Hydrocarbon Accumulation Mechanism of Total Petroleum System in Permian Fengcheng Formation，Mahu Sag

doi:10.7657/XJPG20220604

Abstract

Abstract:

The exploration practice in the Fengcheng formation in the Mahu sag，western Junggar basin，has revealed the orderly coexistence of conventional and unconventional hydrocarbons. By finely dissecting the characteristics of the total petroleum system in the Fengcheng formation in the Mahu sag，and combining with the macro-and micro-analysis and production data of the reservoirs，the hydrocarbon accumulation mechanism of the total petroleum system was analyzed. The results show that conventional oil，tight oil and shale oil accumulate in an orderly pattern in the total petroleum system，which essentially complies with the hydrocarbon accumulation pattern of “source-reservoir coupling” and “dynamic sealing” of oil and gas. In the early diagenesis stage，the present tight reservoirs and shale reservoirs were conventional reservoirs with medium-large pore throats，where hydrocarbons accumulated because of buoyancy. In the middle-later diagenesis stage，the medium-large pore throats gradually evolved to micro-to nano-pore throats，the buoyancy was weakened，and the capillary force was strengthened. The hydrocarbon in the reservoir adjacent to or integrated with the source rocks underwent primary or micro migration continuously until the source-reservoir pressure difference resulted from hydrocarbon generation and expulsion and the capillary force originated from micro-to nano-pore throats reached a dynamic equilibrium，forming a “self-sealing” continuous unconventional oil and gas accumulation. The capillary force in the present conventional reservoirs is far less than the buoyancy，so “external sealing”is needed for hydrocarbon accumulation in traps. Generally，the hydrocarbon accumulation in the Fengcheng formation is represented by the space-time evolution of the pore throat structure in the reservoir and the dynamic coupling of source rock and reservoir on hydrocarbon generation-expulsion-migration-accumulation.

Key words: Junggar basin, Fengcheng formation, conventional hydrocarbon, unconventional hydrocarbon, total petroleum system, dynamic “sealing” effect, hydrocarbon accumulation mechanism, source-reservoir coupling

CLC Number:

TE122

HE Wenjun, SONG Yong, TANG Shiqi, YOU Xincai, BAI Yu, ZHAO Yi. Hydrocarbon Accumulation Mechanism of Total Petroleum System in Permian Fengcheng Formation，Mahu Sag[J]. Xinjiang Petroleum Geology, 2022, 43(6): 663-673.

Figures/Tables 12

Fig. 1.

Fig. 2.

Table 1.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Fig. 7.

Table 2.

Fig. 8.

Fig. 9.

Fig. 10.

References 24

[1]	MAGOON L B, WALLACE G D. The petroleum system:from source to trap[C]. AAPG Memoir,1994.
[2]	唐勇, 曹剑, 何文军, 等. 从玛湖大油区发现看全油气系统地质理论发展趋势[J]. 新疆石油地质, 2021, 42(1):1-9.
	TANG Yong, CAO Jian, HE Wenjun, et al. Development tendency of geological theory of total petroleum system:insights from the discovery of Mahu large oil province[J]. Xinjiang Petroleum Geology, 2021, 42(1):1-9.
[3]	支东明, 宋永, 何文军, 等. 准噶尔盆地中—下二叠统页岩油地质特征、资源潜力及勘探方向[J]. 新疆石油地质, 2019, 40(4):389-401.
	ZHI Dongming, SONG Yong, HE Wenjun, et al. Geological characteristics,resource potential and exploration direction of shale oil in Middle-Lower Permian,Junggar basin[J]. Xinjiang Petroleum Geology, 2019, 40(4):389-401.
[4]	支东明, 唐勇, 何文军, 等. 准噶尔盆地玛湖凹陷风城组常规-非常规油气有序共生与全油气系统成藏模式[J]. 石油勘探与开发, 2021, 48(1):38-51.
	ZHI Dongming, TANG Yong, HE Wenjun, et al. Orderly coexistence and accumulation models of conventional and unconventional hydrocarbons in Lower Permian Fengcheng formation,Mahu sag,Junggar basin[J]. Petroleum Exploration and Development, 2021, 48(1):38-51.
[5]	MAGOON L B, SCHMOKER J W. The total petroleum system:the natural fluid network that constrains the assessment unit[J]. U. S. Geological Survey, 2000,31.
[6]	WANDREY C J, LAW B E, SHAH H A. Patala-Nammal composite total petroleum system,Kohat-Potwar geologic province,Pakistan[M]. U. S. Geological Survey Bulletin, 2004,2208-b.
[7]	贾承造. 论非常规油气对经典石油天然气地质学理论的突破及意义[J]. 石油勘探与开发, 2017, 44(1):1-11.
	JIA Chengzao. Breakthrough and significance of unconventional oil and gas to classical petroleum geological theory[J]. Petroleum Exploration and Development, 2017, 44(1):1-11. doi: 10.1016/S1876-3804(17)30002-2
[8]	贾承造, 邹才能, 杨智, 等. 陆相油气地质理论在中国中西部盆地的重大进展[J]. 石油勘探与开发, 2018, 45(4):546-560.
	JIA Chengzao, ZOU Caineng, YANG Zhi, et al. Significant progress of continental petroleum geology theory in basins of central and western China[J]. Petroleum Exploration and Development, 2018, 45(4):546-560.
[9]	曹剑, 雷德文, 李玉文, 等. 古老碱湖优质烃源岩:准噶尔盆地下二叠统风城组[J]. 石油学报, 2015, 36(7):781-790. doi: 10.7623/syxb201507002
	CAO Jian, LEI Dewen, LI Yuwen, et al. Ancient high-quality alkaline lacustrine source rocks discovered in the Lower Permian Fengcheng formation,Junggar basin[J]. Acta Petrolei Sinica, 2015, 36(7):781-790. doi: 10.7623/syxb201507002
[10]	何文军, 钱永新, 赵毅, 等. 玛湖凹陷风城组全油气系统勘探启示[J]. 新疆石油地质, 2021, 42(6):641-655.
	HE Wenjun, QIAN Yongxin, ZHAO Yi, et al. Exploration implications of total petroleum system in Fengcheng formation,Mahu sag,Junggar basin[J]. Xinjiang Petroleum Geology, 2021, 42(6):641-655.
[11]	单祥, 郭华军, 何文军, 等. 准噶尔盆地玛南斜坡区风城组致密油储层特征及控制因素[C]. 第十六届全国古地理学及沉积学学术会议论文摘要集. 2021:216.
	SHAN Xiang, GUO Huajun, HE Wenjun, et al. Characteristics and controlling factors of tight oil reservoirs in Fengcheng formation in southern Mahu slope of Junggar basin[C]. Abstracts of the 16th National Academic Conference on Paleogeography and Sedimentology. 2021:216.
[12]	邹才能, 朱如凯, 吴松涛, 等. 常规与非常规油气聚集类型、特征、机理及展望:以中国致密油和致密气为例[J]. 石油学报, 2012, 33(2):173-187. doi: 10.7623/syxb201202001
	ZOU Caineng, ZHU Rukai, WU Songtao, et al. Types,characteristics,genesis and prospects of conventional and unconventional hydrocarbon accumulations:taking tight oil and gas in China as an instance[J]. Acta Petrolei Sinica, 2012, 33(2):173-187.
[13]	贾承造, 庞雄奇, 宋岩. 论非常规油气成藏机理:油气自封闭作用与分子间作用力[J]. 石油勘探与开发, 2021, 48(3):437-452.
	JIA Chengzao, PANG Xiongqi, SONG Yan. The mechanism of unconventional hydrocarbon formation:hydrocarbon self-containment and intermolecular forces[J]. Petroleum Exploration and Development, 2021, 48(3):437-452.
[14]	陈发景, 汪新文, 汪新伟. 准噶尔盆地的原型和构造演化[J]. 地学前缘, 2005, 12(3):77-89.
	CHEN Fajing, WANG Xinwen, WANG Xinwei. Prototype and tectonic evolution of the Junggar basin,northwestern China[J]. Earth Science Frontiers, 2005, 12(3):77-89.
[15]	杨海波, 陈磊, 孔玉华. 准噶尔盆地构造单元划分新方案[J]. 新疆石油地质, 2004, 25(6):686-688.
	YANG Haibo, CHEN Lei, KONG Yuhua. A novel classification of structural units in Junggar basin[J]. Xinjiang Petroleum Geology, 2004, 25(6):686-688.
[16]	雷德文, 陈刚强, 刘海磊, 等. 准噶尔盆地玛湖凹陷大油(气)区形成条件与勘探方向研究[J]. 地质学报, 2017, 91(7):1604-1 619.
	LEI Dewen, CHEN Gangqiang, LIU Hailei, et al. Study on the forming conditions and exploration fields of the Mahu giant oil(gas) province,Junggar basin[J]. Acta Geologica Sinica, 2020, 91(7):1604-1 619.
[17]	王小军, 王婷婷, 曹剑. 玛湖凹陷风城组碱湖烃源岩基本特征及其高效生烃[J]. 新疆石油地质, 2018, 39(1):9-15.
	WANG Xiaojun, WANG Tingting, CAO Jian. Basic characteristics and highly efficient hydrocarbon generation of alkaline-lacustrine source rocks in Fengcheng formation of Mahu sag[J]. Xinjiang Petroleum Geology, 2018, 39(1):9-15.
[18]	中国国家标准化管理委员会. 页岩油地质评价方法:GB/T 38718-2020[S]. 北京: 中国标准出版社, 2020.
	Standardization Administration of the People’s Republic of China. Geological evaluating methods for shale oil:GB/T 38718-2020[S]. Beijing: Standards Press of China, 2020.
[19]	支东明, 唐勇, 杨智峰, 等. 准噶尔盆地吉木萨尔凹陷陆相页岩油地质特征与聚集机理[J]. 石油与天然气地质, 2019, 40(3):524-534.
	ZHI Dongming, TANG Yong, YANG Zhifeng, et al. Geological characteristics and accumulation mechanism of continental shale oil in Jimusaer sag,Junggar basin[J]. Oil & Gas Geology, 2019, 40(3):524-534.
[20]	郭旭光, 何文军, 杨森, 等. 准噶尔盆地页岩油“甜点区”评价与关键技术应用:以吉木萨尔凹陷二叠系芦草沟组为例[J]. 天然气地球科学, 2019, 30(8):1168-1 179.
	GUO Xuguang, HE Wenjun, YANG Sen, et al. Evolution and application of key technologies of “sweet area” of shale oil in Junggar basin[J]. Natural Gas Geoscience, 2019, 30(8):1168-1 179.
[21]	TANG, Yong, CAO Jian, HE Wenjun, et al. Discovery of shale oil in alkaline lacustrine basins:the Late Paleozoic Fengcheng formation,Mahu sag,Junggar basin,China[J]. Petroleum Science, 2021, 18:1281-1 293.
[22]	郑民, 李建忠, 王文广, 等. 致密储层石油充注成藏过程分析:以准噶尔盆地吉木萨尔凹陷二叠系芦草沟组为例[J]. 地球科学, 2018, 43(10):3719-3 732.
	ZHENG Min, LI Jianzhong, WANG Wenguang, et al. Analysis of oil charging and accumulation processes in tight reservoir beds:a case study of Lucaogu formation in Jimsar sag of Junggar basin,NW China[J]. Earth Science, 2018, 43(10):3719-3 732.
[23]	潘晓添, 郑荣才, 文华国, 等. 准噶尔盆地乌尔禾地区风城组云质致密油储层特征[J]. 成都理工大学学报(自然科学版), 2013, 40(3):315-325.
	PAN Xiaotian, ZHENG Rongcai, WEN Huaguo, et al. Tight oil reservoir of Permian Fengcheng formation in Urho area,Junggar basin,China[J]. Journal of Chengdu University of Technology(Science & Technology Edition), 2013, 40(3):315-325.
[24]	鲁新川, 孔玉华, 常娟, 等. 准噶尔盆地西北缘克百地区二叠系风城组砂砾岩储层特征及主控因素分析[J]. 天然气地球科学, 2012, 23(3):474-481.
	LU Xinchuan, KONG Yuhua, CHANG Juan, et al. Characteristics and main controlling factors of sand-gravel stone reservoir of Permian Fengcheng formation in Kebai area,northwest Junggar basin[J]. Natural Gas Geoscience, 2012, 23(3):474-481.
