基于井间连通性的碳酸盐岩油藏注采关系优化

doi:10.7657/XJPG20210511

新疆石油地质 ›› 2021, Vol. 42 ›› Issue (5): 584-591.doi: 10.7657/XJPG20210511

基于井间连通性的碳酸盐岩油藏注采关系优化

雷昇¹(), 周玉辉¹(), 王宁^2a, 赛尔江·阿哈提^2b, 郑强^2a, 盛广龙¹

1. 长江大学石油工程学院,武汉 430100
2. 中国石油新疆油田分公司 a.勘探开发研究院；b.百口泉采油厂,新疆克拉玛依 834000

收稿日期:2020-09-09 修回日期:2020-11-09 出版日期:2021-10-01 发布日期:2021-09-28
通讯作者: 周玉辉 E-mail:779644318@qq.com;zhyhtree@163.com
作者简介:雷昇（1995-）,男,湖北潜江人,硕士研究生,油气田开发,（Tel）13125040083（E-mail） 779644318@qq.com
基金资助:
国家自然科学基金(51874044);国家科技重大专项(2016ZX05014)

Injection-Production Optimization of Carbonate Oil Reservoirs Based on a Well Connectivity Model

LEI Sheng¹(), ZHOU Yuhui¹(), WANG Ning^2a, Saierjiang AHATI^2b, ZHENG Qiang^2a, SHENG Guanglong¹

1. School of Petroleum Engineering, Yangtze University, Wuhan, Hubei 430100, China
2. PetroChina Xinjiang Oilfield Company, a.Research Institute of Exploration and Development; b.Baikouquan Oil Production Plant, Karamay, Xinjiang 834000, China

Received:2020-09-09 Revised:2020-11-09 Online:2021-10-01 Published:2021-09-28
Contact: ZHOU Yuhui E-mail:779644318@qq.com;zhyhtree@163.com

摘要/Abstract

摘要：

碳酸盐岩油藏储集层非均质性强,注水开发时注入水易沿高渗通道窜进,导致生产井发生水窜或水淹、含水率上升速度加快、开发效率低。基于井间连通性原理,根据缝洞型碳酸盐岩油藏的地质特征、开发动态等,可定量表征井间的连通性参数传导率和连通体积,构建碳酸盐岩纵向多层油藏井间连通性模型,进而获取油藏各层注水井平面注水劈分系数、注水利用率等。结合自动历史拟合方法和生产优化算法,实现对油水井生产动态的实时优化和预测。现场应用表明,该方法年增油1.1×10⁴ m³,具有较好的增油效果,对同类型油藏的高效开发有重要指导意义。

关键词: 碳酸盐岩油藏, 连通性, 传导率, 注水利用率, 注采关系优化

Abstract:

Carbonate oil reservoirs are very heterogeneous, so that injected water is easy to advance through high-permeability channels, and results in water channeling or flooding, and consequently fast rising water cut and low development effeciency in production wells. Based on the principle of well connectivity, and considering the geological features and development performance of fractured-vuggy carbonate oil reservoirs, parameters of well connectivity (conductivity and connected volume) were quantitatively characterized, then a vertical multi-layer well connectivity model was established, and parameters such as plane splitting coefficient and utilization rate of injected water were estimated for each layer of the oil reservoirs, and finally by using automatic history matching method and production optimization algorithm, real-time optimization and prediction of production performance of oil and water wells were realized. Field application has proved that the yearly incremental oil production is 1.1×10⁴ m³ by using this method and good effect has been obtained. The method has important guiding significance for efficient development of similar oil reservoirs.

Key words: carbonate oil reservoir, well connectivity, conductivity, utilization rate of injected water, injection-production optimization

中图分类号:

TE344

雷昇, 周玉辉, 王宁, 赛尔江·阿哈提, 郑强, 盛广龙. 基于井间连通性的碳酸盐岩油藏注采关系优化[J]. 新疆石油地质, 2021, 42(5): 584-591.

LEI Sheng, ZHOU Yuhui, WANG Ning, Saierjiang AHATI, ZHENG Qiang, SHENG Guanglong. Injection-Production Optimization of Carbonate Oil Reservoirs Based on a Well Connectivity Model[J]. Xinjiang Petroleum Geology, 2021, 42(5): 584-591.

图/表 8

图1

图2

图3

图4

图5

图6

参考文献 20

[1]	李红凯, 袁向春, 康志江. 缝洞型碳酸盐岩油藏储集体组合对注水开发效果的影响研究[J]. 科学技术与工程, 2013, 13(29):8 605-8 611.
	LI Hongkai, YUAN Xiangchun, KANG Zhijiang. Research of reservoir combinations to water-flooding development in fractured-cave carbonate reservoir[J]. Science Technology and Engineering, 2013, 13(29):8 605-8 611.
[2]	HEFFER K J, FOX R J, MCGILL C A, et al. Novel techniques show links between reservoir flow directionality,earth stress,fault structure and geomechanical changes in mature waterfloods[J]. Society of Petroleum Engineers Journal, 1997, 2(2):91-98.
[3]	SAYARPOUR M, KABIR S, SEPEHRNOORI K, et al. Probabilistic history matching with the capacitance resistance model in waterfloods:a precursor to numerical modeling[R]. SPE 129604,2010.
[4]	ZHAO Hui, KANG Zhijiang, ZHANG Xiansong, et al. A physics-based data-driven numerical model for reservoir history matching and prediction with a field application[J]. Society of Petroleum Engineers Journal, 2016, 21(6):2 175-2 194.
[5]	赵辉, 张兴凯, 王春友, 等. 基于连通性方法的油藏分层精细注水优化[J]. 长江大学学报(自科版), 2018, 15(23):42-51.
	ZHAO Hui, ZHANG Xingkai, WANG Chunyou, et al. Optimization of fine water injection for reservoir stratification based on connectivity method[J]. Journal of Yangtze University(Natural Science Edition), 2018, 15(23):42-51.
[6]	ZHAO Hui, LI Ying, CUI Shuyue, et al. History matching and production optimization of water flooding based on a data-driven interwell numerical simulation model[J]. Journal of Natural Gas Science and Engineering, 2016, 31:48-66. doi: 10.1016/j.jngse.2016.02.043
[7]	赵辉, 康志江, 张允, 等. 表征井间地层参数及油水动态的连通性计算方法[J]. 石油学报, 2014, 35(5):922-927.
	ZHAO Hui, KANG Zhijiang, ZHANG Yun, et al. An interwell connectivity numerical method for geological parameter characterization and oil-water two-phase dynamic prediction[J]. Acta Petrolei Sinica, 2014, 35(5):922-927.
[8]	ZHAO Hui, XU Lingfei, GUO Zhenyu, et al. A new and fast waterflooding optimization workflow based on INSIM-derived injection efficiency with a field application[J]. Journal of Petroleum Science and Engineering, 2019, 179:1 186-1 200. doi: 10.1016/j.petrol.2019.04.025
[9]	宋考平, 吴玉树, 计秉玉. 水驱油藏剩余油饱和度分布预测的ϕ函数法[J]. 石油学报, 2006, 27(3):91-95.
	SONG Kaoping, WU Yushu, JI Bingyu. A ϕ-function method for estimating distribution of residual oil saturation in water drive reservoir[J]. Acta Petrolei Sinica, 2006, 27(3):91-95.
[10]	沈文洁, 赵辉, 刘伟, 等. 基于连通性方法的缝洞型油藏优势窜流通道识别[J]. 断块油气田, 2018, 25(4):459-463.
	SHEN Wenjie, ZHAO Hui, LIU Wei, et al. Identification method of dominant channeling in fractured vuggy carbonate reservoir based on connectivity model[J]. Fault-Block Oil & Gas Field, 2018, 25(4):459-463.
[11]	金强, 田飞. 塔河油田岩溶型碳酸盐岩缝洞结构研究[J]. 中国石油大学学报(自然科学版), 2013, 37(5):15-21.
	JIN Qiang, TIAN Fei. Investigation of fracture-cave constructions of karsted cabonate reservoirs of Ordovician in Tahe oilfield,Tarim basin[J]. Journal of China University of Petroleum(Edition of Natural Science), 2013, 37(5):15-21.
[12]	黄勇, 王业飞, 孙致学, 等. 基于流线模拟的高含水油田注水效率优化[J]. 西安石油大学学报(自然科学版), 2017, 32(2):53-58.
	HUANG Yong, WANG Yefei, SUN Zhixue, et al. Optimization of water injection efficiency based on streamline simulation in high water cut stage[J]. Journal of Xi’an Shiyou University(Natural Science Edition), 2017, 32(2):53-58.
[13]	赵辉, 谢鹏飞, 曹琳, 等. 基于井间连通性的油藏开发生产优化方法[J]. 石油学报, 2017, 38(5):555-561.
	ZHAO Hui, XIE Pengfei, CAO Lin, et al. Reservoir production optimization method based on inter-well connectivity[J]. Acta Petrolei Sinica, 2017, 38(5):555-561.
[14]	赵辉, 康志江, 孙海涛, 等. 水驱开发多层油藏井间连通性反演模型[J]. 石油勘探与开发, 2016, 43(1):99-106.
	ZHAO Hui, KANG Zhijiang, SUN Haitao, et al. An interwell connectivity inversion model for waterflooded multilayer reservoirs[J]. Petroleum Exploration and Development, 2016, 43(1):99-106.
[15]	赵辉, 曹琳, 李阳, 等. 基于改进随机扰动近似算法的油藏生产优化[J]. 石油学报, 2011, 32(6):1 031-1 036.
	ZHAO Hui, CAO Lin, LI Yang, et al. Production optimization of oil reservoirs based on an improved simultaneous perturbation stochastic approximation algorithm[J]. Acta Petrolei Sinica, 2011, 32(6):1 031-1 036.
[16]	李红波, 王翠丽, 牛阁, 等. 有封闭水体的缝洞型油藏动态储量评价:以塔里木盆地哈拉哈塘油田为例[J]. 新疆石油地质, 2020, 41(3):321-325.
	LI Hongbo, WANG Cuili, NIU Ge, et al. Dynamic reserves evaluation of fractured-cavity reservoirs with closed water:a case from Halahatang oilfield,Tarim basin[J]. Xinjiang Petroleum Geology, 2020, 41(3):321-325.
[17]	李振华, 顾乔元, 张大鹏, 等. 塔里木油田碳酸盐岩油藏产量预测方法[J]. 新疆石油地质, 2019, 40(5):583-587.
	LI Zhenhua, GU Qiaoyuan, ZHANG Dapeng, et al. Production prediction methods for carbonate reservoirs in Tarim oilfield[J]. Xinjiang Petroleum Geology, 2019, 40(5):583-587.
[18]	邓兴梁, 罗新生, 刘永福, 等. 缝洞型碳酸盐岩定容油藏形成机理及开发技术[J]. 新疆石油地质, 2019, 40(1):79-83.
	DENG Xingliang, LUO Xinsheng, LIU Yongfu, et al. Forming mechanism and development measures of constant-volume fractured-vuggy carbonate oil reservoirs[J]. Xinjiang Petroleum Geology, 2019, 40(1):79-83.
[19]	张凯, 李阳, 姚军, 等. 油藏生产优化理论研究[J]. 石油学报, 2010, 31(1):78-83.
	ZHANG Kai, LI Yang, YAO Jun, et al. Theoretical research on production optimization of oil reservoirs[J]. Acta Petrolei Sinica, 2010, 31(1):78-83.
[20]	GUO Zhenyu, REYNOLDS A C. INSIM-FT in three-dimensions with gravity[J]. Journal of Computational Physics, 2019, 380:143-169. doi: 10.1016/j.jcp.2018.12.016
