Gas Testing Flowback Rules of Shallow Shale Gas Horizontal Wells in TY Block of Zhaotong

doi:10.7657/XJPG20200411

Abstract

Abstract:

Aiming at the shallow burial, low formation energy and high flowback rate of the shale gas reservoirs in Taiyang block of Zhaotong National Shale Gas Demonstration Area in the southern Sichuan basin, it is of great significance to accurately master the laws of gas testing and flowback of horizontal wells in shallow shale gas reservoirs and to formulate a specific test system for improving single well recovery. For this reason, drawing lessons from the gas testing law of the horizontal wells in the middle and deep shale gas strata in the adjacent block, and combining with the knowledge and practical experience of the water drainage and gas production law of the tested wells in the study area, the paper divides the gas testing process in the horizontal wells in the study area into 6 stages, summarizes the laws of gas test and flowback and formulates the corresponding production system on the basis of gas-liquid two-phase percolation theory and stress sensitivity analysis methods. The results show that the optimum well soak time, choke diameter and choke adjusting timing can be determined by taking the key parameters including daily gas production, daily water production and wellhead pressure as evaluation criteria, which can greatly reduce reservoir damages caused by stress sensitivity. Then gas testing productivity can be obtained and well recovery can be improved as well. Based on which, 2 sets of standard charts have been established for gas testing and flowback in horizontal wells in shallow shale gas reservoirs in the study area, and the actual application in field production has proved the good effect of the charts.

Key words: Zhaotong, Taiyang block, shallow shale gas, horizontal well, well soak time, gas testing, flowback rule

CLC Number:

TE357

HUANG Xiaoqing, HAN Yongshen, YANG Qing, ZHOU Yun, YUAN Xiaojun, LIU Ye. Gas Testing Flowback Rules of Shallow Shale Gas Horizontal Wells in TY Block of Zhaotong[J]. Xinjiang Petroleum Geology, 2020, 41(4): 457-463.

Figures/Tables 9

Fig. 1.

Fig. 2.

Table 1

Table 2

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6

Fig. 7

References 22

[1]	范宇, 周小金, 曾波, 等. 密切割分段压裂工艺在深层页岩气Zi2井的应用[J]. 新疆石油地质, 2019,40(2):223-227.
	FAN Yu, ZHOU Xiaojin, ZENG Bo, et al. Application of intensive staged fracturing technology in deep shale gas Well Zi-2[J]. Xinjiang Petroleum Geology, 2019,40(2):223-227.
[2]	马莉, 张驰, 刘敦卿, 等. 涪陵页岩气田压裂后闷井工艺适应性初探[J]. 特种油气藏, 2019,26(1):147-151.
	MA Li, ZHANG Chi, LIU Dunqing, et al. Preliminary study on the well-soaking adaptability after fracturing in Fuling shale gasfield[J]. Special Oil & Gas Reserviors, 2019,26(1):147-151.
[3]	张寅, 李世恩. 涪陵页岩气井焖井时间与产能关系分析[J]. 江汉石油职工大学学报, 2017,30(5):49-51.
	ZHANG Yin, LI Shi’en. Relation analysis of shut-in time and capacity of Fuling shale gas wells[J]. Journal of Jianghan Petroleum University of Staff and Workers, 2017,30(5):49-51.
[4]	韩慧芬, 王良, 贺秋云, 等. 页岩气井返排规律及控制参数优化[J]. 石油钻采工艺, 2018,40(2):253-260.
	HAN Huifen, WANG Liang, HE Qiuyun, et al. Flowback laws and control parameter optimization of shale gas wells[J]. Oil Drilling & Production Technology, 2018,40(2):253-260.
[5]	韩慧芬, 贺秋云, 王良. 长宁区块页岩气井排液技术现状及攻关方向探讨[J]. 钻采工艺, 2017,40(4):69-71.
	HAN Huifen, HE Qiuyun, WANG Liang. The current situation of flowback technology and its further development research for shale-gas wells in Changning block[J]. Drilling & Production Technology, 2017,40(4):69-71.
[6]	翟光明, 宋建国, 靳久强, 等. 板块构造演化与含油气盆地形成和评价[M]. 北京: 石油工业出版社, 2002: 260-276.
	ZHAI Guangming, SONG Jianguo, JIN Jiuqiang, et al. Plate tectonic evolution and formation and evaluation of petroleum bearing basins[M]. Beijing: Petroleum Industry Press, 2002: 260-276.
[7]	张春明, 张维生, 郭英海. 川东南—黔北地区龙马溪组沉积环境及对烃源岩的影响[J]. 地学前缘, 2012,19(1):136-145.
	ZHANG Chunming, ZHANG Weisheng, GUO Yinghai. Sedimentary environment and its effect on hydrocarbon source rocks of Longmaxi formation in southeast Sichuan and northern Guizhou[J]. Earth Science Frontiers, 2012,19(1):136-145.
[8]	伍坤宇, 张廷山, 杨洋, 等. 昭通示范区黄金坝气田五峰—龙马溪组页岩气储层地质特征[J]. 中国地质, 2016,43(1):275-287.
	WU Kunyu, ZHANG Tingshan, YANG Yang, et al. Geological characteristics of Wufeng-Longmaxi shale-gas reservoir in the Huangjinba field,Zhaotong National Shale Gas Demonstration Area[J]. Geology in China, 2016,43(1):275-287.
[9]	田兴旺, 胡国艺, 苏桂萍, 等. 川南威远地区W201井古生界海相页岩矿物特征[J]. 新疆石油地质, 2018,39(4):409-415.
	TIAN Xingwang, HU Guoyi, SU Guiping, et al. Mineralogical characteristics of Paleozoic marine shales in Well W201 of Weiyuan area,southern Sichuan basin[J]. Xinjiang Petroleum Geology, 2018,39(4):409-415.
[10]	张涛, 李相方, 杨立峰, 等. 关井时机对页岩气井返排率和产能的影响[J]. 天然气工业, 2017,37(8):48-60.
	ZHANG Tao, LI Xiangfang, YANG Lifeng, et al. Effects of shut-in timing on flowback rate and productivity of shale gas wells[J]. Natural Gas Industry, 2017,37(8):48-60.
[11]	吴建发, 郭建春, 赵金洲. 裂缝性地层气水两相渗流机理研究[J]. 天然气工业, 2004,24(11):85-87.
	WU Jianfa, GUO Jianchun, ZHAO Jinzhou. Study on gas/water two-phase percolation mechanism for fractured formations[J]. Natural Gas Industry, 2004,24(11):85-87.
[12]	BENNION D B, THOMAS F B, BIETZ R F, et al. Water and hydrocarbon phase trapping in porous media-diagnosis,prevention and treatment[J]. Journal of Canadian Petroleum Technology, 1996,35(10):29-36.
[13]	BLASINGAME T A. The characteristic flow behavior of low-permeability reservoir systems[R]. Colorado,USA：SPE 114168, 2008.
[14]	SHAOUL J R, ZELM L F V, PATER C J D. Damage mechanisms in unconventional gas well stimulation:a new look at an old problem[J]. SPE Production & Operations, 2011,26(4):388-400.
[15]	ELGMATI M, ZHANG Hao, BAI Baojun, et al. Submicron-pore characterization of shale gas plays[R]. Texas,USA:SPE 144050, 2011.
[16]	DEHGHANPOUR H, LAN Q, SAEED Y, et al. Spontaneous imbibition of brine and oil in gas shales:effect of water adsorption and resulting microfractures[J]. Energy & Fuels, 2013,27(6):3 039-3 049.
[17]	王家禄, 刘玉章, 陈茂谦, 等. 低渗透油藏裂缝动态渗吸机理实验研究[J]. 石油勘探与开发, 2009,36(1):86-90.
	WANG Jialu, LIU Yuzhang, CHEN Maoqian, et al. Experimental study on dynamic imbibition mechanism of low permeability reservoirs[J]. Petroleum Exploration and Development, 2009,36(1):86-90.
[18]	钟建华, 刘圣鑫, 马寅生, 等. 页岩宏观破裂模式与微观破裂机理[J]. 石油勘探与开发, 2015,42(2):242-250.
	ZHONG Jianhua, LIU Shengxin, MA Yinsheng, et al. Macro-fracture mode and micro-fracture mechanism of shale[J]. Petroleum Exploration and Development, 2015,42(2):242-250.
[19]	梁利喜, 熊健, 刘向君. 水化作用和润湿性对页岩地层裂纹扩展的影响[J]. 石油实验地质, 2014,36(6):780-786. doi: 10.11781/sysydz201406780
	LIANG Lixi, XIONG Jian, LIU Xiangjun. Effects of hydration swelling and wettability on propagation mechanism of shale formation crack[J]. Petroleum Geology & Experiment, 2014,36(6):780-786.
[20]	张晨晨, 董大忠, 王玉满, 等. 页岩储集层脆性研究进展[J]. 新疆石油地质, 2017,38(1):111-118.
	ZHANG Chenchen, DONG Dazhong, WANG Yuman, et al. Research progress on brittleness of shale reservoirs[J]. Xinjiang Petroleum Geology, 2017,38(1):111-118.
[21]	钱斌, 朱炬辉, 杨海, 等. 页岩储集层岩心水化作用实验[J]. 石油勘探与开发, 2017,44(4):615-621.
	QIAN Bin, ZHU Juhui, YANG Hai, et al. Experiments on shale reservoirs plugs hydration[J]. Petroleum Exploration and Development, 2017,44(4):615-621.
[22]	尹国君, 许庆双, 范传雷. 压裂液返排试验及返排制度优化研究[J]. 当代化工研究, 2016,16(10):106-107.
	YIN Guojun, XU Qingshuang, FAN Chuanlei. Study of fracturing and flowback experiment and flowback system optimization[J]. Mdoern Chemical Research, 2016,16(10):106-107.

井区	目的层埋深/m	最小水平主应力/MPa	最大水平主应力/MPa	上覆地层应力/MPa	地层压力系数
HJB-108井区	2 509	56.5	71.0	61.0	2.00
TY-118井区	2 246	44.7	65.4	57.3	1.61
TY-102井区	760	16.0	26.2	18.8	1.43
TY-1井区	960	20.2	24.2	24.0	1.22

储集层分类	总有机碳含量/%	有效孔隙度/%	脆性矿物含量/%	含气量（/m³·t^-1）
Ⅰ类储集层	>3	>5	>55	>3
Ⅱ类储集层	2~3	3~5	45~55	2~3
Ⅲ类储集层	1~2	2~3	30~45	1~2
非储集层	<1	<2	<30	<1
