顺北一区断溶体油藏溶解气驱开发特征

doi:10.7657/XJPG20230209

新疆石油地质 ›› 2023, Vol. 44 ›› Issue (2): 195-202.doi: 10.7657/XJPG20230209

顺北一区断溶体油藏溶解气驱开发特征

刘学利¹(), 谭涛¹, 陈勇¹, 解慧¹, 朱苏阳²(), 吴昊镪², 向东流²

1.中国石化 a.西北油田分公司勘探开发研究院；b.缝洞型油藏提高采收率重点实验室，乌鲁木齐 830011
2.西南石油大学油气藏地质及开发工程国家重点实验室，成都 610500

收稿日期:2022-04-16 修回日期:2022-06-30 出版日期:2023-04-01 发布日期:2023-03-31
通讯作者: 朱苏阳（1989-），男，江苏如皋人，讲师，博士，油藏工程，（Tel）15828512977（E-mail）Suyang.zhu@swpu.edu.cn
作者简介:刘学利（1974-），男，辽宁建平人，教授级高级工程师，博士，油气藏开发，（E-mail）lu-cas2000_swpi@126.com
基金资助:
中国石化缝洞型油藏提高采收率重点实验室2022年度开放基金(34400000-22-ZC0607-0008)

Development Characteristics of Solution-Gas Drive in Fault-Karst Reservoirs in Shunbei-1 Block

LIU Xueli¹(), TAN Tao¹, CHEN Yong¹, XIE Hui¹, ZHU Suyang²(), WU Haoqiang², XIANG Dongliu²

1. Sinopec, a.Research Institute of Exploration and Development, Northwest Oilfield Company；b.Key Laboratory of Enhanced Recovery for Fracture-Cavity Reservoirs, Urumqi, Xinjiang 830011, China
2. State Key Laboratory of Reservoir Geology and Development Engineering, Southwest Petroleum University, Chengdu, Sichuan 610500, China

Received:2022-04-16 Revised:2022-06-30 Online:2023-04-01 Published:2023-03-31

摘要/Abstract

摘要：

为确定顺北一区断溶体油藏是否有溶解气驱，通过油藏数值模拟，表征了断溶体油藏溶解气驱的特点；基于油藏工程，分析了顺北一区断溶体油藏的溶解气驱特征。研究表明，由于顺北断溶体油藏厚度大，在井底附近和油藏顶部同时发生组分重力分异，大量溶解气未被采出，形成次生气顶，发挥了溶解气的弹性能，使得井底流压的下降变缓，同时一定程度上增加了单井的动态储量，这个过程伴随着油相驱动指数的下降。随着溶解气进一步析出，次生气顶侵入井底，从而造成产油量快速递减。因此，在顺北一区断溶体油藏衰竭开发过程中，可在一定程度上利用溶解气驱，但仍需保压开发，不可任由溶解气进一步析出。

关键词: 塔里木盆地, 顺北一区, 断溶体油藏, 溶解气驱, 次生气顶, 油藏工程, 数值模拟

Abstract:

In order to confirm whether there is solution-gas drive in the fault-karst reservoirs in the Shunbei-1 block, reservoir numerical simulation was performed to characterize the solution-gas drive in the fault-karst reservoirs. Based on the reservoir engineering method, the solution-gas-drive characteristics of the fault-karst reservoirs in the Shunbei-1 block were analyzed. The study shows that due to the large thickness of the fault-karst reservoirs in the study area, component gravity differentiation occurs simultaneously near the bottom of the well and at the top of the reservoir, leaving a large amount of solution-gas unproduced and forming a secondary gas cap. Under the action of the elastic energy of solution-gas, the decline of bottomhole flow pressure slows down, and the dynamic reserves of a single well increase to a certain extent. This process is accompanied by the decline in oil-phase driving index. With the further development of solution-gas drive, the secondary gas cap invades the bottom of the well, resulting in a rapid decline of oil production. Therefore, during the depletion development of the fault-karst reservoirs in the Shunbei-1 block, the solution-gas drive can be used to a certain extent together with development under pressure.

Key words: Tarim basin, Shunbei block, fault-karst reservoir, solution-gas drive, secondary gas cap, reservoir engineering, numerical simulation

中图分类号:

TE155

刘学利, 谭涛, 陈勇, 解慧, 朱苏阳, 吴昊镪, 向东流. 顺北一区断溶体油藏溶解气驱开发特征[J]. 新疆石油地质, 2023, 44(2): 195-202.

LIU Xueli, TAN Tao, CHEN Yong, XIE Hui, ZHU Suyang, WU Haoqiang, XIANG Dongliu. Development Characteristics of Solution-Gas Drive in Fault-Karst Reservoirs in Shunbei-1 Block[J]. Xinjiang Petroleum Geology, 2023, 44(2): 195-202.

图/表 8

图1

图2

图3

图4

图5

图6

图7

图8

参考文献 26

[1]	焦方正. 塔里木盆地顺托果勒地区北东向走滑断裂带的油气勘探意义[J]. 石油与天然气地质, 2017, 38(5):831-839.
	JIAO Fangzhen. Significance of oil and gas exploration in NE strike-slip fault belts in Shuntuoguole area of Tarim basin[J]. Oil & Gas Geology, 2017, 38(5):831-839.
[2]	刘哲. 顺北弱挥发性碳酸盐岩油藏合理开发方式研究[D]. 成都: 成都理工大学, 2018.
	LIU Zhe. The reasonable development mode of weak volatile oil and carbonate reservoir in Shunbei zone[D]. Chengdu: Chengdu University of Technology, 2018.
[3]	LU Teng, LI Zhaomin, LI Songyan, et al. Performances of different recovery methods for orinoco belt heavy oil after solution gas drive[J]. Energy & Fuels, 2013, 27(6):3 498-3 507.
[4]	AL-MASRI W, SHAPIRO A. Experimental determination of relative permeabilities and critical gas saturations under solution-gas drive[J]. Journal of Petroleum Science & Engineering, 2021, 202:108 509.
[5]	PADILLA S R, CAMACHO V R G, CASTREJÓN A R, et al. Inflow performance relationships under gravity segregation for solution gas-drive reservoirs[J]. Journal of Energy Resources Technology Transactions of The ASME, 2009, 131(3):1-11.
[6]	张晨朔, 韩征, 冯志刚, 等. 基于状态方程的溶解气回注油藏物质平衡计算方法[J]. 科学技术与工程, 2020, 20(24):9 851-9 855.
	ZHANG Chenshuo, HAN Zheng, FENG Zhigang, et al. Material balance equation calculations for solution gas reinjection reservoir with the equation of state[J]. Science Technology and Engineering, 2020, 20(24):9 851-9 855.
[7]	MOULU J C. Solution-gas drive:experiments and simulation[J]. Journal of Petroleum Science & Engineering, 1989, 2(4):379-386.
[8]	吴明涛, 王晓冬, 董文秀. 确定溶解气驱油藏压力与饱和度关系的新方法[J]. 煤炭技术, 2018, 37(9):55-56.
	WU Mingtao, WANG Xiaodong, DONG Wenxiu. Novel method to estimate relationship of pressure and saturation in solution-gas drive reservoirs[J]. Coal Technology, 2018, 37(9):55-56.
[9]	SHAKIBA M, AYATOLLAHI S, RIAZI M. Activating solution gas drive as an extra oil production mechanism after carbonated water injection[J]. Chinese Journal of Chemical Engineering, 2020, 28(11):2 938-2 945. doi: 10.1016/j.cjche.2020.07.026
[10]	张鹏, 吴通, 李中, 等. BP神经网络法预测顺北超深碳酸盐岩储层应力敏感程度[J]. 石油钻采工艺, 2020, 42(5):622-626.
	ZHANG Peng, WU Tong, LI Zhong, et al. Application of BP neural network method to predict the stress sensitivity of ultra deep carbonate reservoir in Shunbei oilfield[J]. Oil Drilling & Production Technology, 2020, 42(5):622-626.
[11]	GEORGE D S, HAYAT O, KOVSCEK A R. A microvisual study of solution-gas-drive mechanisms in viscous oils[J]. Journal of Petroleum Science & Engineering, 2005, 46(1):101-119.
[12]	杨龙, 梅海燕, 张茂林, 等. 考虑干酪根中溶解气的页岩气藏储量计算方法[J]. 新疆石油地质, 2016, 37(5):602-605.
	YANG Long, MEI Haiyan, ZHANG Maolin, et al. A new method to calculate shale gas reserves considering dissolved gas in kerogen[J]. Xinjiang Petroleum Geology, 2016, 37(5):602-605.
[13]	李青, 李小波, 谭涛, 等. 断溶体油藏注采井网构建方法[J]. 新疆石油地质, 2021, 42(2):213-217.
	LI Qing, LI Xiaobo, TAN Tao, et al. Constructing optimum injection-production well pattern for fault-karst reservoirs[J]. Xinjiang Petroleum Geology, 2021, 42(2):213-217.
[14]	DONG Wenxiu, WANG Xiaodong, WANG Jiahang. A new method to calculate the early performance of solution-gas-drive reservoirs[J]. Journal of Petroleum Science & Engineering, 2018, 171:153-163.
[15]	丁良成. 一种预测溶解气可采储量的广义模型[J]. 新疆石油地质, 2007, 28(6):747-748.
	DING Liangcheng. A generalized model for prediction of solution gas reserves[J]. Xinjiang Petroleum Geology, 2007, 28(6):747-748.
[16]	漆立新, 云露, 曹自成, 等. 顺北油气田地质储量评估与油气勘探方向[J]. 新疆石油地质, 2021, 42(2):127-135.
	QI Lixin, YUN Lu, CAO Zicheng, et al. Geological reserves assessment and petroleum exploration targets in Shunbei oil & gas field[J]. Xinjiang Petroleum Geology, 2021, 42(2):127-135.
[17]	李映涛, 漆立新, 张哨楠, 等. 塔里木盆地顺北地区中—下奥陶统断溶体储层特征及发育模式[J]. 石油学报, 2019, 40(12):1 470-1 484.
	LI Yingtao, QI Lixin, ZHANG Shaonan, et al. Characteristics and development mode of the middle and lower Ordovician fault-kaust reservoir in Shunbei area,Tarim basin[J]. Acta Petrolei Sinica, 2019, 40 (12):1 470-1 484.
[18]	刘荣和, 张文彪, 冷有恒. 裂缝-孔隙型碳酸盐岩气藏稳态产能评价方法[J]. 特种油气藏, 2022, 29(2):122-127.
	LIU Ronghe, ZHANG Wenbiao, LENG Youheng. Steady productivity evaluation method of fractured-porous carbonate gas reservoirs[J]. Special Oil & Gas Reservoirs, 2022, 29(2):122-127.
[19]	伍齐乔, 李景瑞, 曹飞, 等. 顺北1井区奥陶系断溶体油藏岩溶发育特征[J]. 中国岩溶, 2019, 38(3):444-449.
	WU Qiqiao, LI Jingrui, CAO Fei, et al. Karst development characteristics of Ordovician fault solution reservoir in Shunbei Well 1[J]. Carsologica Sinica, 2019, 38 (3):444-449.
[20]	云露. 顺北地区奥陶系超深断溶体油气成藏条件[J]. 新疆石油地质, 2021, 42(2):136-142.
	YUN Lu. Hydrocarbon accumulation of ultra-deep Ordovician fault-karst reservoirs in Shunbei area[J]. Xinjiang Petroleum Geology, 2021, 42(2):136-142.
[21]	常媛, 贾鹏飞. 塔里木盆地塔中地区连续型碳酸盐岩油气藏地质特征及形成原因[J]. 大庆石油地质与开发, 2022, 41(2):11-15.
	CHANG Yuan, JIA Pengfei. Geological characteristics and forming cause of the continuous carbonate reservoirs in Tazhong area,Tarim basin[J]. Petroleum Geology & Oilfield Development in Daqing, 2022, 41(2):11-15.
[22]	刘宝增, 漆立新, 李宗杰, 等. 顺北地区超深层断溶体储层空间雕刻及量化描述技术[J]. 石油学报, 2020, 41(4):412-420. doi: 10.7623/syxb202004004
	LIU Baozeng, QI Lixin, LI Zongjie, et al. Spatial characterization and quantitative description technology for ultra-deep fault-karst reservoirs in Shunbei area[J]. Acta Petrolei Sinica, 2020, 41 (4):412-420. doi: 10.7623/syxb202004004
[23]	常宝华, 李世银, 曹雯, 等. 缝洞型碳酸盐岩油气藏关键开发指标预测方法及应用[J]. 特种油气藏, 2021, 28(2):72-77.
	CHANG Baohua, LI Shiyin, CAO Wen, et al. Prediction method of key development indicators of fracture-cavity carbonate reservoirs and its application[J]. Special Oil & Gas Reservoirs, 2021, 28(2):72-77.
[24]	李冬梅, 李会会, 朱苏阳, 等. 断溶体油气藏流动物质平衡方法[J]. 岩性油气藏, 2022, 34(1):154-162.
	LI Dongmei, LI Huihui, ZHU Suyang, et al. Modified flowing material balance method in fault-karst reservoirs[J]. Lithologic Reservoirs, 2022, 34(1):154-162.
[25]	杨旺旺, 张冲, 杨梦琼, 等. 基于长短期记忆循环神经网络的伊拉克H油田碳酸盐岩储层渗透率测井评价[J]. 大庆石油地质与开发, 2022, 41(1):126-133.
	YANG Wangwang, ZHANG Chong, YANG Mengqiong, et al. Permeability logging evaluation of carbonate reservoirs in Oilfield H of Iraq based on long short-term memory recurrent neural network[J]. Petroleum Geology & Oilfield Development in Daqing, 2022, 41(1):126-133.
[26]	李传亮. 油藏工程原理[M]. 北京: 石油工业出版社, 2011.
	LI Chuanliang. Reservoir engineering principles[M]. Beijing: Petroleum Industry Press, 2011.
