Sedimentary Facies and Controlling Factors of Shengjinkou Formation in Chepaizi Swell

doi:10.7657/XJPG20210102

Abstract

Abstract:

In Chepaizi swell of the Junggar basin, the sedimentary paleo-environment of the Lower Cretaceous Shengjinkou formation was restored according to the analysis of trace elements; the sedimentary characteristics of fan delta and braided river delta in the formation were compared and analyzed using drilling, logging, seismic and laboratory data; and the controlling factors on the distribution of the fan delta and braided river delta were determined after restoring the paleogeomorphology of the Shengjinkou formation. The result shows: (1) when the Cretaceous Shengjinkou formation deposited, Chepaizi swell was in oxygen-rich freshwater to brackish water environment under dry and hot climate, and the paleo-water temperature ranged from 27.3 ℃ to 29.2 ℃; (2) there were two sedimentary systems such as fan delta-lake and braided river delta-lake in the Shengjinkou formation; and several fan delta lobes were developed in the southwest of the study area, and many braided river delta lobes in the eastern regions. Transport channels, distance from sources and terrain slope are factors controlling the development of two types of deltas in the study area.

Key words: Junggar basin, Chepaizi swell, Shengjinkou formation, sedimentary facies, fan delta, braided river delta, transport channel, ter- rain slope

CLC Number:

TE121.3

ZHU Yan, LI Yanran, YUE Xinxin, ZHANG Hui, LI Hengquan, ZHANG Chi, ZHANG Xinchao. Sedimentary Facies and Controlling Factors of Shengjinkou Formation in Chepaizi Swell[J]. Xinjiang Petroleum Geology, 2021, 42(1): 10-11.

Figures/Tables 14

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Fig. 7.

Fig. 8.

Fig. 9.

Fig. 10.

Fig. 11.

References 22

[1]	赵东娜, 朱筱敏, 董艳蕾 , 等. 准噶尔盆地车排子地区下白垩统层序地层格架及主控因素分析[J]. 沉积学报, 2013,31(6):1 070-1 080.
	ZHAO Dongna, ZHU Xiaomin, DONG Yanlei , et al. Sequence stratigraphic framework of Lower Cretaceous and its main controlling factors in Chepaizi area,Junggar basin[J]. Acta Sedimentologica Sinica, 2013,31(6):1 070-1 080.
[2]	董艳蕾, 朱筱敏, 赵东娜 , 等. 准噶尔盆地车排子地区下白垩统沉积体系分布及油气成藏模式[J]. 现代地质, 2015,29(1):71-79.
	DONG Yanlei, ZHU Xiaomin, ZHAO Dongna , et al. Sedimentary system and reservoir models of the Lower Cretaceous in Chepaizi area,Junggar basin[J]. Geoscience, 2015,29(1):71-79.
[3]	张辉, 岳欣欣, 朱颜 , 等. 准噶尔盆地春光油田油藏特征及成藏模式[J]. 新疆石油地质, 2020,41(4):379-387.
	ZHANG Hui, YUE Xinxin, ZHU Yan , et al. Reservoir characteristics and hydrocarbon accumulation model in Chunguang oilfield,Junggar basin[J]. Xinjiang Petroleum Geology, 2020,41(4):379-387.
[4]	王千军 . 准噶尔盆地车排子地区白垩系沉积特征及演化[J]. 东北石油大学学报, 2015,39(2):51-58.
	WANG Qianjun . Deposition characteristics and evolution of the Cretaceous system of Chepaizi area in Junggar basin[J]. Journal of Northeast Petroleum University, 2015,39(2):51-58.
[5]	匡立春, 雷德文, 唐勇 , 等. 准噶尔盆侏罗—白垩系沉积特征和岩性地层油气藏[M]. 北京: 石油工业出版社, 2013: 16-18.
	KUANG Lichun, LEI Dewen, TANG Yong , et al. The sedimentary characteristics and lithostratigraphic reservoir of Jurassic-Cretaceous in Junggar basin[M]. Beijing: Petroleum Industry Press, 2013: 16-18.
[6]	何登发, 陈新发, 况军 , 等. 准噶尔盆地车排子-莫索湾古隆起的形成演化与成因机制[J]. 地学前缘, 2008,15(4):42-55.
	HE Dengfa, CHEN Xinfa, KUANG Jun , et al. Development and genetic mechanism of Chepaizi-Mosuowan uplift in Junggar basin[J]. Earth Science Frontiers, 2008,15(4):42-55.
[7]	隋风贵 . 准噶尔盆地西北缘构造演化及其与油气成藏的关系[J]. 地质学报, 2015,89(4):779-793.
	SUI Fenggui . Tectonic evolution and its relationship with hydrocarbon accumulation in the northwest margin of Junggar basin[J]. Acta Geologica Sinica, 2015,89(4):779-793.
[8]	洪太元, 王离迟, 张福顺 , 等. 准噶尔盆地西缘车排子地区地层沉积特征[J]. 中国西部油气地质, 2006,2(2):164-167.
	HONG Taiyuan, WANG Lichi, ZHANG Fushun , et al. Study on the stratigraphic and depositional features in Chepaizi uplift of western Junggar basin[J]. West China Petroleum Geosciences, 2006,2(2):164-167.
[9]	樊晓伊, 薛国勤, 刘斌 , 等. 准噶尔盆地春光油田稀井区曲流河储集层构型定量表征[J]. 新疆石油地质, 2020,41(2):147-157.
	FAN Xiaoyi, XUE Guoqin, LIU bin, et al. Quantitative characterization of reservoir architecture of meandering-river deposits in sparse well blocks:a case study of Chunguang oilfield,Junggar basin[J]. Xinjiang Petroleum Geology, 2020,41(2):147-157.
[10]	中国国家标准化管理委员会. 硅酸盐岩石化学分析方法第30部分: 44个元素量测定:GB/T 14506.30—2010[S]. 北京:中国标准出版社, 2011.
	Standardization Administration of the People’s Republic of China. Methods for chemical analysis of silicate rocks— Part 30: determination of 44 elements:GB/T 14506.30—2010[S]. Beijing:Standards Press of China, 2011.
[11]	刘刚, 周东升 . 微量元素分析在判别沉积环境中的应用:以江汉盆地潜江组为例[J]. 石油实验地质, 2007,29(3):307-310. doi: 10.11781/sysydz200703307
	LIU Gang, ZHOU Dongsheng . Application of microelements analysis in identifying sedimentary environment:taking Qianjiang formation in the Jianghan basin as an example[J]. Petroleum Geology and Experiment, 2007,29(3):307-310.
[12]	袁海军, 赵兵 . 川西雅安—名山地区白垩系泥岩的地球化学特征及古气候探讨[J]. 沉积与特提斯地质, 2012,32(1):78-83.
	YUAN Haijun, ZHAO Bing . Geochemical and palaeoclimatic approaches to the Cretaceous mudstones in the Ya’an-Mingshan zone,western Sichuan[J]. Sedimentary Geology and Tethyan Geology, 2012,32(1):78-83.
[13]	范玉海, 屈红军, 王辉 , 等. 微量元素分析在判别沉积介质环境中的应用:以鄂尔多斯盆地西部中区晚三叠世为例[J]. 中国地质, 2012,39(2):382-389.
	FAN Yuhai, QU Hongjun, WANG Hui , et al. The application of trace elements analysis to identifying sedimentary media environment:a case study of Late Triassic strata in the middle part of western Ordos basin[J]. Geology in China, 2012,39(2):382-389.
[14]	邓宏文, 钱凯 . 沉积地球化学与环境分析[M]. 兰州: 甘肃科学技术出版社, 1993: 95-104.
	DENG Hongwen, QIAN Kai. Sedimentary geochemistry and environment analysis[M]. Lanzhou: Gansu Science and Technology Press, 1993: 95-104.
[15]	HATCH J R, LEVENTHAL J S . Relationship between inferred redox potential of the depositional environment and geochemistry of the Upper Pensylvanian (Missourian) Stark shale member of the Dennis limestone,Wabaunsee country,Kansas USA[J]. Chemical Geology, 1992,99(1/2/3):65-82.
[16]	RIMMER S M . Geochemical paleoredox indicators in Devonian Mississippian black shales,Central Appalachian basin (USA)[J]. Chemical Geology, 2003,206(3/4):373-391. doi: 10.1016/j.chemgeo.2003.12.029
[17]	熊国庆, 王剑, 胡仁发 . 贵州梵净山地区震旦系微量元素特征及沉积环境[J]. 地球学报, 2008,29(1):51-60.
	XIONG Guoqing, WANG Jian, HU Renfa . Trace element characteristics and sedimentary environment of the Sinian system of the Fanjingshan area in Guizhou province[J]. Acta Geosicentica Sinica, 2008,29(1):51-60.
[18]	JONE S B, MANNING D A C. Comparison of geochemical indices used for the interpretation of palaeoredox conditions in ancient mudstones[J]. Chemical Geology, 1994,111(1):111-129. doi: 10.1016/0009-2541(94)90085-X
[19]	刘磊, 钟怡江, 陈洪德 , 等. 中国东部箕状断陷湖盆扇三角洲与辫状河三角洲对比研究[J]. 沉积学报, 2015,33(6):1 170-1 181.
	LIU Lei, ZHONG Yijiang, CHEN Hongde , et al. Contrastive research of fan deltas and braided river deltas in half-garben rift lake basin in east China[J]. Acta Sedimentologica Sinica, 2015,33(6):1 170-1 181.
[20]	朱筱敏, 刘媛, 方庆 , 等. 大型坳陷湖盆浅水三角洲形成条件和沉积模式:以松辽盆地三肇凹陷扶余油层为例[J]. 地学前缘, 2012,19(1):89-99.
	ZHU Xiaomin, LIU Yuan, FANG Qing , et al. Formation and sedimentary model of shallow delta in large-scale lake:example from Cretaceous Quantou formation in Sanzhao sag,Songliao basin[J]. Earth Science Frontiers, 2012,19(1):89-99.
[21]	杨桥, 漆家福 . 碎屑岩层的分层去压实校正方法[J]. 石油实验地质, 2003,25(2):206-210. doi: 10.11781/sysydz200302206
	YANG Qiao, QI Jiafu . Method of delaminated decompaction correction[J]. Petroleum Geology & Experiment, 2003,25(2):206-210.
[22]	王峰, 刘玄春, 邓秀芹 , 等. 鄂尔多斯盆地纸坊组微量元素地球化学特征及沉积环境指示意义[J]. 沉积学报, 2017,35(6):1 265-1 273.
	WANG Feng, LIU Xuanchun, DENG Xiuqin , et al. Geochemical characteristics and environmental implications of trace elements of Zhifang formation in Ordos basin[J]. Acta Sedimentologica Sinica, 2017,35(6):1 265-1 273.
