANG Lili, et al. Design of block sandstone reservoirs in natural gas drive[J]. Reservoir Evaluation and Development, 2018,8(1):24-28. | |
[7] | 郭永伟, 杨胜来, 李良川, 等. 长岩心注天然气驱油物理模拟实验[J]. 断块油气田, 2009,16(6):76-78. |
GUO Yongwei, YANG Shenglai, LI Liangchuan, et al. Experiment on physical modeling of displacement oil with natural gas for long core[J]. Fault-Block Oil & Gas Field, 2009,16(6):76-78. | |
[8] | 王东琪, 殷代印. 特低渗透油藏水驱开发效果评价[J]. 特种油气藏, 2017,24(6):107-110. |
WANG Dongqi, YIN Daiyin. Waterflooding performance evaluation in ultra-low permeability oil reservoir[J]. Special Oil and Gas Reservoirs, 2017,24(6):107-110. | |
[9] | 刘英. 水驱与天然气驱结合提高厚油层油井产能实践[J]. 钻采工艺, 2012,35(2):48-50. |
LIU Ying. Research on increasing oil well productivity of thick reservoir by water flooding and natural gas injection[J]. Dring & Production Technology, 2012,24(2):48-50. | |
[10] | 李传亮, 朱苏阳, 王凤兰, 等. 关于储集层敏感性评价的若干问题[J]. 新疆石油地质, 2017,38(4):488-491. |
LI Chuanliang, ZHU Suyang, WANG Fenglan, et al. Some topics about reservoir sensitivity evaluation[J]. Xinjiang Petroleum Geology, 2017,38(4):488-491. | |
[11] | 李传亮, 涂兴万. 储层岩石的2 种应力敏感机制:应力敏感有利于驱油[J]. 岩性油气藏, 2008,20(1):111-113. |
LI Chuanliang, TU Xingwan. Two types of stress sensitivity mecha-nisms for reservoir rocks:being favorable for oil recovery[J]. Lithologic Reservoirs, 2008,20(1):111-113. | |
[12] | 车星祥, 卢渊, 周珺, 等. 迪北地区致密砂岩储集层损害实验研究[J]. 新疆石油地质, 2015,36(5):579-582. |
CHE Xingxiang, LU Yuan, ZHOU Jun, et al. Tight sandstone gas reservoir damages in Dibei area of Tarim basin:experimental study[J]. Xinjiang Petroleum Geology, 2015,36(5):579-582. | |
[13] | 赵燕芹, 李巧梅, 陈德斌, 等. 低渗油藏天然气驱适应性研究[J]. 断块油气藏, 2009,16(2):77-79. |
ZHAO Yanqin, LI Qiaomei, CHEN Debin, et al. Research on the adaptability of natural gas drive for low-permeability reservoir[J]. Fault-Block Oil & Gas Field, 2009,16(2):77-79. | |
[14] | 陈建琪, 裴连君. 涠四段油藏注天然气非混相驱油层非均质模拟[J]. 吐哈油气, 2007,12(1):48-51. |
CHEN Jianqi, PEI Lianjun. Immiscible displacement reservoir heterogeneity simulations by natural gas injection in Weisi reservoir[J]. Tuha Oil & Gas, 2007,12(1):48-51. | |
[15] | 王高峰, 宋新民, 马德胜, 等. 油藏气驱开发规律研究[J]. 科学技术与工程, 2013,13(2):460-463. |
WANG Gaofeng, SONG Xinmin, MA Desheng, et al. Regularity findings of gas flooding performance[J]. Science Technology and Engineering, 2007,13(2):460-463. | |
[16] | 郑家朋. 冀东油田深层中低渗透油藏气驱适应性[J]. 中国石油大学学报 (自然科学版 ), 2009,33(5):84-88. |
ZHENG Jiapeng. Adaptability of gas flooding for deep reservoir with low to medium permeability in Jidong oilfield[J]. Journal of China University of Petroleum(Edition of Natural Sciences), 2009,33(5):84-88. | |
[17] | 王高峰, 胡永乐, 宋新民, 等. 低渗透油藏气驱产量预测新方法[J]. 科学技术与工程, 2013,13(30):8 905-8 911. |
WANG Gaofeng, HU Yongle, SONG Xinmin, et al. New theory of oil production prediction in gas flooding tight reservoirs[J]. Science Technology and Engineering, 2013,13(30):8 905-8 911. | |
[18] | 赵云海, 王健, 吕柏林, 等. 高温高压油藏纳米颗粒提高CO2泡沫驱油效果实验[J]. 新疆石油地质, 2019,40(6):708-713. |
ZHAO Yunhai, WANG Jian, LYU Bolin, et al. Experimental study on nano-particle/CO2 foam flooding effect in high-temperature high-pressure reservoirs[J]. Xinjiang Petroleum Geology, 2019,40(6):708-713. | |
[19] | 赵继勇, 熊维亮, 范伟, 等. 特低渗透油藏提高采收率驱油体系筛选及应用[J]. 新疆石油地质, 2019,40(6):720-724. |
ZHAO Jiyong, XIONG Weiliang, FAN Wei, et al. Selection and application of oil displacement system for EOR in extra-low permeability reservoirs[J]. Xinjiang Petroleum Geology, 2019,40(6):720-724. |
