苏里格气田东区马五5气藏主控因素及富集区优选

doi:10.7657/XJPG20220303

摘要/Abstract

摘要：

为提高鄂尔多斯盆地马五₅气藏有效储集层钻遇率,运用钻井、测井、录井、岩心及生产试气等资料,通过对沉积微相、成岩作用、古地形等有效储集层主控因素分析,明确了马五₅气藏白云岩分布规律,并对储集层进行综合分类评价,优选出马五₅气藏有利富集区。研究结果表明,苏里格气田东区马五₅储集层呈局部透镜状分布,连片性不强,最有利的储集体是颗粒白云岩和粗粉晶白云岩,主要储集空间为晶间孔、晶间溶孔和构造裂缝。沉积相和成岩作用是马五₅储集层的主控因素,颗粒滩是马五₅储集层白云岩最有利的沉积微相;有效储集层主要受控于准同生白云化作用和埋藏白云岩成岩作用对储集层的改造程度;相对高部位的古斜坡是马五₅气藏开发的有利区。

关键词: 鄂尔多斯盆地, 苏里格气田, 奥陶系, 马家沟组, 沉积微相, 成岩作用, 古地形, 储集层

Abstract:

In order to improve the drilling rate of pay zones in the Ma5₅ gas reservoir in eastern Sulige gas field, Ordos basin, using the drilling, logging, core and gas production testing data, and analyzing the main factors controlling pay zones such as sedimentary microfacies, diagenesis and paleotopography, the distribution law of dolomite in the Ma5₅ gas reservoir was clarified. Moreover, the reservoirs were comprehensively classified and evaluated, and the favorable gas enrichment areas in the Ma5₅ gas reservoir were selected. The research results show that the pay zones in the Ma5₅ reservoir are distributed as “lens” in local areas, with poor continuity. The most favorable reservoir rocks are granular dolomite and coarse powder crystalline dolomite, and the main storage space consists of intergranular pores, intergranular dissolved pores and structural fractures. Sedimentary facies and diagenesis are the main controlling factors of the Ma5₅ reservoir, and the grain beach is the most favorable sedimentary microfacies of the Ma5₅ dolomite. The pay zones are mainly controlled by quasi-contemporaneous dolomitization and buried dolomite diagenesis. The paleoslope on the relatively high position is a favorable area for the development of the Ma5₅ gas reservoir.

Key words: Ordos basin, Sulige gas field, Ordovician, Majiagou formation, sedimentary microfacies, diagenesis, paleotopography, reservoir

中图分类号:

TE122.221

白慧, 杨特波, 侯科锋, 马志欣, 冯敏. 苏里格气田东区马五₅气藏主控因素及富集区优选[J]. 新疆石油地质, 2022, 43(3): 271-277.

BAI Hui, YANG Tebo, HOU Kefeng, MA Zhixin, FENG Min. Main Controlling Factors and Gas Enrichment Area Selection of Ma5₅ Gas Reservoir in Eastern Sulige Gas Field[J]. Xinjiang Petroleum Geology, 2022, 43(3): 271-277.

图/表 6

图1

图2

图3

图4

图5

图6

参考文献 26

[1]	张明禄, 卢涛, 王勇. 长庆气田下古生界气藏高产富集规律和高产井筛选[J]. 中国石油勘探, 2001,6(4):50-56.
	ZHANG Minglu, LU Tao, WANG Yong. High-yield enrichment and screening of high-yield wells in the Lower Paleozoic gas reservoirs in Changqing gas field[J]. China Petroleum Exploration, 2001,6(4):50-56.
[2]	魏新善, 陈娟萍, 张道锋, 等. 鄂尔多斯盆地东部大面积致密碳酸盐岩气地质特征及成藏条件分析[J]. 天然气地球科学, 2017,28(5):677-686.
	WEI Xinshan, CHEN Juanping, ZHANG Daofeng, et al. Geological characteristics and reservoir forming conditions of large area tight carbonate gas in eastern Ordos basin,China[J]. Natural Gas Geoscience, 2017,28(5):677-686.
[3]	杨华, 刘新社, 张道锋. 鄂尔多斯盆地奥陶系海相碳酸盐岩天然气成藏主控因素及勘探进展[J]. 天然气工业, 2013,33(5):1-12.
	YANG Hua, LIU Xinshe, ZHANG Daofeng. Main controlling factors of gas pooling in Ordovician marine carbonate reservoirs in the Ordos basin and advances in gas exploration[J]. Natural Gas Industry, 2013,33(5):1-12.
[4]	贺训云, 寿建峰, 沈安江, 等. 白云岩地球化学特征及成因:以鄂尔多斯盆地靖西马五段中组合为例[J]. 石油勘探与开发, 2014,41(3):375-384.
	HE Xunyun, SHOU Jianfeng, SHEN Anjiang, et al. Geochemical characteristics and origin of dolomite:a case study from the middle assemblage of Majiagou formation Member 5 of the west of Jingbian gas field,Ordos basin,North China[J]. Petroleum Exploration and Development, 2014,41(3):375-384.
[5]	刘燕, 付金华, 李建明. 鄂尔多斯盆地东部奥陶系马家沟组白云岩成因机理分析[J]. 石油天然气学报, 2011,33(11):46-50.
	LIU Yan, FU Jinhua, LI Jianming. Origin of dolomite in Majiagou formation of Ordovician,east of Ordos basin[J]. Journal of Oil and Gas Technology, 2011,33(11):46-50.
[6]	赵俊兴, 陈洪德, 张锦泉, 等. 鄂尔多斯盆地中部马五段白云岩成因机理研究[J]. 石油学报, 2005,26(5):38-41.
	ZHAO Junxing, CHEN Hongde, ZHANG Jinquan, et al. Genesis of dolomite in the fifth member of Majiagou formation in the middle Ordos basin[J]. Acta Petrolei Sinica, 2005,26(5):38-41.
[7]	罗清清, 刘波, 姜伟民, 等. 鄂尔多斯盆地中部奥陶系马家沟组五段白云岩储层成岩作用及孔隙演化[J]. 石油与天然气地质, 2020,41(1):102-115.
	LUO Qingqing, LIU Bo, JIANG Weimin, et al. Diagenesis and pore evolution of dolomite reservoir in the 5th member of Ordovician Majiagou formation,central Ordos basin[J]. Oil & Gas Geology, 2020,41(1):102-115.
[8]	于洲, 孙六一, 吴兴宁, 等. 鄂尔多斯盆地靖西地区马家沟组中组合储层特征及主控因素[J]. 海相油气地质, 2012,17(4):49-56.
	YU Zhou, SUN Liuyi, WU Xingning, et al. Characteristics and controlling factors of the middle array of Ordovician Majiagou reservoirs to the west of Jingbian gas field, Ordos basin[J]. Marine Origin Petroleum Geology, 2012,17(4):49-56.
[9]	张威, 丁晓琪, 李春堂, 等. 鄂尔多斯盆地北部杭锦旗马家沟组四段碳酸盐岩储层分布规律[J]. 石油与天然气地质, 2021,42(3):615-626.
	ZHANG Wei, DING Xiaoqi, LI Chuntang, et al. Distribution of paleo-karst reservoirs in Ma 4 member,Hangjinqi area,northern Ordos basin[J]. Oil & Gas Geology, 2021,42(3):615-626.
[10]	张才利, 刘新社, 杨亚娟, 等. 鄂尔多斯盆地长庆油田油气勘探历程与启示[J]. 新疆石油地质, 2021,42(3):253-263.
	ZHANG Caili, LIU Xinshe, YANG Yajuan, et al. Petroleum exploration history and enlightenment of Changqing oilfield in Ordos basin[J]. Xinjiang Petroleum Geology, 2021,42(3):253-263.
[11]	李振宏, 王欣, 杨遂正, 等. 鄂尔多斯盆地奥陶系岩溶储层控制因素分析[J]. 现代地质, 2006,20(2):299-306.
	LI Zhenhong, WANG Xin, YANG Suizheng, et al. Analysis of control factors of Ordovician karst reservoir in Ordos basin[J]. Geoscience, 2006,20(2):299-306.
[12]	霍勇, 罗顺社, 庞秋维, 等. 鄂尔多斯台地靖边潜台南部中奥陶统马五5$_{2}^{1}$岩相古地理[J]. 中国地质, 2012,39(1):86-95.
	HUO Yong, LUO Shunshe, PANG Qiuwei, et al. Lithofacies Paleogeography of Middle Ordovician Ma5$_{2}^{1}$ in Jingbian tableland,Ordos platform[J]. Geology in China, 2012,39(1):86-95.
[13]	谢锦龙, 吴兴宁, 孙六一, 等. 鄂尔多斯盆地奥陶系马家沟组五段岩相古地理及有利区带预测[J]. 海相油气地质, 2013,18(4):23-32.
	XIE Jinlong, WU Xingning, SUN Liuyi, et al. Lithofacies palaeogeography and potential zone predicition of Ordovician Majiagou Member-5 in Ordos basin[J]. Marine Origin Peteoleum Geology, 2013,18(4):23-32.
[14]	苏中堂, 陈洪德, 欧阳征健, 等. 鄂尔多斯地区马家沟组层序岩相古地理特征[J]. 中国地质, 2012,39(3):623-633.
	SU Zhongtang, CHEN Hongde, OUYANG Zhengjian, et al. Sequence-based lithofacies and paleogeography of Majiagou formation in Ordos basin[J]. Geology in China, 2012,39(3):623-633.
[15]	苏中堂, 陈洪德, 徐粉燕, 等. 鄂尔多斯盆地马家沟组白云岩地球化学特征及白云岩化机制分析[J]. 岩石学报, 2011,27(8):2 230-2 238.
	SU Zhongtang, CHEN Hongde, XU Fenyan, et al. Geochemistry and dolomitization mechanism of Majiagou dolomites in Ordovician,Ordos,China[J]. Acta Petrologica Sinica, 2011,7(8):2 230-2 238.
[16]	黄擎宇, 张哨楠, 丁晓琪, 等. 鄂尔多斯盆地西南缘奥陶系马家沟组白云岩成因研究[J]. 石油实验地质, 2010,32(2):147-153.
	HUANG Qingyu, ZHANG Shaonan, DING Xiaoqi, et al. Origin of dolomite of Ordovician Majiagou formation,western and southern margin of the Ordos basin[J]. Petroleum Geology & Experiment, 2010,32(2):147-153.
[17]	郑剑锋, 沈安江, 刘永福, 等. 塔里木盆地寒武-奥陶系白云岩成因及分布规律[J]. 新疆石油地质, 2011,32(6):600-604.
	ZHENG Jianfeng, SHEN Anjiang, LIU Yongfu, et al. Genesis and distribution of the Cambro-Ordovician dolomite in Tarim basin[J]. Xinjiang Petroleum Geology, 2011,32(6):600-604.
[18]	赵卫卫, 王宝清. 鄂尔多斯盆地苏里格地区奥陶系马家沟组马五段白云岩的地球化学特征[J]. 地球学报, 2011,32(6):681-690.
	ZHAO Weiwei, WANG Baoqing. Geochemical characteristics of dolomite from 5th member of the Ordovician Majiagou formation in Sulige area,Ordos basin[J]. Acta Geoscientica Sinica, 2011,32(6):681-690.
[19]	白慧, 杨国平, 杨特波, 等. 致密碳酸盐岩气藏井位优选技术及其应用:以苏里格气田东区为例[J]. 西北地质, 2020,53(3):264-272.
	BAI Hui, YANG Guoping, YANG Tebo et al. Research and application of well location optimization technique in tight carbonatite gas reservoir:a case study of the eastern part of Sulige gas field[J]. Northwestern Geology, 2020,53(3):264-272.
[20]	李朝旭, 秦启荣, 田国庆, 等. 靖边气田南部奥陶系马五₁₊₂亚段储集层成岩演化特征[J]. 新疆石油地质, 2020,41(2):172-179.
	LI Zhaoxu, QIN Qirong, TIAN Guoqing, et al. Diagenetic evolution of the Ordovician Ma5₁₊₂ sub-member reservoir in the Southern Jingbian gasfield,Ordos basin[J]. Xinjiang Petroleum Geology, 2020,41(2):172-179.
[21]	鲁锴, 鲍志东, 季汉成, 等. 雄安新区蓟县系雾迷山组岩溶热储特征、主控因素及有利区预测[J]. 古地理学报, 2019,21(6):885-900.
	LU Kai, BAO Zhidong, JI Hancheng, et al. Characteristics,main controlling factors and favorable area prediction of karstic geothermal reservoirs of the Jixianian Wumishan formation in Xiong'an new area[J]. Journal of Palaeogeography, 2019,21(6):885-900.
[22]	朱荣伟, 蒋有录, 刘景东, 等. 鄂尔多斯盆地靖西中部地区天然气富集差异及有利勘探方向预测[J]. 天然气地球科学, 2017,28(1):32-42.
	ZHU Rongwei, JIANG Youlu, LIU Jingdong, et al. Natural gas enrichment difference and prediction of favorable exploration targets in the midland of Jingxi area,Ordos basin[J]. Natural Gas Geoscience, 2017,28(1):32-42.
[23]	白慧, 颜学成, 王龙, 等. 苏里格气田东区奥陶系马家沟上组合储层特征及主控因素分析[J]. 西北地质, 2015,48(1):221-228.
	BAI Hui, YAN Xuecheng, WANG Long, et al. Analysis on the main controlling factors and characteristics of the upper combination of Ordovician Majiagou formation in the eastern part of Sulige gasfield[J]. Northwestern Geology, 2015,48(1):221-228.
[24]	王保全, 强子同, 张帆, 等. 鄂尔多斯盆地奥陶系马家沟组马五段白云岩的同位素地球化学特征[J]. 地球化学, 2009,38(5):472-479.
	WANG Baoquan, QIANG Zitong, ZHANG Fan, et al. Isotope characteristics of dolomite from the fifth member of the Ordovician Majiagou formation,the Ordos basin[J]. Geochimica, 2009,38(5):472-479.
[25]	姚泾利, 王保全, 王一, 等. 鄂尔多斯盆地下奥陶统马家沟组马五段白云岩的地球化学特征[J]. 沉积学报, 2009,27(3):381-389.
	YAO Jingli, WANG Baoquan, WANG Yi, et al. Geochemical characteristics of dolomites in Lower Ordovician Majiagou formation,Ordos basin[J]. Acta Sedimentologica Sinica, 2009,27(3):381-389.
[26]	张军涛, 金晓辉, 谷宁, 等. 鄂尔多斯盆地北部地区马家沟组岩溶储层的差异性和发育模式[J]. 石油与天然气地质, 2021,42(5):1 159-1 168.
	ZHANG Juntao, JIN Xiaohui, GU Ning, et al. Differences and development patterns of karst reservoirs in Majiagou formation,northern Ordos basin[J]. Oil & Gas Geology, 2021,42(5):1 159-1 168.
