Reservoir Characteristics and Hydrocarbon Accumulation Model in Chunguang Oilfield, Junggar Basin

doi:10.7657/XJPG20200401

Abstract

Abstract:

Chunguang oilfield is a multi-layer oil-bearing, multi-reservoir type, light oil and heavy oil co-existing complex oil-gas accumulation area. In order to determine the reservoir characteristics and hydrocarbon accumulation model in Chunguang oilfield, the paper analyzes the reservoir-forming factors and typical reservoirs. Double sag hydrocarbon supply, multiple reservoir-cap combinations, multiple reservoir sand bodies and compound transportation system are the necessary conditions for the multi-layer oil-bearing and three-dimensional reservoir-forming of Chunguang oilfield, and the peripheral areas of stratigraphic overlap line, denudation line and sandbody pinchout line are favorable areas for oil and gas accumulation. Gypsum-salt-bearing regional caprock and high-porosity and high-permeability reservoirs are the key factors for high oil production of Shawan formation in Chunguang oilfield, biodegradation is the main reason for the thickening of Cretaceous crude oil and the distributions of light oil and heavy oil are mainly controlled by preservation conditions. The hydrocarbon accumulation model can be summarized as follows：double sag hydrocarbon supply, two-stage charging, compound transportation, three-dimensional reservoir forming and crude oil biodegradation and thickening, and the favorable areas are presented, which can provide references for the oil and gas exploration of the western uplift and its surrounding areas in Junggar basin.

Key words: Junggar basin, Chunguang oilfield, reservoir characteristic, reservoir-forming factor, hydrocarbon accumulation model, double sag hydrocarbon supply, compound transportation

CLC Number:

TE112.43

ZHANG Hui, YUE Xinxin, ZHU Yan, LI Yanran, GUO Juncan, YU Mengli, CHEN Feng. Reservoir Characteristics and Hydrocarbon Accumulation Model in Chunguang Oilfield, Junggar Basin[J]. Xinjiang Petroleum Geology, 2020, 41(4): 379-387.

Figures/Tables 8

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Fig. 7.

Fig. 8.

References 31

[1]	王屿涛. 准噶尔盆地西北缘稠油生物降解特征[J]. 沉积学报, 1994,12(1):81-88.
	WANG Yutao. Characteristics of heavy oil biodegradation in the northwestern margin of Junggar basin[J]. Acta Sedimentologica Sinica, 1994,12(1):81-88.
[2]	王屿涛, 蒋少斌. 准噶尔盆地西北缘稠油分布的地质规律及成因探讨[J]. 石油勘探与开发, 1998,25(5):18-20.
	WANG Yutao, JIANG Shaobin. An approach to the distribution and origin of heavy oil in the northwest margin of Junggar basin[J]. Petroleum Exploration and Development, 1998,25(5):18-20.
[3]	沈扬, 林会喜, 赵乐强, 等. 准噶尔盆地西北缘超剥带油气运聚特征与成藏模式[J]. 新疆石油地质, 2015,36(5):505-509.
	SHEN Yang, LIN Huixi, ZHAO Leqiang, et al. Hydrocarbon migration-accumulation characteristics and pool-forming patterns in overlap-erosion zones in northwestern margin of Junggar basin[J]. Xinjiang Petroleum Geology, 2015,36(5):505-509.
[4]	姚卫江, 党玉芳, 张顺存, 等. 准噶尔盆地西北缘红车断裂带石炭系成藏控制因素浅析[J]. 天然气地球科学, 2010,21(6):917-923.
	YAO Weijiang, DANG Yufang, ZHANG Shuncun, et al. Formation of Carboniferous reservoir in Hongche fault belt,northwestern margin of Junggar basin[J]. Natural Gas Geoscience, 2010,21(6):917-923.
[5]	赵爱文, 王振奇, 李伟强. 准噶尔盆地西北缘红车断裂带油气来源与成藏模式[J]. 西安石油大学学报(自然科学版), 2015,30(5):16-22.
	ZHAO Aiwen, WANG Zhenqi, LI Weiqiang. Hydrocarbon sources and accumulation models of Hongche fault zone in the northwestern margin of Junggar basin[J]. Journal of Xi’an Shiyou University (Natural Science Edition) , 2015,30(5):16-22.
[6]	林小云, 覃军, 聂婉, 等. 准噶尔盆地南缘卡因迪克地区油气成藏模式研究[J]. 石油实验地质, 2014,36(3):304-309.
	LIN Xiaoyun, QIN Jun, NIE Wan, et al. Hydrocarbon accumulation pattern of Kayindike region in southern Junggar basin[J]. Petroleum Geology & Experiment, 2014,36(3):304-309.
[7]	任培罡, 陈思, 潘建国, 等. 准噶尔盆地卡因迪克地区构造特征[J]. 油气地质与采收率, 2010,17(1):25-28.
	REN Peigang, CHEN Si, PAN Jianguo, et al. Structural characteristics of the Kayindike area,Junggar basin[J]. Petroleum Geology and Recovery Efficiency, 2010,17(1):25-28.
[8]	洪太元, 王离迟, 孟闲龙, 等. 准噶尔盆地西缘车排子地区油气成藏的主控因素[J]. 新疆地质, 2007,25(4):389-393.
	HONG Taiyuan, WANG Lichi, MENG Xianlong, et al. The main control factors of the oil and gas accumulation in the Chepaizi area of the western Junggar basin[J]. Xinjiang Geology, 2007,25(4):389-393.
[9]	徐常胜, 杜社宽, 黄建良, 等. 车排子凸起沙湾组油藏特征与成藏主控因素[J]. 新疆石油地质, 2013,34(3):258-261.
	XU Changsheng, DU Shekuan, HUANG Jianliang, et al. Characteristics and key controlling factors for oil-gas accumulation of Neogene Shawan reservoir in Chepaizi swell,Junggar basin[J]. Xinjiang Petroleum Geology, 2013,34(3):258-261.
[10]	宋传春, 贺伦俊, 马立群, 等. 准噶尔盆地车排子凸起成藏特征[J]. 新疆石油地质, 2007,28(2):136-137.
	SONG Chuanchun, HE Lunjun, MA Liqun, et al. Characteristic of hydrocarbon accumulation of Chepaizi swell in Junggar basin[J]. Xinjiang Petroleum Geology, 2007,28(2):136-137.
[11]	胡宗全. 准噶尔盆地西北缘车排子地区油气成藏模式[J]. 断块油气田, 2004,11(1):12-15.
	HU Zongquan. Hydrocarbon reservoir formation model of Chepaizi area in northwest edge of Junggar basin[J]. Fault-Block Oil ＆ Gas Field, 2004,11(1):12-15.
[12]	张善文, 林会喜, 沈扬. 准噶尔盆地车排子凸起新近系“网毯式”成藏机制剖析及其对盆地油气勘探的启示[J]. 地质论评, 2013,59(3):489-500.
	ZHANG Shanwen, LIN Huixi, SHEN Yang. Analysis on meshwork-carpet pool-forming mechanism of Chepaizi uplift and enlightenment on petroleum exploration of Junggar basin[J]. Geological Review, 2013,59(3):489-500.
[13]	叶茂松, 解习农. 准噶尔盆地车排子凸起下切谷特征及演化模式[J]. 地球科学:中国地质大学学报, 2014,39(5):577-586.
	YE Maosong, XIE Xinong. Characteristics and evolutionary pattern of incised valley in Chepaizi area,Junggar basin[J]. Earth Science:Journal of China University of Geosciences, 2014,39(5):577-586.
[14]	胡秋媛, 董大伟, 赵利, 等. 准噶尔盆地车排子凸起构造演化特征及其成因[J]. 石油与天然气地质, 2016,37(4):556-564.
	HU Qiuyuan, DONG Dawei, ZHAO Li, et al. Tectonic evolutionary characteristics and their causes of Chepaizi uplift in Junggar basin[J]. Oil ＆ Gas Geology, 2016,37(4):556-564.
[15]	樊晓伊, 姚光庆, 岳欣欣, 等. 基于现代沉积的车排子凸起春光区块沙二段沉积相研究[J]. 新疆石油地质, 2017,38(2):155-160.
	FAN Xiaoyi, YAO Guangqing, YUE Xinxin, et al. Research on sedimentary facies based on modern sedimentary systems:a case from the second member of Shawan formation in Chunguang area of Chepaizi swell,Junggar basin[J]. Xinjiang Petroleum Geology, 2017,38(2):155-160.
[16]	陈轩, 张尚锋, 张昌民, 等. 准噶尔盆地车排子地区新近系沙湾组层序地层[J]. 新疆石油地质, 2008,29(1):65-67.
	CHEN Xuan, ZHANG Shangfeng, ZHANG Changmin, et al. Sequence stratigraphy of Neogene Shawan formation in Chepaizi area,Junggar basin[J]. Xinjiang Petroleum Geology, 2008,29(1):65-67.
[17]	陈建平, 王绪龙, 邓春萍, 等. 准噶尔盆地烃源岩与原油地球化学特征[J]. 地质学报, 2016,90(1):37-67.
	CHEN Jianping, WANG Xulong, DENG Chunping, et al. Geochemical features of source rocks and crude oil in the Junggar basin,northwest China[J]. Acta Geologica Sinica, 2016,90(1):37-67.
[18]	张枝焕, 向奎, 秦黎明, 等. 准噶尔盆地四棵树凹陷烃源岩地球化学特征及其对车排子凸起油气聚集的贡献[J]. 中国地质, 2012,39(2):326-337.
	ZHANG Zhihuan, XIANG Kui, QIN Liming, et al. Geochemical characteristics of source rocks and their contribution to petroleum accumulation of Chepaizi area in Sikeshu depression,Junggar basin[J]. Geology in China, 2012,39(2):326-337.
[19]	程长领. 四棵树凹陷侏罗系烃源岩再认识[J]. 新疆石油地质, 2018,39(1):119-124.
	CHENG Changling. Re-cognition of the Jurassic source rocks in Sikeshu sag[J]. Xinjiang Petroleum Geology, 2018,39(1):119-124.
[20]	付顺, 王成善, 田景春, 等. 准噶尔盆地陆梁油气田原油的生物降解特征及其成藏意义[J]. 成都理工大学学报(自然科学版), 2005,32(3):252-256.
	FU Shun, WANG Chengshan, TIAN Jingchun, et al. Biodegradation characteristics of the oil from the Luliang oil field of Junggar basin,China[J]. Journal of Chengdu University of Technology(Science ＆ Technology Edition), 2005,32(3):252-256.
[21]	杜宏宇, 王铁冠, 胡剑梨, 等. 三塘湖盆地上二叠统烃源岩中的25-降藿烷系列与微生物改造作用[J]. 石油勘探与开发, 2004,31(1):42-44.
	DU Hongyu, WANG Tieguan, HU Jianli, et al. 25-norhopane in the source rock of Santanghu basin and the function of microbe degradation[J]. Petroleum Exploration and Development, 2004,31(1):42-44.
[22]	袁玲, 任新成, 穆玉庆, 等. 准噶尔盆地春风油田油气输导体系[J]. 新疆石油地质, 2012,33(3):288-289.
	YUAN Ling, REN Xincheng, MU Yuqing, et al. Oil-gas transport system in Chunfeng oilfield in Junggar basin[J]. Xinjiang Petroleum Geology, 2012,33(3):288-289.
[23]	陶士振, 袁选俊, 侯连华, 等. 中国岩性油气藏区带类型、地质特征与勘探领域[J]. 石油勘探与开发, 2016,43(6):863-872.
	TAO Shizhen, YAN Xuanjun, HOU Lianhua, et al. Play types,geologic characteristics and exploration domains of lithological reservoirs in China[J]. Petroleum Exploration and Development, 2016,43(6):863-872.
[24]	隋风贵. 准噶尔盆地西北缘中国石化探区勘探突破实践[J]. 新疆石油地质, 2013,34(2):129-132.
	SUI Fenggui. The practices for exploration breakthrough in Sinopec prospecting area in northwestern margin of Junggar basin[J]. Xinjiang Petroleum Geology, 2013,34(2):129-132.
[25]	刘卫民, 陶柯宇, 高秀伟, 等. 含油气盆地远距离成藏模式与主控因素[J]. 地质论评, 2015,61(3):621-633.
	LIU Weimin, TAO Keyu, GAO Xiuwei, et al. Long-distance hydrocarbon migration and accumulation models and key controls in petroliferous basin[J]. Geological Review, 2015,61(3):621-633.
[26]	赵卫军, 支东明, 徐群洲, 等. 车排子油田地下水特征及勘探领域[J]. 新疆石油地质, 2009,30(2):219-220.
	ZHAO Weijun, ZHI Dongming, XU Qunzhou, et al. Groundwater nature and exploration domain in Chepaizi field[J]. Xinjiang Petroleum Geology, 2009,30(2):219-220.
[27]	付金华, 柳广弟, 杨伟伟, 等. 鄂尔多斯盆地陇东地区延长组低渗透油藏成藏期次研究[J]. 地学前缘, 2013,20(2):125-131.
	FU Jinhua, LIU Guangdi, YANG Weiwei, et al. A study of the accumulation periods of low permeability reservoir of Yanchang formation in Longdong area,Ordos basin[J]. Earth Science Frontiers, 2013,20(2):125-131.
[28]	刘华, 蒋有录, 卢浩, 等. 渤南洼陷流体包裹体特征与成藏期流体压力恢复[J]. 地球科学, 2016,41(8):1 384-1 394.
	LIU Hua, JIANG Youlu, LU Hao, et al. Restoration of fluid pressure during hydrocarbon accumulation period and fluid inclusion feature in the Bonan sag[J]. Earth Science, 2016,41(8):1 384-1 394.
[29]	高先志, 陈发景. 应用流体包裹体研究油气成藏期次:以柴达木盆地南八仙油田第三系储层为例[J]. 地学前缘, 2000,7(4):548-554.
	Gao Xianzhi, CHEN Fajing. Application of fluid inclusions to determination of the times and stages of hydrocarbon reservoir filling:a case study of Nanbaxian oilfield in the Qaidam basin[J]. Earth Science Frontiers, 2000,7(4):548-554.
[30]	张枝焕, 刘洪军, 李伟, 等. 准噶尔盆地车排子地区稠油成因及成藏过程[J]. 地球科学与环境学报, 2014,36(2):18-32.
	ZHANG Zhihuan, LIU Hongjun, LI Wei, et al. Origin and accumulation process of heavy oil in Chepaizi area of Junggar basin[J]. Journal of Earth Sciences and Environment, 2014,36(2):18-32.
[31]	梁宝兴, 周伟, 刘勇, 等. 四棵树凹陷高探1井流体特征及油藏类型分析[J]. 新疆石油地质, 2019,40(2):152-155.
	LIANG Baoxing, ZHOU Wei, LIU Yong, et al. Fluid features and reservoir types in well Gaotan 1 in Sikeshu sag,Junggar basin[J]. Xinjiang Petroleum Geology, 2019,40(2):152-155.
