Genesis of Tilted Oil-Water Contact of Heavy Oil Reservoir in Shawan Formation, Chunfeng Oilfield, Junggar Basin

doi:10.7657/XJPG20240209

Abstract

Abstract:

The oil-water relationship of the heavy oil reservoir in the first member of the Neogene Shawan formation （Sha 1 member） in Chunfeng oilfield is complex and cannot be explained from the traditional viewpoint of oil-water contact （OWC）, which affects the exploration and development process of the oilfield. Taking the P601-20 block with prominent contradiction in oil-water relationship as an example, researches on seismic-geology and pool-forming dynamics were conducted, and combining with the reservoir performance during development, the oil-water relationship of the heavy oil reservoir in Sha 1 member and its genesis were analyzed. It is found that the complex oil-water relationship in this oilfield is caused by the presence of a tilted OWC in the reservoir which is a structural-lithological reservoir with bottom/edge water. In terms of reservoir physical property, fault, formation pressure, tectonic movement, etc., the presence of the tilted OWC should be attributed to the adjustment of the reservoir due to tectonic movements, and the crude oil densification and flat strata intensified the lag of OWC adjustment. This reservoir can be classified as an unsteady oil and gas reservoir.

Key words: Junggar basin, Chepaizi swell, Chunfeng oilfield, Shawan formation, heavy oil reservoir, oil-water relationship, tilted oil-water contact, unsteady oil and gas reservoir

CLC Number:

TE122.3

ZHANG Deyao. Genesis of Tilted Oil-Water Contact of Heavy Oil Reservoir in Shawan Formation, Chunfeng Oilfield, Junggar Basin[J]. Xinjiang Petroleum Geology, 2024, 45(2): 205-212.

Figures/Tables 6

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Table 1.

Fig. 5.

References 21

[1]	何生, 叶加仁, 徐思煌, 等. 石油及天然气地质学[M]. 北京: 中国地质大学出版社, 2010.
	HE Sheng, YE Jiaren, XU Sihuang, et al. Petroleum and gas geology[M]. Beijing: China University of Geosciences Press, 2010.
[2]	赵晓东, 杨少春, 向奎, 等. 准噶尔盆地车北地区浅层砂岩油藏顶底双油水倒置成因[J]. 石油勘探与开发, 2014, 41(4):438-443.
	ZHAO Xiaodong, YANG Shaochun, XIANG Kui, et al. Oil-water inversion and its generation at top and bottom of the shallow sandstone reservoir in the northern Chepaizi area,Junggar basin,NW China[J]. Petroleum Exploration and Development, 2014, 41(4):438-443.
[3]	杨少春, 孟祥梅, 陈宁宁, 等. 准噶尔盆地车排子地区新近系沙湾组沉积特征[J]. 中国石油大学学报(自然科学版), 2011, 35(2):20-24.
	YANG Shaochun, MENG Xiangmei, CHEN Ningning, et al. Depositional characteristics of Shawan formation in Neogene of Chepaizi area,Junggar basin[J]. Journal of China University of Petroleum (Edition of Natural Science), 2011, 35(2):20-24.
[4]	向奎, 赵永福, 王建芳. 利用多种手段进行地层综合划分与对比:以准噶尔盆地春风油田主力稠油层层位归属为例[J]. 油气地质与采收率, 2011, 18(5):1-5.
	XIANG Kui, ZHAO Yongfu, WANG Jianfang. Stratigraphic division and correlation using various approaches: Case of stratigraphic correlation of heavy oil,Chunfeng oilfield,Junggar basin[J]. Petroleum Geology and Recovery Efficiency, 2011, 18(5):1-5.
[5]	樊晓伊. 准噶尔盆地春光探区古近系浅水辫状河三角洲沉积特征[J]. 特种油气藏, 2022, 29(4):47-54. doi: 10.3969/j.issn.1006-6535.2022.04.006
	FAN Xiaoyi. Sedimentary characteristics of Paleogene shallow braided river delta in Chunguang prospect area,Junggar basin[J]. Special Oil & Gas Reservoirs, 2022, 29(4):47-54.
[6]	张兴平, 任峤, 蒋旭东. 尚店油田东营组三角洲砂体沉积特征[J]. 大庆石油地质与开发, 2009, 23(6):1-2.
	ZHANG Xingping, REN Qiao, JIANG Xudong. Sedimentary features of delta sand bodies in Dongying formation of Shangdian oilfield[J]. Petroleum Geology and Oilfield Development in Daqing, 2009, 23(6):1-2.
[7]	吴元燕, 吴胜和, 蔡正旗, 等. 油矿地质学(第四版)[M]. 北京: 石油工业出版社, 2011.
	WU Yuanyan, WU Shenghe, CAI Zhengqi, et al. Industrial geology of petroleum (4th edition)[M]. Beijing: Petroleum Industry Press, 2011.
[8]	柳广弟, 张厚福. 石油地质学(第四版)[M]. 北京: 石油工业出版社, 2009.
	LIU Guangdi, ZHANG Houfu. Petroleum geology (4th edition)[M]. Beijing: Petroleum Industry Press, 2009.
[9]	肖正录, 路俊刚, 李勇, 等. 鄂尔多斯盆地延长组裂缝特征及控藏作用[J]. 新疆石油地质, 2023, 44(5):535-542.
	XIAO Zhenglu, LU Jungang, LI Yong, et al. Characteristics of fractures and their controls on Yanchang formation reservoir in Ordos basin[J]. Xinjiang Petroleum Geology, 2023, 44(5):535-542.
[10]	刘萍. 古龙凹陷姚一段致密油藏成藏主控因素及成藏模式[J]. 新疆石油地质, 2023, 44(6):635-646.
	LIU Ping. Controlling factors and models of hydrocarbon accumulation in tight oil reservoirs of Yao 1 member in Gulong sag[J]. Xinjiang Petroleum Geology, 2023, 44(6):635-646.
[11]	杨帆, 于兴河, 李胜利, 等. 低孔低渗构造岩性油藏油水倒置成因研究[J]. 中国矿业大学学报, 2010, 39(5):747-771.
	YANG Fan, YU Xinghe, LI Shengli, et al. Oil/water inversion and its genetic mechanism in the structural-lithologic reservoir of low-porosity and low permeability[J]. Journal of China University of Mining and Technology, 2010, 39(5):747-771.
[12]	孙龙德, 江同文, 徐汉林, 等. 非稳态成藏理论探索与实践[J]. 海相油气地质, 2008, 13(3):11-16.
	SUN Longde, JIANG Tongwen, XU Hanlin, et al. Exploration and practice for theory of unsteady-state hydrocarbon accumulation[J]. Marine Origin Petroleum Geology, 2008, 13(3):11-16.
[13]	江同文, 徐汉林, 练章贵, 等. 倾斜油水界面成因分析与非稳态成藏理论探索[J]. 西南石油大学学报, 2008, 30(5):1-5.
	JIANG Tongwen, XU Hanlin, LIAN Zhanggui, et al. Origin of tilted oil-water contact and probe into the theory of unsteady hydrocarbon accumulation[J]. Journal of Southwest Petroleum University, 2008, 30(5):1-5.
[14]	孙龙德, 江同文, 徐汉林, 等. 塔里木盆地哈得逊油田非稳态油藏[J]. 石油勘探与开发, 2009, 36(1):62-67.
	SUN Longde, JIANG Tongwen, XU Hanlin, et al. Unsteady reservoir in Hadson oilfield,Tarim basin[J]. Petroleum Exploration and Development, 2009, 36(1):62-67. doi: 10.1016/S1876-3804(09)60111-7
[15]	杜洋, 衣英杰, 辛军, 等. 伊朗SA油田Sarvak油藏大幅度倾斜油水界面成因探讨[J]. 石油实验地质, 2015, 37(2):187-193.
	DU Yang, YI Yingjie, XIN Jun, et al. Genesis of large-amplitude tilting oil-water contact in Sarvak formation in south Azadegan oilfield,Iran[J]. Petroleum Geology and Experiment, 2015, 37(2):187-193.
[16]	刘得光, 倪云燕, 陈建平, 等. 准噶尔盆地西北缘车排子凸起原油类型与油源[J]. 地质学报, 2023, 97(5):1576-1597.
	LIU Deguang, NI Yunyan, CHEN Jianping, et al. Types and sources of crude oil in the Chepaizi uplift,northwest margin of the Junggar basin[J]. Acta Geologica Sinica, 2023, 97(5):1576-1597.
[17]	张枝焕, 刘洪军, 李伟, 等. 准噶尔盆地车排子地区稠油成因及成藏过程[J]. 地球科学与环境学报, 2014, 36(2):18-32.
	ZHANG Zhihuan, LIU Hongjun, LI Wei, et al. Origin and accumlation process of heavy oil in Chepaizi area of Junggar basin[J]. Journal of Earth Sciences and Environment, 2014, 36(2):18-32.
[18]	商丰凯. 叠合盆地凸起区多期复杂断裂特征及形成机制:以准噶尔盆地车排子凸起为例[J]. 断块油气田, 2020, 27(3):278-283.
	SHANG Fengkai. Characteristics and formation mechanism of multi-stage complex fault system of uplift in superimposed basin:A case study of Chepaizi uplift,Junggar basin,NW China[J]. Fault-block Oil and Gas Field, 2020, 27(3):278-283.
[19]	董臣强. 准噶尔盆地车排子地区成藏特征分析[J]. 油气地球物理, 2008, 6(4):34-37.
	DONG Chenqiang. The analysis of the reservoir-forming characteristics of the Chepaizi area in Zhugar basin[J]. Petroleum Geophysics, 2008, 6(4):34-37.
[20]	胡秋媛, 董大伟, 赵利, 等. 准噶尔盆地车排子凸起构造演化特征及其成因[J]. 石油与天然气地质, 2016, 37(4):556-564.
	HU Qiuyuan, DONG Dawei, ZHAO Li, et al. Tectonic evolutionary characteristics and their causes of Chepaizi uplift in Junggar basin[J]. Oil and Gas Geology, 2016, 37(4):556-564.
[21]	宁方兴. 济阳拗陷地层油气藏成藏动力与含油高度预测[J]. 新疆石油天然气, 2010, 6(3):34-37.
	NING Fangxing. Research on reservoir-forming dynamics and oil-bearing prediction of the stratigraphic hydrocarbon reservoir in Jiyang depression[J]. Xinjiang Oil and Gas, 2010, 6(3):34-37.

井名	油水界面/m		井名	油水界面/m		井名	油水界面/m
井名	测深	海拔	井名	测深	海拔	井名	测深	海拔
P601-P420DY井	410.3	-122.8	P601-28井	431.7	-145.7	P601-25井	466.8	-178.1
P601-22井	413.0	-126.0	P601-24井	437.3	-149.1	P601-JX11井	472.6	-181.8
P601-27井	423.5	-138.3	P601-20井	442.9	-156.5	P601-21井	486.0	-199.2
P601-X467井	473.0	-139.8	P601-525井	453.5	-167.4	P611井	487.8	-200.3
P601-23井	425.3	-140.5	P601-26井	456.0	-168.4	P601-J12井	499.3	-210.4
