超低渗透油藏微生物活化水驱油机理

doi:10.7657/XJPG20250310

摘要/Abstract

摘要：

超低渗透油藏水驱开发过程中，水驱波及范围内原油优先被开采，剩余油饱和度较高，具备再次开发潜力，微生物活化水驱油技术是有效的油藏开发技术，但在超低渗透油藏中的驱油机理尚不明确。综合运用地球物理学、微生物学等，结合油藏工程，对原油族组分、微生物多样性等进行跟踪分析，并利用生产动态数据，对驱油机理进行研究。研究发现，在储集层较为均质的区域，油井产出液的表面张力基本保持不变，原油中的生物标志化合物未出现明显降解，原油黏度未出现明显变化，研究区微生物驱油机理以微观调剖为主，以提高驱油效率、降低原油黏度等机理为辅。在矿场实践中，依据油藏微生物变化规律和油井生产数据对该观点进行了验证。

关键词: 超低渗透油藏, 微生物活化水驱油, 驱油机理, 微观调剖, 生物降解

Abstract:

During water flooding in ultra-low permeability reservoirs, crude oil within the swept area is preferentially produced, leaving a high residual oil saturation with the potential for further recovery. Microbially activated water flooding is an effective reservoir development technology; however, its mechanism in ultra-low permeability reservoirs remains unclear. By integrating geophysics, microbiology, and reservoir engineering, the group components and microbial diversity of crude oil were tracked and analyzed. Then, using production performance data, the mechanism of microbially activated water flooding was investigated. The results indicate that in relatively homogeneous reservoir regions, surface tension of produced fluids remains stable, biomarkers in crude oil show no significant degradation, and oil viscosity exhibits no substantial changes. MEOR in the study area is mainly realized with the mechanism of microscopic profile control, supplemented by displacement efficiency enhancement and viscosity reduction. During field applications, this finding was validated by using reservoir microbial variations and production data.

Key words: ultra-low permeability reservoir, microbially activated water flooding, mechanism, microscopic profile control, biodegradation

中图分类号:

TE331

张永强, 张晓斌, 薛姝雯, 徐飞艳. 超低渗透油藏微生物活化水驱油机理[J]. 新疆石油地质, 2025, 46(3): 338-343.

ZHANG Yongqiang, ZHANG Xiaobin, XUE Shuwen, XU Feiyan. Mechanism of Microbially Activated Water Flooding in Ultra-Low Permeability Reservoirs[J]. Xinjiang Petroleum Geology, 2025, 46(3): 338-343.

图/表 11

表1

图1

图2

图3

图4

图5

图6

表2

表3

图7

图8

参考文献 21

[1]	汪卫东. 微生物采油技术研究进展与发展趋势[J]. 油气地质与采收率, 2021, 28(2):1-9.
	WANG Weidong. Research advance and development trend in microbial enhanced oil recovery technology[J]. Petroleum Geology and Recovery Efficiency, 2021, 28(2):1-9.
[2]	宋永亭, 胡婧, 冯云, 等. 微生物技术在页岩油气开发中的研究与应用[J]. 油气地质与采收率, 2023, 30(5):92-99.
	SONG Yongting, HU Jing, FENG Yun, et al. Research and application of microbial technology in shale oil and gas reservoirs development[J]. Petroleum Geology and Recovery Efficiency, 2023, 30(5):92-99.
[3]	刘晓丽, 李阳, 白雷, 等. 薄层砂岩边底水油藏内源微生物驱油技术[J]. 特种油气藏, 2024, 31(2):103-111. doi: 10.3969/j.issn.1006-6535.2024.02.012
	LIU Xiaoli, LI Yang, BAI Lei, et al. Endogenous microbial oil displacement technology for thin sandstone reservoir with edge and bottom water[J]. Special Oil & Gas Reservoirs, 2024, 31(2):103-111.
[4]	曹功泽. 胜利油田水驱与聚合物驱油藏微生物群落特征差异[J]. 大庆石油地质与开发, 2023, 42(3):115-121.
	CAO Gongze. Difference of microbial community characteristics between water flooding and polymer flooding reservoirs in Shengli oilfield[J]. Petroleum Geology & Oilfield Development in Daqing, 2023, 42(3):115-121.
[5]	佘跃惠, 舒闯闯, 付健, 等. 微生物提高采收率过程中促进原油动用的机制[J]. 科学技术与工程, 2023, 23(22):9331-9340.
	SHE Yuehui, SHU Chuangchuang, FU Jian, et al. Mechanism of promoting crude oil production during microbial enhanced oil recovery process[J]. Science Technology and Engineering, 2023, 23(22):9331-9340.
[6]	毕永强, 高煜婷, 王春友, 等. 渗透率对菌体调剖驱油效果的影响[J]. 断块油气田, 2020, 27(4):493-497.
	BI Yongqiang, GAO Yuting, WANG Chunyou, et al. Effect of permeability on profile control and oil displacement by bacteria[J]. Fault-Block Oil & Gas Field, 2020, 27(4):493-497.
[7]	张晓斌, 谢进霞, 张英, 等. 一株耐高温高矿化度的芽孢杆菌CQ11及其对原油的乳化和降解性能[J]. 南开大学学报(自然科学版), 2021, 54(6):30-38.
	ZHANG Xiaobin, XIE Jinxia, ZHANG Ying, et al. Study on the characteristics and emulsifying activity of a product emulsifier CQ11[J]. Acta Scientiarum Naturalium Universitatis Nankaiensis, 2021, 54(6):30-38.
[8]	邬传威, 尹三宁, 张百燕, 等. 原油族组分分析的优化及应用[J]. 化工管理, 2022, 35(32):38-41.
	WU Chuanwei, YIN Sanning, ZHANG Baiyan, et al. Optimization and application of crude oil group component analysis[J]. Chemical Enterprise Management, 2022, 35(32):38-41.
[9]	任国领, 窦绪谋, 曲丽娜, 等. 低渗透油藏激活前后微生物群落结构及演替规律:以大庆油田葡南X区块为例[J]. 大庆石油地质与开发, 2023, 42(2):108-115.
	REN Guoling, DOU Xumou, QU Lina, et al. Microbial community structure and succession laws before and after activation of low-permeability reservoir:A case study of Block X in Punan area of Daqing oilfield[J]. Petroleum Geology & Oilfield Development in Daqing, 2023, 42(2):108-115.
[10]	周银波, 张瑞林, 魏建平, 等. 微生物菌群的甲烷氧化效能及吸附煤体特性[J]. 天然气工业, 2023, 43(12):152-160.
	ZHOU Yinbo, ZHANG Ruilin, WEI Jianping, et al. Methane oxidizing capacity and coal adsorbing characteristics of microbial flora[J]. Natural Gas Industry, 2023, 43(12):152-160.
[11]	魏彩云, 马行陟, 胡国艺, 等. 石油地质气相色谱及气相色谱-质谱实验室比对结果评价[J]. 石油实验地质, 2023, 45(3):528-536.
	WEI Caiyun, MA Xingzhi, HU Guoyi, et al. Evaluation of laboratory comparison results of GC and GC-MS in petroleum geology industry[J]. Petroleum Geology & Experiment, 2023, 45(3):528-536.
[12]	马遵敬, 陈中红, 吴洛菲, 等. 哈拉阿拉特山西部地区生物降解原油地球化学特征及来源分析[J]. 地球化学, 2020, 49(5):549-562.
	MA Zunjing, CHEN Zhonghong, WU Luofei, et al. Geochemical characteristics and source correlation of biodegraded oils from the western Halaalate area[J]. Geochimica, 2020, 49(5):549-562.
[13]	肖正录, 李勇, 喻健, 等. 致密油“近源成藏”关键地球化学证据:以鄂尔多斯盆地延长组近源组合为例[J]. 石油实验地质, 2023, 45(3):517-527.
	XIAO Zhenglu, LI Yong, YU Jian, et al. Key geochemical evidence of “near-source accumulation” of tight oil:A case study of near-source assemblage of Triassic Yanchang formation in Ordos Basin[J]. Petroleum Geology & Experiment, 2023, 45(3):517-527.
[14]	仇永峰. 高邮凹陷北斜坡戴南组原油地球化学特征[J]. 大庆石油地质与开发, 2017, 36(5):14-19.
	QIU Yongfeng. Geochemical characteristics of the crude oil in Dainan formation of the northern slope in Gaoyou sag[J]. Petroleum Geology & Oilfield Development in Daqing, 2017, 36(5):14-19.
[15]	刘锋, 赵红静, 金颖, 等. 吐哈盆地胜北洼陷中—下侏罗统致密油烃源岩评价及油源对比[J]. 新疆石油地质, 2023, 44(3):277-288.
	LIU Feng, ZHAO Hongjing, JIN Ying, et al. Source rock evaluation and oil-source correlation for Middle-Lower Jurassic tight oil in Shengbei subsag,Turpan-Hami Basin[J]. Xinjiang Petroleum Geology, 2023, 44(3):277-288.
[16]	许汇源, 刘全有, 朱东亚, 等. 深部铅锌热液流体作用下的原油地球化学特征[J]. 石油与天然气地质, 2023, 44(1):178-185.
	XU Huiyuan, LIU Quanyou, ZHU Dongya, et al. Geochemical characteristics of crude oils under alteration of deep Pb-Zn-bearing hydrothermal fluids[J]. Oil & Gas Geology, 2023, 44(1):178-185.
[17]	刘奎勇, 吴滔, 卢树藩, 等. 黔东北铜仁地区牛蹄塘组烃源岩成熟度评价[J]. 新疆石油地质, 2023, 44(5):528-534.
	LIU Kuiyong, WU Tao, LU Shufan, et al. Maturity evaluation of Niutitang formation source rocks in Tongren area,northeast Guizhou[J]. Xinjiang Petroleum Geology, 2023, 44(5):528-534.
[18]	刘超威, 尤新才, 李辉, 等. 准噶尔盆地阜康凹陷芦草沟组烃源岩地球化学特征与生烃潜力研究[J]. 石油实验地质, 2023, 45(2):338-346.
	LIU Chaowei, YOU Xincai, LI Hui, et al. Geochemical characteristics and hydrocarbon generation potential of Lucaogou formation source rocks in Fukang sag,Junggar Basin[J]. Petroleum Geology & Experiment, 2023, 45(2):338-346.
[19]	刘音颂, 韦海文, 王继刚, 等. 水驱油藏微生物群落结构及影响因素[J]. 科学技术与工程, 2022, 22(23):9968-9975.
	LIU Yinsong, WEI Haiwen, WANG Jigang, et al. Microbial community structure and influencing factors in water drive reservoir[J]. Science Technology and Engineering, 2022, 22(23):9968-9975.
[20]	胡婧, 束青林, 孙刚正, 等. 油藏内源微生物演替规律及其对驱油效果的影响[J]. 中国石油大学学报(自然科学版), 2019, 43(1):108-114.
	HU Jing, SHU Qinglin, SUN Gangzheng, et al. Succession of indigenous microbe in reservoirs and its effect on displacement efficiency[J]. Journal of China University of Petroleum(Edition of Natrual Science), 2019, 43(1):108-114.
[21]	伊莉娜, 崔庆锋, 俞理, 等. 内源微生物驱后油藏理化性质变化及细菌群落结构解析[J]. 科学技术与工程, 2013, 13(24):6984-6989.
	YI Lina, CUI Qingfeng, YU Li, et al. Physical and chemical properties change of reservoir and analysis of indigenous microbial community after original microbe flooding[J]. Science Technology and Engineering, 2013, 13(24):6984-6989.

井名	试验2年前含量				试验开始时含量				试验2年后含量
井名	饱和烃	芳香烃	非烃	沥青质	饱和烃	芳香烃	非烃	沥青质	饱和烃	芳香烃	非烃	沥青质
A井	89.72	8.59	1.01	0.68	86.28	11.20	1.40	1.12	78.00	14.26	6.37	1.37
B井	83.53	12.65	2.77	1.05	74.91	17.87	5.32	1.90	78.23	13.71	5.38	2.68
C井	82.88	11.96	1.65	3.51	77.40	14.86	5.26	2.48	70.80	13.72	12.39	3.09
D井	80.78	16.52	1.44	1.26	71.66	21.13	3.09	4.12	69.89	17.92	9.68	2.51
E井	85.66	9.88	2.51	1.95	82.97	13.33	3.21	0.49	74.97	14.17	9.13	1.73
F井	82.34	10.87	5.13	1.66	81.09	14.86	3.51	0.54	71.58	15.54	8.18	4.70

井名	试验前黏度/（mPa·s）	试验后黏度/（mPa·s）
A井	8.32	7.79
B井	7.76	8.87
C井	4.62	4.45
F井	4.02	4.72
G井	7.26	6.87
H井	6.77	6.83

井名	试验前表面张力/（mN·m^-1）	试验后表面张力/（mN·m^-1）
A井	65.499	66.581
B井	63.695	61.560
C井	62.563	65.732
D井	67.831	69.298
F井	65.363	63.456
I井	63.778	66.783
