珠江口盆地阳江东凹断层特征及其对油气成藏的影响

doi:10.7657/XJPG20200405

摘要/Abstract

摘要：

珠江口盆地阳江东凹断层发育,所发现的油气与断层密切相关。通过区域地质背景、地震、钻井等资料,对阳江东凹的断层特征及其对油气成藏的影响进行了总结与分析。阳江东凹发育“下断上拗”2套断层系统,根据断层的规模、发育时间、作用等特征,可划分为一级控洼断层、二级控圈断层和三级调节断层;根据断层的发育期次,可划分为早期型断层、长期型断层和晚期型断层3种类型。断层的发育和演化对阳江东凹圈闭形成、油气运移和侧向封堵具有控制作用。一级控洼断层和二级控圈断层控制了凹陷内二级构造带及构造圈闭的形成;Ⅰ类、Ⅱ类和Ⅲ类输导断层的垂向输导能力有较大差异,其中Ⅰ类输导断层输导能力最强,可将油气垂向运移至1 500 m以浅;北西—南东走向的张扭性断层侧向封堵能力好,利于油气规模富集。

关键词: 珠江口盆地, 阳江东凹, 断层, 油气运移, 圈闭, 成藏, 控藏

Abstract:

Faults are developed in the eastern Yangjiang sag of Pearl River Mouth basin, and the discovered hydrocarbon in the sag is closely related to faults. Based on the regional geological setting, seismic and drilling data, fault characteristics and its impacts are summarized and analyzed. Two sets of fault systems, namely “lower fault and upper depression”, are developed in the eastern Yangjaing sag. According to fault scale, development time and impact, the faults in the sag are divided into first-class fault controlling sags, second-class fault controlling traps and third-class accommodation fault. According to fault development stage, the faults are divided into early fault, long-term fault and late faults. The development and evolution of the faults control the formation of traps, hydrocarbon migration and lateral sealing. The formation of secondary structural belts and structural traps in the sag are controlled by the first-class faults controlling sags and second-class faults controlling traps. TypeⅠ, typeⅡ and typeⅢ transporting faults have greatly different vertical delivery capabilities, among which the typeⅠhas the strongest delivery capability and can vertically transport oil and gas to the strata with the depth of 1500 m or less. The NW-SE trending faults are compressional and have good lateral sealing ability, which are favorable for large scaled petroleum accumulation.

Key words: Pearl River Mouth basin, eastern Yangjiang sag, fault, hydrocarbon migration, trap, petroleum accumulation, controlling factor

中图分类号:

TE112.4

杜晓东, 彭光荣, 吴静, 张志伟, 许新明, 朱定伟. 珠江口盆地阳江东凹断层特征及其对油气成藏的影响[J]. 新疆石油地质, 2020, 41(4): 414-421.

DU Xiaodong, PENG Guangrong, WU Jing, ZHANG Zhiwei, XU Xinming, ZHU Dingwei. Faults and Its Impacts on Petroleum Accumulation in Eastern Yangjiang Sag, Pearl River Mouth Basin[J]. Xinjiang Petroleum Geology, 2020, 41(4): 414-421.

图/表 9

图1

图2

图3

表1

图4

图5

表2

图6

图7

参考文献 24

[1]	张厚福, 方朝亮, 高先志, 等. 石油地质学[M]. 北京: 石油工业出版社, 1999.
	ZHANG Houfu, FANG Chaoliang, GAO Xianzhi, et al. Petroleum Geology[M]. Beijing: Petroleum Industry Press, 1999.
[2]	罗群, 姜震学, 庞雄奇. 断裂控藏机理与模式[M]. 北京: 石油工业出版社, 2007.
	LUO Qun, JIANG Zhenxue, PANG Xiongqi. The mechanism and model of fault controlling petroleum accumulation[M]. Beijing: Petroleum Industry Press, 2007.
[3]	付广, 彭万涛, 徐衍彬, 等. 断砂配置输导油气时间有效性研究方法及其应用[J]. 新疆石油地质, 2019,40(2):156-160.
	FU Guang, PENG Wantao, XU Yanbin, et al. A method to study time effectiveness of fault-sand configuration transporting hydrocarbon and its application[J]. Xinjiang Petroleum Geology, 2019,40(2):156-160.
[4]	卓勤功, 赵孟军, 邹开真, 等. 中国中西部前陆冲断带油气分布规律及勘探领域[J]. 新疆石油地质, 2018,39(2):125-133.
	ZHUO Qingong, ZHAO Mengjun, ZOU Kaizhen, et al. Petroleum distribution in foreland thrust belts and its exploration areas in midwest China[J]. Xinjiang Petroleum Geology, 2018,39(2):125-133.
[5]	黄正吉. 珠江口盆地陆相烃源岩与油气生成[J]. 中国海上油气(地质), 1998,12(4):255-261.
	HUANG Zhengji. Nonmarine source rock and petroleum from formation of Pearl River Mouth basin[J]. China Offshore Oil and Gas(Geology), 1998,12(4):255-261.
[6]	陈长民, 施和生, 许仕策, 等. 珠江口盆地(东部)第三系油气藏形成条件[M]. 北京: 科学出版社, 2003.
	CHEN Changmin, SHI Hesheng, XU Shice, et al. Tertiary petroleum formation conditions of Pearl River Mouth basin(East)[M]. Beijing: Science Press, 2003.
[7]	李平鲁. 珠江口盆地新生代构造运动[J]. 中国海上油气(地质), 1993,7(6):11-17.
	LI Pinglu. Cenozoic tectonic movement in the Pearl River Mouth basin[J]. China Offshore Oil and Gas(Geology), 1993,7(6):11-17.
[8]	何敏, 朱伟林, 吴哲, 等. 珠江口盆地新构造运动特征与油气成藏[J]. 中国海上油气, 2019,31(5):9-20.
	HE Min, ZHU Weilin, WU Zhe, et al. Neotectonic movement characteristics and hydro accumulation of the Pearl River Mouth basin[J]. China Offshore Oil and Gas, 2019,31(5):9-20.
[9]	姜华, 王华, 李俊良, 等. 珠江口盆地珠三坳陷断层特征及其对油气成藏的控制作用[J]. 石油实验地质, 2008,30(5):460-466. doi: 10.11781/sysydz200805460
	JIANG Hua, WANG Hua, LI Junliang, et al. Fault characteristic and control on petroleum accumulation in the ZHU Ⅲ depression,the Pearl River Mouth basin[J]. Petroleum Geology & Experiment, 2008,30(5):460-466.
[10]	李辉, 陈胜红, 张迎朝, 等. 珠江口盆地珠三坳陷断裂特征与油气成藏[J]. 海洋地质与第四纪地质, 2014,34(3):115-124.
	LI Hui, CHEN Shenghong, ZHANG Yingzhao, et al. Fault in the Zhu-3 depression of Pearl River Mouth basin and their control over hydrocarbon accumulation[J]. Marine Geology & Quanternary Geology, 2014,34(3):115-124.
[11]	杨计海, 杨希冰, 游君君, 等. 珠江口盆地珠三坳陷油气成藏规律及勘探方向[J]. 石油学报, 2019,40(增刊1):11-25.
	YANG Jihai, YANG Xibing, YOU Junjun, et al. Hydrocarbon accumulation law and exploration direction in Zhu Ⅲ depression,Pearl River Mouth basin[J]. Acta Petrolei Sinica, 2019,40(Supp.1):11-25.
[12]	杨海长, 徐建永, 武爱俊, 等. 珠三坳陷阳江凹陷构造特征及其对油气成藏的影响[J]. 海洋石油, 2011,31(2):20-24.
	YANG Haizhang, XU Jianyong, WU Aijun, et al. Structural features and impact on hydrocarbon accumulation in Yangjiang sag of Zhu Ⅲ depression[J]. Offshore Oil, 2011,31(2):20-24.
[13]	彭光荣, 张向涛, 许新明, 等. 南海北部珠江口盆地阳江凹陷油气勘探重要发现与认识[J]. 中国石油勘探, 2019,24(3):267-279.
	PENG Guangrong, ZHANG Xiangtao, XU Xinming, et al. Important discoveries and understandings of oil and gas exploration in Yangjiang sag of the Pearl River Mouth basin,northern South China Sea[J]. China Petroleum Exploration, 2019,24(3):267-279.
[14]	孙晓猛, 张旭庆, 张功成, 等. 南海北部新生代盆地基底结构及构造属性[J]. 中国科学:地球科学, 2014,44(6):1 312-1 323.
	SUN Xiaomeng, ZHANG Xuqing, ZHANG Gongcheng, et al. Texture and tectonic attribute of Cenozoic basin basement in the northern South China Sea[J]. Science China:Earth Sciences, 2014,44(6):1 312-1 323.
[15]	李三忠, 索艳慧, 刘鑫, 等. 南海的盆地群与盆地动力学[J]. 海洋地质与第四纪地质, 2012,32(6):55-78.
	LI Sanzhong, SUO Yanhui, LIU Xin, et al. Basin dynamics and basin groups of the South China Sea[J]. Marine Geology & Quanternary Geology, 2012,32(6):55-78.
[16]	李三忠, 曹现志, 王光增, 等. 太平洋板块中-新生代构造演化及板块重建[J]. 地质力学学报, 2019,25(5):642-677.
	LI Sanzhong, CAO Xianzhi, WANG Guangzeng, et al. Meso-Cenozoic tectonic evolution and plate reconstruction of the Pacific Plate[J]. Journal of Geomechanics, 2019,25(5):642-677.
[17]	孙卫东, 林秋婷, 张丽鹏, 等. 跳出南海看南海:新特提斯洋闭合与南海的形成演化[J]. 岩石学报, 2018,34(12):3 467-3 478.
	SUN Weidong, LIN Qiuting, ZHANG Lipeng, et al. The formation of the South China Sea resulted from the closure of the Neo-Tethys:a perspective from regional geology[J]. Acta Petrologica Sinica, 2018,34(12):3 467-3 478.
[18]	张远泽, 漆家福, 吴景富. 南海北部新生代盆地断裂系统及构造动力学影响因素[J]. 地球科学, 2019,44(2):603-625.
	ZHANG Yuanze, QI Jiafu, WU Jingfu. Cenozoic faults systems and its geodynamics of the continental margin basins in the northern of South China Sea[J]. Earth Science, 2019,44(2):603-625.
[19]	漆家福, 吴景富, 马兵山, 等. 南海北部珠江口盆地中段伸展构造模型及其动力学[J]. 地学前缘, 2019,26(2):203-221.
	QI Jiafu, WU Jingfu, MA Bingshan, et al. The structural model and dynamics concerning middle section,Pearl River Mouth basin in north margin of South China Sea[J]. Erath Science Frontiers, 2019,26(2):203-221.
[20]	田立新, 张向涛, 彭光荣, 等. 珠江口盆地阳江凹陷石油地质特征及成藏主控因素[J]. 中国海上油气, 2020,32(1):13-22.
	TIAN Lixin, ZHANG Xiangtao, PENG Guangrong, et al. Petroleum geological characteristics and main controlling factors of the Yangjiang sag in Pearl River Mouth basin[J]. China Offshore Oil and Gas, 2020,32(1):13-22.
[21]	周心怀, 牛成民, 滕长宇. 环渤中地区新构造运动期活动特征与油气成藏关系[J]. 石油与天然气地质, 2009,30(4):469-482. doi: 10.11743/ogg20090413
	ZHOU Xinhuai, NIU Chengmin, TENG Changyu. Relationship between faulting and hydrocarbon pooling during the neotectonic movement around central Bohai Bay[J]. Oil & Gas Geology, 2009,30(4):469-482.
[22]	万天丰, 王明明, 殷秀兰, 等. 渤海湾地区不同方向断裂带的封闭性[J]. 现代地质, 2004,18(2):157-163.
	WAN Tianfeng, WANG Mingming, YIN Xiulan, et al. Sealing properties of different direction fault in the Bohai Bay area[J]. Geoscience, 2004,18(2):157-163.
[23]	吴智平, 陈伟, 薛雁, 等. 断裂带的结构特征及其对油气的输导和封堵性[J]. 地质学报, 2010,84(4):570-578.
	WU Zhiping, CHEN Wei, XUE Yan, et al. Structural characteristics of faulting zone and its ability in transporting and sealing oil and gas[J]. Acta Geologica Sinica, 2010,84(4):570-578.
[24]	王光增. 郯庐断裂渤海段走滑派生构造及其控藏作用[D]. 山东东营：中国石油大学(华东), 2017.
	WANG Guangzeng. Cenozoic strike-slip associated structures of Tanlu fault and their reservoir-controlling effect in Bohai sea area[D]. Dongying,Shandong：China University of Petroleum(East China), 2017.

洼陷	走向	结构特征	结构样式
阳江24洼	北东东—南西西	F2断层控制,北断南超	半地堑
恩平19洼	近东西	F2和F3断层控制,早期南断北超、晚期双断	复式半地堑
恩平20洼	近东西	F4和F5断层控制,各时期活动性均衡,南北双断	不对称地堑
恩平21洼	北东东—南西西	F6断层控制,南断北超,断块旋转强烈	低角度半地堑

输导断层类别	活动时期	切割层位	韩江组沉积晚期活动速率/（m·Ma-1）	粤海组沉积期至今活动速率/（m·Ma-1）	充注构造	油气显示最浅深度/m	油气显示最浅层段
Ⅰ类	始新统—更新统	前古近系—万山组	>23	>18	Y10	1 500	韩江组下段
					Y11	1 200	韩江组上段
					Y12	1 550	珠江组上段
					Y13	1 600	韩江组下段
					Y15	1 200	韩江组上段
Ⅱ类	中新统	前古近系—万山组	8~23	7~18	Y16	1 900	珠江组上段
Ⅲ类	中新统	文昌组—韩江组	<8	<7	Y14	2 500	珠江组下段
