Exploration Practice and Total Petroleum System in Residual Marine Sag，Eastern Junggar Basin

doi:10.7657/XJPG20240201

Abstract

Abstract:

The Shiqiantan sag in the eastern Junggar basin is a residual marine sag. In recent years, high-yield natural gas have been obtained from many wells in the Shiqiantan formation, and oil and gas shows have been observed in different strata across the sag, indicating its excellent exploration potential and characteristics as a total petroleum system. Based on seismic, drilling, logging, and organic geochemical data, the formation and evolution of the Shiqiantan sag, the conditions for the formation of the total petroleum system, and the models of hydrocarbon accumulation are studied. The results show that during the Late Carboniferous the north Tianshan oceanic crust subduction and seawater intrusion in the region led to the development of terrigenous, marine, medium- to high-quality source rocks which are now in the mature- to high-mature stage. The reservoir contains volcanic rocks in the Carboniferous strata, marine clastic rocks in the Shiqiantan formation, and continental clastic rocks in the Permian Jingou formation, in all of which hydrocarbons were accumulated. Controlled by the hydrocarbon generation and evolution in the source rocks of the Shiqiantan formation and the characteristics of multiple types of reservoirs, a distribution pattern of shale gas reservoir in the sag-tight oil and gas reservoir in the slope-conventional oil and gas reservoir in the high position is formed, showing a total petroleum system featured with orderly symbiosis of unconventional and conventional oil and gas reservoirs. According to the theory of total petroleum system, the exploration in the Shiqiantan sag should focus on tight oil and gas reservoirs in the near-source slope area, structural-lithological oil and gas reservoirs and volcanic weathering-crust oil and gas reservoirs in the above-source fault-terrace area and structural high, and marine shale gas reservoirs within the source. The Carboniferous near-source favorable lithofacies belts, piedmont thrust fault-concealed structures, intra-basin palaeouplifts, and slope areas are favorable exploration zones in northern Xinjiang. Specifically, exploration efforts should be made towards shale oil and gas reservoirs within the sag, tight sandstone oil and gas reservoirs around the sag, conventional oil and gas reservoirs in the structural highs, and volcanic weathering-crust oil and gas reservoirs in uplifted areas.

Key words: Junggar basin, Shiqiantan sag, Carboniferous, residual marine, Shiqiantan formation, oil and gas exploration, total petroleum system

CLC Number:

TE121.1

ZHI Dongming, CHEN Xuan, YANG Runze, LIU Juntian, YU Haiyue, MA Qiang. Exploration Practice and Total Petroleum System in Residual Marine Sag，Eastern Junggar Basin[J]. Xinjiang Petroleum Geology, 2024, 45(2): 127-138.

Figures/Tables 11

Fig. 1.

Fig. 2.

Fig. 3.

Table 1.

Fig. 4.

Table 2.

Fig. 5.

Fig. 6.

Table 3.

Fig. 7.

Fig. 8.

References 29

[1]	贺凯, 李培俊, 何贤英, 等. 北三台地区石炭系成藏条件及勘探方向[J]. 新疆石油地质, 2001, 22(5):421-423.
	HE Kai, LI Peijun, HE Xianying, et al. The reservoir-formed conditions and exploration target of Carboniferous in Beisantai area[J]. Xinjiang Petroleum Geology, 2001, 22(5):421-423.
[2]	陈军, 陈静, 李娜, 等. 准噶尔盆地东部石炭系天然气勘探潜力[J]. 天然气地球科学, 2020, 31(7):952-961.
	CHEN Jun, CHEN Jing, LI Na, et al. The exploration potential of Carboniferous gas in the eastern Junggar basin[J]. Natural Gas Geoscience, 2020, 31(7):952-961.
[3]	王伟锋, 张仲达. 准噶尔盆地五彩湾地区石炭系烃源岩演化及油气成藏过程[J]. 天然气地球科学, 2019, 30(4):447-455.
	WANG Weifeng, ZHANG Zhongda. Evolution of Carboniferous source cocks and hydrocarbon accumulation process in the area of the Wucaiwan area in Junggar basin[J]. Natural Gas Geoscience, 2019, 30(4):447-455.
[4]	董雪梅, 徐怀民, 贺陆明, 等. 克拉麦里石炭系火山岩气田的高效勘探开发[J]. 新疆石油地质, 2012, 33(2):214-217.
	DONG Xuemei, XU Huaimin, HE Luming, et al. Efficient exploration and development of Carboniferous volcanic gas field in Kelameili area in Junggar basin[J]. Xinjiang Petroleum Geology, 2012, 33(2):214-217.
[5]	杨帆, 宋永, 陈洪, 等. 准噶尔盆地阜东地区石炭系松喀尔苏组烃源岩评价及气源对比[J]. 天然气地球科学, 2019, 30(7):1018-1026.
	YANG Fan, SONG Yong, CHEN Hong, et al. Evaluation of Carboniferous Songkaersu formation source rocks and gas source correlation in the Fukang sag of eastern Junggar basin[J]. Natural Gas Geoscience, 2019, 30(7):1018-1026.
[6]	武小宁, 邓勇, 刘啸虎, 等. 准东石炭系烃源岩分布及勘探潜力分析[J]. 西南石油大学学报(自然科学版), 2022, 44(4):14-26. doi: 10.11885/j.issn.1674-5086.2020.11.18.02
	WU Xiaoning, DENG Yong, LIU Xiaohu, et al. An analysis of distribution of Carboniferous source rocks and exploration potential analysis in eastern Junggar basin[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2022, 44(4):14-26.
[7]	邹才能, 杨智, 朱如凯, 等. 中国非常规油气勘探开发与理论技术进展[J]. 地质学报, 2015, 89(6):979-1007.
	ZOU Caineng, YANG Zhi, ZHU Rukai, et al. Progress in China’s unconventional oil & gas exploration and development and theoretical technologies[J]. Acta Geologica Sinica, 2015, 89(6):979-1007.
[8]	贾承造. 论非常规油气对经典石油天然气地质学理论的突破及意义[J]. 石油勘探与开发, 2017, 44(1):1-11. doi: 10.11698/PED.2017.01.01
	JIA Chengzao. Breakthrough and significance of unconventional oil and gas to classical petroleum geological theory[J]. Petroleum Exploration and Development, 2017, 44(1):1-11. doi: 10.1016/S1876-3804(17)30002-2
[9]	高俊, 江拓, 王信水, 等. 准噶尔—天山—北山蛇绿岩:对中亚造山带西南缘洋陆格局演化的制约[J]. 地质科学, 2022, 57(1):1-42.
	GAO Jun, JIANG Tuo, WANG Xinshui, et al. The Junggar,Tianshan and Beishan ophiolites:Constraint on the evolution of oceanic and continental framework along the southwestern margin of the Central-Asian orogenic belt[J]. Chinese Journal of Geology, 2022, 57(1):1-42.
[10]	LI Di, HE Dengfa, YANG Hao, et al. Diverse origins of Late Paleozoic calc-alkaline magmatic rocks from the Bogda tectonic belt:Implications for the geodynamic evolution of the eastern Tianshan,NW China[J]. Lithos, 2021, 404/405:106442. doi: 10.1016/j.lithos.2021.106442
[11]	康积伦, 付国斌, 韩成, 等. 准噶尔盆地东部隆起石钱滩凹陷石钱滩组层序划分[J]. 新疆石油地质, 2023, 44(3):265-276.
	KANG Jilun, FU Guobin, HAN Cheng, et al. Sequence division of Shiqiantan formation in Shiqiantan sag on eastern uplift of Junggar basin[J]. Xinjiang Petroleum Geology, 2023, 44(3):265-276.
[12]	王治平, 冯庆来. 新疆准噶尔石钱滩组的生物群沉积环境及生物区系特征[J]. 地球科学:中国地质大学学报, 1992, 17(3):281-288.
	WANG Zhiping, FENG Qinglai. On faunas,sedimental encironment and palaeobiogengraphy of Shiqiantan formation,Junggar,Xinjiang[J]. Earth Science:Journal of China University if Geosciences, 1992, 17(3):281-288.
[13]	罗旭东, 邓世坤, 冯芸, 等. 火山岩储层分类方法在克百断裂带一区石炭系的应用[J]. 特种油气藏, 2023, 30(1):57-64. doi: 10.3969/j.issn.1006-6535.2023.01.008
	LUO Xudong, DENG Shikun, FENG Yun, et al. Application of volcanic rock reservoir classification method to Carboniferous system in Kebai fault area 1[J]. Special Oil & Gas Reservoirs, 2023, 30(1):57-64.
[14]	匡立春, 吕焕通, 王绪龙, 等. 准噶尔盆地天然气勘探实践与克拉美丽气田的发现[J]. 天然气工业, 2010, 30(2):1-6.
	KUANG Lichun, LYU Huantong, WANG Xulong, et al. Exploration of volcanic gas reservoirs and discovery of the Kelameili gas field in the Junggar basin[J]. Natural Gas Industry, 2010, 30(2):1-6.
[15]	雷丹凤, 李熙喆, 位云生, 等. 海相页岩有效产气储层特征:以四川盆地五峰组—龙马溪组页岩为例[J]. 中国矿业大学学报, 2019, 48(2):333-343.
	LEI Danfeng, LI Xizhe, WEI Yunsheng, et al. Characteristics of effective gas-producing reservoirs in marine shale:A case study of the Wufeng-Longmaxi shales in Sichuan basin[J]. Journal of China University of Mining & Technology, 2019, 48(2):333-343.
[16]	王玉满, 黄金亮, 王淑芳, 等. 四川盆地长宁、焦石坝志留系龙马溪组页岩气刻度区精细解剖[J]. 天然气地球科学, 2016, 27(3):423-432.
	WANG Yuman, HUANG Jinliang, WANG Shufang, et al. Dissection of two calibrated areas of the Silurian Longmaxi formation,Changning and Jiaoshiba,Sichuan basin[J]. Natural Gas Geoscience, 2016, 27(3):423-432.
[17]	梁峰, 姜巍, 戴赟, 等. 四川盆地威远—资阳地区筇竹寺组页岩气富集规律及勘探开发潜力[J]. 天然气地球科学, 2022, 33(5):755-763.
	LIANG Feng, JIANG Wei, DAI Yun, et al. Enrichment law and potential of shale gas of Qiongzhusi formation in Weiyuan-Ziyang areas,Sichuan basin[J]. Natural Gas Geoscience, 2022, 33(5):755-763.
[18]	刘小洪, 冯明友, 郗爱华, 等. 克拉美丽气田滴西地区石炭系火山岩储层成岩作用及孔隙演化[J]. 岩性油气藏, 2016, 28(1):38-48.
	LIU Xiaohong, FENG Mingyou, XI Aihua, et al. Diagenesis and pore evolution of Carboniferous volcanic reservoirs in Dixi area,Kelameili gas field[J]. Lithologic Reservoirs, 2016, 28(1):38-48.
[19]	唐勇, 雷德文, 曹剑, 等. 准噶尔盆地二叠系全油气系统与源内天然气勘探新领域[J]. 新疆石油地质, 2022, 43(6):654-662.
	TANG Yong, LEI Dewen, CAO Jian, et al. Total petroleum system and inner-source natural gas exploration in Permian strata of Junggar basin[J]. Xinjiang Petroleum Geology, 2022, 43(6):654-662.
[20]	庞雄奇, 贾承造, 宋岩, 等. 全油气系统定量评价:方法原理与实际应用[J]. 石油学报, 2022, 43(6):727-759. doi: 10.7623/syxb202206001
	PANG Xiongqi, JIA Chengzao, SONG Yan, et al. Quantitative evaluation of whole petroleum system:Principle and application[J]. Acta Petrolei Sinica, 2022, 43(6):727-759. doi: 10.7623/syxb202206001
[21]	金之钧, 张一伟, 王捷. 油气成藏机理与分布规律[M]. 北京: 石油工业出版社, 2003.
	JIN Zhijun, ZHANG Yiwei, WANG Jie. Hydrocarbon accumulation mechanisms and oil/gas distribution[M]. Beijing: Petroleum Industry Press, 2003.
[22]	支东明, 唐勇, 何文军, 等. 准噶尔盆地玛湖凹陷风城组常规-非常规油气有序共生与全油气系统成藏模式[J]. 石油勘探与开发, 2021, 48(1):38-51. doi: 10.11698/PED.2021.01.04
	ZHI Dongming, TANG Yong, HE Wenjun, et al. Orderly coexistence and accumulation models of conventional and unconventional hydrocarbons in Lower Permian Fengcheng formation,Mahu sag,Junggar basin[J]. Petroleum Exploration and Development, 2021, 48(1):38-51.
[23]	支东明, 李建忠, 杨帆, 等. 准噶尔盆地吉木萨尔凹陷二叠系全油气系统地质特征与勘探开发实践[J]. 中国石油勘探, 2023, 28(4):14-23. doi: 10.3969/j.issn.1672-7703.2023.04.002
	ZHI Dongming, LI Jianzhong, YANG Fan, et al. Geological characteristics and exploration and development practice of the Permian full oil and gas system in Jimsar sag,Junggar basin[J]. China Petroleum Exploration, 2023, 28(4):14-23. doi: 10.3969/j.issn.1672-7703.2023.04.002
[24]	张赫, 王小军, 贾承造, 等. 松辽盆地北部中浅层全油气系统特征与油气成藏聚集模式[J]. 石油勘探与开发, 2023, 50(4):683-694. doi: 10.11698/PED.20230054
	ZHANG He, WANG Xiaojun, JIA Chengzao, et al. Total petroleum system and hydrocarbon accumulation model in shallow and medium strata in northern Songliao basin,NW China[J]. Petroleum Exploration and Development, 2023, 50(4):683-694.
[25]	姜福杰, 郭婧, 庞雄奇, 等. 渤海湾盆地南堡凹陷全油气系统3类油气资源联合评价[J]. 石油学报, 2023, 44(9):1472-1486. doi: 10.7623/syxb202309006
	JIANG Fujie, GUO Jing, PANG Xiongqi, et al. Joint evaluation of three types of oil-gas resources in whole petroleum system of Nanpu sag,Bohai Bay basin[J]. Acta Petrolei Sinica, 2023, 44(9):1472-1486.
[26]	姜福杰, 贾承造, 庞雄奇, 等. 鄂尔多斯盆地上古生界全油气系统成藏特征与天然气富集地质模式[J]. 石油勘探与开发, 2023, 50(2):250-261. doi: 10.11698/PED.20220602
	JIANG Fujie, JIA Chengzao, PANG Xiongqi, et al. Upper Paleozoic total petroleum system and geological model of natural gas enrichment in Ordos basin,NW China[J]. Petroleum Exploration and Development, 2023, 50(2):250-261.
[27]	周兴熙. 成藏要素的时空结构与油气富集:兼论近源富集成藏[J]. 石油与天然气地质, 2005, 26(6):711-716.
	ZHOU Xingxi. Time-space structure of reservoiring elements and hydrocarbon enrichment:Concurrently discussing near-source reservoiring[J]. Oil & Gas Geology, 2005, 26(6):711-716.
[28]	LI Di, HE Dengfa, TANG Yong, et al. Reconstructing multiple arc-basin systems in the Altai-Junggar area (NW China):Implications for the architecture and evolution of the western Central Asian orogenic belt[J]. Journal of Asian Earth Sciences, 2016, 121:84-107. doi: 10.1016/j.jseaes.2016.02.010
[29]	杨有星, 张君峰, 张金虎, 等. 新疆博格达山周缘中上二叠统与中上三叠统沉积特征及其主控因素[J]. 石油勘探与开发, 2022, 49(4):670-682. doi: 10.11698/PED.20210611
	YANG Youxing, ZHANG Junfeng, ZHANG Jinhu, et al. Sedimentary characteristics and main controlling factors of the Middle-Upper Permian and Middle-Upper Triassic around Bogda mountain of Xinjiang,NW China[J]. Petroleum Exploration and Development, 2022, 49(4):670-682.

井名	层位	生烃潜量/（mg·g^-1）	热解峰温/℃	总有机碳含量/%	氢指数/（mg·g^-1）	氯仿沥青“A”含量/%
石钱1井	石钱滩组二段	（0.12~1.07）0.61	（473~492）479	（0.17~2.48）1.31	（27.1~53.2）37.3	0.04
石钱1井	石钱滩组一段	（0.10~1.72）0.79	（433~510）489	（0.11~6.68）3.66	（12.1~72.7）20.7	0.05
石钱2井	石钱滩组二段	（1.12~2.31）1.75	（452~453）452	（1.23~1.83）1.62	（68.3~95.2）79.9
石钱4井	石钱滩组二段	（0.81~3.31）1.61	（464~472）469	（0.78~1.93）1.19	（80.8~131.1）98.5	（0.05~0.11）0.06
石钱4井	石钱滩组一段	（2.04~9.33）4.30	（451~479）473	（2.21~6.21）3.23	（70.5~136.9）107.9	（0.12~0.51）0.29
石钱201井	石钱滩组二段	（3.44~4.49）3.92	（462~473）469	（0.78~1.93）1.19	（80.8~131.1）98.5
石钱3井	石钱滩组一段	（0.93~2.15）1.45	（482~492）487	（1.08~2.33）1.55	（4.9~105.9）48.1

构造或地区	构造背景	区域构造应力类型	优质页岩埋深/m	优质页岩厚度/m	总有机碳含量/%	孔隙度/ %	总含气量/ （m³·t^-1）	压力系数	天然裂缝发育情况
石钱滩凹陷	凹陷斜坡区	挤压	2 600~4 100	50~120	1.0~6.6	2.2~5.1	2.3~4.6	1.09~1.33	较为发育
长宁示范区	向斜北翼平缓斜坡带	挤压	2 450~2 650	30~46	2.8~6.3	2.9~5.1	2.2~5.5	1.30~2.02	局部发育
威远示范区	古隆起斜坡区	挤压	1 800~3 697	24~40	2.2~5.3	2.4~5.9	2.5~4.4	1.40~1.95	局部发育
涪陵焦石坝	箱状背斜	挤压为主	2 100~2 500	30~45	2.0~8.0	4.0~7.0	4.7~5.7	1.35~1.65	发育
昭通示范区	向斜轴部—背斜北斜坡带	压扭（走滑+挤压）	2 030~2 950	31~38	2.1~6.7	2.0~5.0	2.0~4.5	1.60~1.96	较发育

样品来源	包裹体类型	宿主矿物	均一温度/℃	冰点温度/℃	盐度/%	捕获压力/MPa	成藏期次
石钱1井、石钱3井、石钱4井	油包裹体伴生盐水包裹体	石英加大边和石英内裂纹	90.5~109.8	-1.2~-0.7	1.2~2.1	18.4~20.6	Ⅰ
石钱1井、石钱3井、石钱4井	油包裹体伴生盐水包裹体	石英加大边和石英内裂纹	165.9~183.3	-1.9	3.2	42.5~45.8	Ⅱ
