ROP Improvement and Production Enhancement for Ultra-Deep Wells Based on Geology-Engineering Integration: A Case in Kuqa Depression, Tarim Basin

doi:10.7657/XJPG20220212

Abstract

Abstract:

The Kuqa depression in the Tarim basin is rich in oil and gas resources and has great potential for exploration. However, the geological setting in this area is complex and the target layers are generally buried deeper than 6 000 m, or even more than 8 000 m, making oil and gas exploration and development difficult. Considering the geological engineering characteristics and existing problems of ultra-deep wells in the Kuqa depression, a solution based on the concept of geology-engineering integration is proposed, and the successful practice of the first pre-salt highly-deviated well in Tarim oilfield is introduced. Research and practices show that geomechanical research is beneficial to reducing drilling complexities and increasing rate of penetration, can help select favorable reservoirs and optimize stimulation schemes, and finally support the ROP improvement and production enhancement. The geology-engineering integration is necessary for efficient development of complex oil and gas reservoirs. In this aspect, multiple disciplines will be collaborated in operations through the life cycle of each well to generate the maximum benefits and achieve overall progress from well location deployment, drilling engineering, well completion and stimulation to oil/gas production engineering, thereby facilitating the construction of large oil and gas fields.

Key words: Tarim basin, Kuqa depression, ultra-deep well, geology-engineering integration, geomechanics, highly deviated well, ROP improvement, production enhancement

CLC Number:

TE371

CAI Zhenzhong, XU Ke, ZHANG Hui, WANG Zhimin, YIN Guoqing, LIU Xinyu. ROP Improvement and Production Enhancement for Ultra-Deep Wells Based on Geology-Engineering Integration: A Case in Kuqa Depression, Tarim Basin[J]. Xinjiang Petroleum Geology, 2022, 43(2): 206-213.

Figures/Tables 7

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Fig. 7.

References 31

[1]	杨海军, 李勇, 唐雁刚, 等. 塔里木盆地克深气田成藏条件及勘探开发关键技术[J]. 石油学报, 2021, 42(3):399-414.
	YANG Haijun, LI Yong, TANG Yangang, et al. Accumulation conditions,key exploration and development technologies for Keshen gas field in Tarim basin[J]. Acta Petrolei Sinica, 2021, 42(3):399-414.
[2]	田军. 塔里木盆地油气勘探成果与勘探方向[J]. 新疆石油地质, 2019, 40(1):1-11.
	TIAN Jun. Petroleum exploration achievements and future targets of Tarim basin[J]. Xinjiang Petroleum Geology, 2019, 40(1):1-11.
[3]	田军, 杨海军, 吴超, 等. 博孜9井的发现与塔里木盆地超深层天然气勘探潜力[J]. 天然气工业, 2020, 40(1):11-19.
	TIAN Jun, YANG Haijun, WU Chao, et al. Discovery of Well Bozi 9 and ultra-deep natural gas exploration potential in the Kelasu tectonic zone of the Tarim basin[J]. Natural Gas Industry, 2020, 40(1):11-19.
[4]	曾庆鲁, 莫涛, 赵继龙, 等. 7 000 m以深优质砂岩储层的特征、成因机制及油气勘探意义:以库车坳陷下白玺统巴什基奇克组为例[J]. 天然气工业, 2020, 40(1):38-47.
	ZENG Qinglu, MO Tao, ZHAO Jilong, et al. Characteristics,genetic mechanism and oil & gas exploration significance of high-quality sandstone reservoirs deeper than 7 000 m:a case study of the Bashijiqike formation of Lower Cretaceous in the Kuqa depression[J]. Natural Gas Industry, 2020, 40(1):38-47.
[5]	杨海军, 李勇, 唐雁刚, 等. 塔里木盆地克拉苏盐下深层大气田的发现[J]. 新疆石油地质, 2019, 40(1):12-20.
	YANG Haijun, LI Yong, TANG Yan’gang, et al. Discovery of Kelasu subsalt deep large gas field,Tarim basin[J]. Xinjiang Petroleum Geology, 2019, 40(1):12-20.
[6]	徐珂, 田军, 杨海军, 等. 深层致密砂岩储层现今地应力场预测及应用:以塔里木盆地克拉苏构造带克深10气藏为例[J]. 中国矿业大学学报, 2020, 49(4):708-720.
	XU Ke, TIAN Jun, YANG Haijun, et al. Prediction of current in-situ stress filed and its application of deeply buried tight reservoir:a case study of Keshen 10 gas reservoir in Kelasu structural belt,Tarim basin[J]. Journal of China University of Mining & Technology, 2020, 49(4):708-720.
[7]	胡文瑞. 地质工程一体化是实现复杂油藏效益勘探开发的必由之路[J]. 中国石油勘探, 2017, 22(1):1-5.
	HU Wenrui. Geology-engineering integration: a necessary way to realize profitable exploration and development of complex reservoirs[J]. China Petroleum Exploration, 2017, 22(1):1-5.
[8]	吴奇, 梁兴, 鲜成钢, 等. 地质—工程一体化高效开发中国南方海相页岩气[J]. 中国石油勘探, 2015, 20(4):1-23.
	WU Qi, LIANG Xing, XIAN Chenggang, et al. Geoscience-to-production integration ensures effective and efficient South China marine shale gas development[J]. China Petroleum Exploration, 2015, 20(4):1-23.
[9]	谢军, 张浩淼, 佘朝毅, 等. 地质工程一体化在长宁国家级页岩气示范区中的实践[J]. 中国石油勘探, 2017, 22(1):21-28.
	XIE Jun, ZHANG Haomiao, SHE Chaoyi, et al. Practice of geology-engineering integration in Changning State Shale Gas Demonstration Area[J]. China Petroleum Exploration, 2017, 22(1):21-28.
[10]	雍锐, 常程, 张德良, 等. 地质—工程—经济一体化页岩气水平井井距优化:以国家级页岩气开发示范区宁209井区为例[J]. 天然气工业, 2020, 40(7):42-48.
	YONG Rui, CHANG Cheng, ZHANG Deliang, et al. Optimization of shale-gas horizontal well spacing based on geology-engineering-economy integration:a case study of well block Ning 209 in the National Shale Gas Development Demonstration Area[J]. Natural Gas Industry, 2020, 40(7):42-48.
[11]	杨海军, 张辉, 尹国庆, 等. 基于地质力学的地质工程一体化助推缝洞型碳酸盐岩高效勘探:以塔里木盆地塔北隆起南缘跃满西区块为例[J]. 中国石油勘探, 2018, 23(2):27-36.
	YANG Haijun, ZHANG Hui, YIN Guoqing, et al. Geomechanics-based geology-engineering integration boosting high-efficiency exploration of fractured-vuggy carbonate reservoirs:a case study of west Yueman block,northern Tarim basin[J]. China Petroleum Exploration, 2018, 23(2):27-36.
[12]	尹国庆, 张辉, 王海应, 等. 地质工程一体化在克深24构造高效勘探中的应用[J]. 新疆石油地质, 2019, 40(4):486-492.
	YIN Guoqing, ZHANG Hui, WANG Haiying, et al. Application of geology-engineering integration in efficient exploration in structure KS24[J]. Xinjiang Petroleum Geology, 2019, 40(4):486-492.
[13]	张辉, 杨海军, 尹国庆, 等. 地质工程一体化关键技术在克拉苏构造带高效开发中的应用实践[J]. 中国石油勘探, 2020, 25(2):120-132.
	ZHANG Hui, YANG Haijun, YIN Guoqing, et al. Application practice of key technologies of geology-engineering integration in efficient development in Kelasu structural belt[J]. China Petroleum Exploration, 2020, 25(2):120-132.
[14]	胥志雄, 张辉, 尹国庆, 等. 超深井安全提速提产地质工程一体化关键技术[J]. 天然气工业, 2021, 41(11):104-114.
	XU Zhixiong, ZHANG Hui, YIN Guoqing, et al. Key technologies of geology-engineering integration for safe ROP improvement and production increase of ultra-deep wells[J]. Natural Gas Industry, 2021, 41(11):104-114.
[15]	王志民, 张辉, 徐珂, 等. 超深裂缝性砂岩气藏增产地质工程一体化关键技术与实践[J]. 中国石油勘探, 2022, 27(1):164-171.
	WANG Zhimin, ZHANG Hui, XU Ke, et al. Key technology and practice of well stimulation with geology and engineering integration of ultra-deep fractured sandstone gas reservoir[J]. China Petroleum Exploration, 2022, 27(1):164-171.
[16]	能源, 谢会文, 李勇, 等. 塔里木盆地库车坳陷中部构造变形样式及分布特征[J]. 地质科学, 2012, 47(3):629-639.
	NENG Yuan, XIE Huiwen, LI Yong, et al. The character of deformation style and its distribution law in the middle part of Kuqa depression,northern margin of Tarim basin,NW China[J]. Chinese Journal of Geology, 2012, 47(3):629-639.
[17]	漆家福, 雷刚林, 李明刚, 等. 库车坳陷—南天山盆山过渡带的收缩构造变形模式[J]. 地学前缘(中国地质大学(北京);北京大学), 2009, 16(3):120-128.
	QI Jiafu, LEI Ganglin, LI Minggang, et al. A model of contractional structure for transition belt between Kuche depression and Southern Tianshan uplift[J]. Earth Science Frontiers(China University of Geosciences(Beijing);Peking University), 2009, 16(3):120-128.
[18]	汪新, 王招明, 谢会文, 等. 塔里木库车坳陷新生代盐构造解析及其变形模拟[J]. 中国科学:地球科学, 2010, 40(12):1 655-1 668.
	WANG Xin, WANG Zhaoming, XIE Huiwen, et al. Cenozoic salt tectonics and physical models in the Kuqa depression of Tarim basin,China[J]. Science China:Earth Sciences, 2010, 40(12):1 655-1 668.
[19]	丁乙, 刘向君, 罗平亚, 等. 弱面结构对页岩地层井壁稳定性影响研究[J]. 地下空间与工程学报, 2018, 14(4):1 130-1 136.
	DING Yi, LIU Xiangjun, LUO Pingya, et al. Influence of weak plane on wellbore stability in shale formation[J]. Chinese Journal of Underground Space and Engineering, 2018, 14(4):1 130-1 136.
[20]	刘志远, 陈勉, 金衍, 等. 多弱面地层水平井裸眼井壁垮塌量计算模型[J]. 石油勘探与开发, 2014, 41(1):102-107.
	LIU Zhiyuan, CHEN Mian, JIN Yan, et al. Calculation model for bore-hole collapse volume of a horizontal openhole in multiple-weak-plane formation[J]. Petroleum Exploration and Development, 2014, 41(1):102-107.
[21]	孙金声, 李锐, 王韧, 等. 准噶尔盆地南缘井壁失稳机理及对策研究[J]. 西南石油大学学报(自然科学版), 2022, 44(1):1-12.
	SUN Jinsheng, LI Rui, WANG Ren, et al. Research on the mechanism and countermeasures of shaft instability in the southern margin of Junggar basin[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2022, 44(1):1-12.
[22]	卢运虎, 肖先恒, 赵琳, 等. 温度对超深裂缝性地层井壁稳定性的影响[J]. 钻井液与完井液, 2020, 37(2):160-167.
	LU Yunhu, XIAO Xianheng, ZHAO Lin, et al. The effect of temperature on stability of borehole wall in ultra-deep fractured formation[J]. Drilling Fluid & Completion Fluid, 2020, 37(2):160-167.
[23]	乔李华, 范生林, 齐玉. 中美典型高压页岩气藏钻井提速技术对比与启示[J]. 天然气工业, 2020, 40(1):104-109.
	QIAO Lihua, FAN Shenglin, QI Yu. Comparison and implications of ROP improvement technologies in typical high-pressure shale gas reservoirs in America and China[J]. Natural Gas Industry, 2020, 40(1):104-109.
[24]	曾凡辉, 张涛, 马磊, 等. 深层页岩体积压裂缝网动态渗透率模型及其应用[J]. 天然气地球科学, 2021, 32(7):941-949.
	ZENG Fanhui, ZHANG Tao, MA Lei, et al. Dynamic permeability model of volume fracturing network in deep shale gas reservoir and its application[J]. Natural Gas Geoscience, 2021, 32(7):941-949.
[25]	商琳. 富台碳酸盐岩潜山多期裂缝发育规律研究[D]. 山东青岛:中国石油大学(华东), 2014.
	SHANG Lin. Research on developing regularity of multiperiod structural fractures in Futai carbonate buried hill[D]. RQingdao,Shandong:China University of Petroleum (East China), 2014.
[26]	唐雁刚, 张荣虎, 魏红兴, 等. 致密砂岩储层多尺度裂缝渗透率定量表征及开发意义[J]. 特种油气藏, 2018, 25(5):30-34.
	TANG Yangang, ZHANG Ronghu, WEI Hongxing, et al. Quantitative permeability characterization of multi-scale fractures and its development significance in tight sandstone gas reservoir[J]. Special Oil & Gas Reservoirs, 2018, 25(5):30-34.
[27]	周鹏, 唐雁刚, 尹宏伟, 等. 塔里木盆地克拉苏构造带克深2气藏储层裂缝带发育特征及与产量关系[J]. 天然气地球科学, 2017, 28(1):135-145.
	ZHOU Peng, TANG Yangang, YIN Hongwei, et al. Relationship between characteristics of fracture belt and production of Keshen 2 gas reservior in Kelasu tectonic zone,Tarim basin[J]. Natural Gas Geoscience, 2017, 28(1):135-145.
[28]	卢婷, 王鸣川, 马文礼, 等. 考虑多重应力敏感效应的页岩气藏压裂水平井试井模型[J]. 新疆石油地质, 2021, 42(6):741-748.
	LU Ting, WANG Mingchuan, MA Wenli, et al. Fractured horizontal well test model for shale gas reservoirs with considering multiple stress sensitive factors[J]. Xinjiang Petroleum Geology, 2021, 42(6):741-748.
[29]	蒲晓, 郭大立, 兰天, 等. 低渗透油藏转向压裂产能预测及影响因素[J]. 新疆石油地质, 2021, 42(1):76-80.
	PU Xiao, GUO Dali, LAN Tian, et al. Productivity prediction and influencing factors of low permeability reservoirs after steering fracturing stimulation[J]. Xinjiang Petroleum Geology, 2021, 42(1):76-80.
[30]	田军, 刘洪涛, 滕学清, 等. 塔里木盆地克拉苏构造带超深复杂气田井全生命周期地质工程一体化实践[J]. 中国石油勘探, 2019, 24(2):165-173.
	TIAN Jun, LIU Hongtao, TENG Xueqing, et al. Geology-engineering integration practices throughout well lifecycle in ultra-deep complex gas reservoirs of Kelasu tectonic belt,Tarim basin[J]. China Petroleum Exploration, 2019, 24(2):165-173.
[31]	徐珂, 田军, 杨海军, 等. 塔里木盆地库车坳陷超深层现今地应力对储层品质的影响及实践应用[J]. 天然气地球科学, 2022, 33(1):13-23.
	XU Ke, TIAN Jun, YANG Haijun, et al. Effects and practical applications of present-day in-situ stress on reservoir quality in ultra-deep layers of Kuqa depression,Tarim basin[J]. Natural Gas Geoscience, 2022, 33(1):13-23.
