稠油底水油藏水平井分段完井方法及应用

doi:10.7657/XJPG20200216

摘要/Abstract

摘要：

分段完井可以有效缓解水平井过早见水,调整水平井产液剖面。利用渗流力学理论、油藏工程方法、聚类分析方法、油藏数值模拟等,建立一套底水油藏水平井分段完井和优化配产方案。首先,综合考虑储集层非均质性、压力系统、避水高度和完井成本,利用聚类分析方法对水平井进行合理分段;然后,通过油藏渗流和井筒管流耦合模型,以各段均衡产液为原则,计算最优附加阻力;最后,利用油藏数值模拟结果,对分段完井和传统裸眼完井进行对比,验证该方法的可靠性。研究结果在曹妃甸油田群和秦皇岛32-6油田得到广泛应用,水平井平均见水时间推迟152 d,提高采收率3%~5%.

关键词: 渤海油田, 稠油底水油藏, 水平井, 分段完井, 完井成本, 附加阻力

Abstract:

Segmented well completion technology can cope with the problems of early water breakthrough and liquid profile modification in horizontal wells. The paper establishes a set of methods of segmented well completion and optimized production allocation in horizontal wells in the reservoirs with bottom water by using flowing mechanics theory, reservoir engineering method, clustering analysis method and reservoir numerical simulation. Firstly, based on the comprehensive consideration of reservoir heterogeneity, pressure system, water avoidance height and well completion cost, a horizontal well is reasonably segmented by using clustering analysis method. Then the optimum additional resistance is calculated on the basis of a seepage-pipe coupling model and the principle of balanced liquid production in each segment. Finally, reservoir numerical simulation is used to compare the results of segmented well completion and conventional open-hole completion to verify the reliability of the method. The actual applications of the method in Caofeidian oilfields and Qinhuangdao 32-6 oilfield show that the average water breakthrough time is delayed by 152 days and the recovery factor can be improved by 3%-5%.

Key words: Bohai oilfield, heavy oil reservoir with bottom water, horizontal well, segmented well completion, well completion cost, additional resistance

中图分类号:

TE345

石洪福. 稠油底水油藏水平井分段完井方法及应用[J]. 新疆石油地质, 2020, 41(2): 232-236.

SHI Hongfu. A Method and Application of Horizontal Well Segmentation in Heavy Oil Reservoirs With Bottom Water[J]. Xinjiang Petroleum Geology, 2020, 41(2): 232-236.

图/表 3

参考文献 18

[1]	郭太现, 杨庆红, 黄凯 , 等. 海上河流相油田高效开发技术[J]. 石油勘探与开发, 2013,40(6):708-714.
	GUO Taixian, YANG Qinghong, HUANG Kai , et al. Techniques for high-efficient development of offshore fluvial oilfields[J]. Petroleum Exploration and Development, 2013,40(6):708-714.
[2]	苏彦春, 李廷礼 . 海上砂岩油田高含水期开发调整实践[J]. 中国海上油气, 2016,28(3):83-90.
	SU Yanchun, LI Tingli . Practice of development adjustment in offshore sandstone oilfileds in high water cut stage[J]. China Offshore Oil and Gas, 2016,28(3):83-90.
[3]	王家禄, 刘玉章, 江如意 , 等. 水平井开采底水油藏水脊脊进规律的物理模拟[J]. 石油勘探与开发, 2007,34(5):590-593.
	WANG Jialu, LIU Yuzhang, JIANG Ruyi , et al. 2-D physical modeling of water coning of horizontal well production in bottom water driving reservoirs[J]. Petroleum Exploration and Development, 2007,34(5):590-593.
[4]	PERMADI P, LEE R L, KARTOATMODJO R S T . Behavior of water cresting under horizontal wells[C]. SPE Annual Technical Conference and Exhibition. Dallas,Texas:Society of Petroleum Engineers, 1995.
[5]	WIBOWO W, PERMADI P, MARDISEWOJO P , et al. Behavior of water cresting and production performance of horizontal well in bottom water drive reservoir:a scaled model study [R]. SPE 87046, 2004.
[6]	刘建国, 王勤田, 杨志军 , 等. 底水油藏水平井开采物理模拟试验研究[J]. 石油天然气学报, 2010,32(1):145-147.
	LIU Jianguo, WANG Qintian, YANG Zhijun , et al. Physical simulation experiment of horizontal well production in reservoirs with bottom water[J]. Journal of Oil and Gas Technology, 2010,32(1):145-147.
[7]	熊军, 何汉平, 熊友明 , 等. 水平井分段完井参数对底水脊进影响[J]. 天然气地球科学, 2013,24(6):1 232-1 237.
	XIONG Jun, HE Hanping, XIONG Youming , et al. The effect of partial completion parameters in horizontal well on water coning[J]. Natural Gas Geoscience, 2013,24(6):1 232-1 237.
[8]	饶富培, 董云龙, 吴杰生 , 等. 大港油田底水油藏水平井控水完井工艺[J]. 石油钻采工艺, 2010,32(3):107-109.
	RAO Fupei, DONG Yunlong, WU Jiesheng , et al. Technology of water control and well completion of horizontal wells in bottom water reservoir in Dagang oilfield[J]. Oil Drilling & Production Technology, 2010,32(3):107-109.
[9]	罗伟, 林永茂, 李海涛 , 等. 非均质底水油藏水平井ICD完井优化设计[J]. 石油学报, 2017,38(10):1 200-1 209.
	LUO Wei, LIN Yongmao, LI Haitao , et al. ICD completion optimization design of horizontal wells in heterogeneous bottom-water reservoirs[J]. Acta Petrolei Sinica, 2017,38(10):1 200-1 209.
[10]	范子菲, 方宏长, 俞国凡 . 水平井水平段最优长度设计方法研究[J]. 石油学报, 1997,18(1):55-62.
	FAN Zifei, FANG Hongchang, YU Guofan . A study on design method of optimal horizontal wellbore length[J]. Acta Petrolei Sinica, 1997,18(1):55-62.
[11]	刘想平, 蒋志祥, 江如意 , 等. 射孔完井的水平井向井流动态关系[J]. 石油勘探与开发, 1999,26(2):71-74.
	LIU Xiangping, JIANG Zhixiang, JIANG Ruyi , et al. Inflow performance relationship for perforated horizontal wells[J]. Petroleum Exploration and Development , 1999,26(2):71-74.
[12]	王大为, 李晓平 . 水平井水平段长度优化原则[J]. 新疆石油地质, 2011,32(2):163-166.
	WANG Dawei, LI Xiaoping . Optimization principles for horizontal wellbore length[J]. Xinjiang Petroleum Geology, 2011,32(2):163-166.
[13]	刘振平, 刘启国, 王宏玉 , 等. 底水油藏水平井水脊脊进规律[J]. 新疆石油地质, 2015,36(1):86-89.
	LIU Zhenping, LIU Qiguo, WANG Hongyu , et al. Water coning laws of horizontal well production in bottom water reservoirs[J]. Xinjiang Petroleum Geology, 2015,36(1):86-89.
[14]	周代余, 江同文, 冯积累 , 等. 底水油藏水平井水淹动态和水淹模式研究[J]. 石油学报, 2004,25(6):73-77.
	ZHOU Daiyu, JIANG Tongwen, FENG Jilei , et al. Waterflooding performance and pattern in horizontal well with bottom water reservoir[J]. Acta Petrolei Sinica, 2004,25(6):73-77.
[15]	程林松, 郎兆新, 张丽华 . 底水驱油藏水平井锥进的油藏工程研究[J]. 石油大学学报(自然科学版), 1994,18(4):43-47.
	CHENG Linsong, LANG Zhaoxin, ZHANG Lihua . Reservoir engineering problem of horizontal wells coning in bottom-water driven reservoir[J]. Journal of the University of Petroleum,China, 1994,18(4):43-47.
[16]	郭长永, 熊启勇, 邓伟兵 , 等. 底水油藏水平井水平段动用状况预测方法[J]. 新疆石油地质, 2019,40(4):468-472.
	GUO Changyong, XIONG Qiyong, DENG Weibing , et al. Methods to predict horizontal section producing status of horizontal wells in reservoirs with bottom water[J]. Xinjiang Petroleum Geology, 2019,40(4):468-472.
[17]	张利军, 朱国金, 王帅 , 等. 河流相储集层砂体构型试井响应图版[J]. 新疆石油地质, 2018,39(3):367-371.
	ZHANG Lijun, ZHU Guojin, WANG Shuai , et al. Well test response charts of sand body configuration in fluvial facies reservoirs[J]. Xinjiang Petroleum Geology, 2018,39(3):367-371.
[18]	刘旺东, 杨智刚 , 艾尼·买买提,等.阿里斯库姆大气顶薄油环边底水油田开发方式[J]. 新疆石油地质, 2018,39(5):622-626.
	LIU Wangdong, YANG Zhigang, Aini MAIMAITI , et al. Development methods of Aryskum oilfield with large gas cap,thin oil rim and edge/bottom water[J]. Xinjiang Petroleum Geology, 2018,39(5):622-626.
