太平油田强边底水稠油油藏剩余油赋存规律

doi:10.7657/XJPG20210207

摘要/Abstract

摘要：

太平油田新近系馆陶组下段为强边底水油藏,边底水活跃,水侵严重,储量动用不充分,采出程度低,剩余油量大,具有开发调整的潜力。根据太平油田馆陶组下段油藏开发方式和剩余油赋存规律,通过水平井变流线井间加密调整,采用大通道堵水调剖和冷采降黏开发,以达到提高采收率的目的。通过矿场水平井开发调整实施,取得了显著的增产效果,降低了稠油开发成本,形成的强边底水稠油油藏开发配套技术可供类似油藏开发参考。

关键词: 太平油田, 馆陶组, 边底水稠油油藏, 微观孔隙结构, 剩余油赋存规律, 油藏流场调整, 冷采降黏, 提高采收率

Abstract:

Reservoirs in the lower member of the Neogene Guantao formation in the Taiping oilfield have strong and active edge and bottom water, so that water invasion is severe, the reserves producing degree and the recovery percent of reserves are low and there is a large amount of remaining oil, which should be produced by adjusting the development pattern. According to the development pattern and the occurrence law of the remaining oil, infill horizontal wells were located to change the flow field, large water channels were plugged, and cold production and viscosity reduction technologies were applied to enhance the oil recovery. Finally, the oil production has been increased, and the development cost of the heavy oil has been reduced significantly. The supporting technology developed during producing the heavy oil reservoirs in the lower member of the Neogene Guantao formation in the Taiping oilfield can be a reference to developing similar heavy oil reservoirs with strong edge and bottom water.

Key words: Taiping oilfield, Guantao formation, heavy oil reservoir with edge and bottom water, microscopic pore structure, remaining oil occurrence law, flow field adjustment, cold production and viscosity reduction, enhanced oil recovery

中图分类号:

TE345

吴伟, 张博. 太平油田强边底水稠油油藏剩余油赋存规律[J]. 新疆石油地质, 2021, 42(2): 173-178.

WU Wei, ZHANG Bo. Occurrence Law of Remaining Oil in Heavy Oil Reservoirs With Strong Edge and Bottom Water in Taiping Oilfield[J]. Xinjiang Petroleum Geology, 2021, 42(2): 173-178.

图/表 7

表1

图1

图2

表2

图3

图4

图5

参考文献 20

[1]	李振泉, 郭长春, 王军, 等. 特高含水期油藏剩余油分布新认识:以孤岛油田中一区Ng^上3砂组为例[J]. 油气地质与采收率, 2019,26(6):19-27.
	LI Zhenquan, GUO Changchun, WANG Jun, et al. New understanding of remaining oil distribution in oil reservoirs at extra-high water-cut stage:a case of upper Ng3 sand group in Zhongyi area,Gudao oilfield[J]. Petroleum Geology and Recovery Efficiency, 2019,26(6):19-27.
[2]	隋永婷, 邓宏伟. 强边底水稠油油藏转换开发方式研究[J]. 内蒙古石油化工, 2014,24(1):123-125.
	SUI Yongting, DENG Hongwei. Study on the conversion and development method of heavy oil reservoir of strong-side bottom water[J]. Inner Mongolia Petrochemical Industry, 2014,24(1):123-125.
[3]	王芳芳, 胡海光, 何志雄. 剩余油形成机理与赋存状态研究综述[J]. 广东化工, 2013,40(3):66-67.
	WANG Fangfang, HU Haiguang, HE Zhixiong. Remaining oil forming mechanism of occurrence research[J]. Guangdong Chemical Industry, 2013,40(3):66-67.
[4]	邢凤存, 刘连启, 刘成鑫, 等. 太平油田馆陶组下段沉积特征[J]. 大庆石油地质与开发, 2004,23(6):3-5.
	XING Fengcun, LIU Lianqi, LIU Chengxin, et al. Sedimentary features of lower member of Guantao formation in Taiping oilfield[J]. Petroleum Geology & Oilfield Development in Daqing, 2004,23(6):3-5.
[5]	黄全华, 林星宇, 童凯, 等. 非达西渗流边水气藏水平井见水时间预测[J]. 岩性油气藏, 2019,31(1):147-152.
	HUANG Quanhua, LIN Xingyu, TONG Kai, et al. Prediction of water breakthrough time for horizontal well in non-Darcy flow edge water gas reservoirs[J]. Lithologic Reservoirs, 2019,31(1):147-152.
[6]	孙盈盈, 宋新民, 马德胜, 等. 老君庙油田水驱后剩余油微观赋存状态[J]. 新疆石油地质, 2014,35(3):311-314.
	SUN Yingying, SONG Xinmin, MA Desheng, et al. Characteristics of remaining oil micro-distribution in Laojunmiao oilfield after waterflooding[J]. Xinjiang Petroleum Geology, 2014,35(3):311-314.
[7]	荆林. 太平油田综合挖潜措施与效果分析[J]. 油气藏评价与开发, 2016,9(3):140.
	JING Lin. Analysis of comprehensive excavation measures and effects in Taiping oilfield[J]. Reservoir Evaluation and Development, 2016,9(3):140.
[8]	闫伟超, 孙建孟. 微观剩余油研究现状分析[J]. 地球物理学进展, 2016,31(5):2 198-2 211.
	YAN Weichao, SUN Jianmeng. Analysis of research present situation of microscopic remaining oil[J]. Progress in Geophysics, 2016,31(5):2 198-2 211.
[9]	王平. 太平油田边底水稠油油藏高效调整技术[J]. 科技资讯, 2008,36(18):79-80.
	WANG Ping. High efficiency adjustment technology of heavy oil reservoir with edge and bottom water in Taiping oilfield[J]. Science & Technology Information, 2008,36(18):79-80.
[10]	孙建芳. 胜利油区稠油非达西渗流启动压力梯度研究[J]. 油气地质与采收率, 2010,17(6):74-77.
	SUN Jianfang. Threshold pressure gradient study on non-Newtonian flow of heavy oil reservoirs in Shengli oilfield[J]. Petroleum Geology and Recovery Efficiency, 2010,17(6):74-77.
[11]	王玥, 陈小凡, 邹利军, 等. 带夹层底水油藏油井底水锥进影响因素分析[J]. 油气藏评价与开发, 2013,3(6):24-27.
	WANG Yue, CHEN Xiaofan, ZOU Lijun, et al. Analysis on oil wells bottom water coning influence factors of bottom water reservoir with interlayer[J]. Reservoir Evaluation and Development, 2013,3(6):24-27.
[12]	徐守余, 宋洪亮. 微观剩余油仿真实验研究[J]. 中国科技论文在线, 2008,3(11):863-866.
	XU Shouyu, SONG Hongliang. Laboratory emulation study on micro remaining oil[J]. Sciencepaper Online, 2008,3(11):863-866.
[13]	高文君, 付焱鑫, 潘有军, 等. 水驱油理论解析法[J]. 新疆石油地质, 2016,37(1):51-55.
	GAO Wenjun, FU Yanxin, PAN Youjun, et al. Analytical method of water displacing oil theory[J]. Xinjiang Petroleum Geology, 2016,37(1):51-55.
[14]	郑延超, 王婷婷, 王中华, 等. MRC技术及应用[J]. 中外能源, 2015,27(3):32-37.
	ZHENG Yanchao, WANG Tingting, WANG Zhonghua, et al. MRC technique and its application[J]. Sino-Global Energy, 2015,27(3):32-37.
[15]	郭长永, 熊启勇, 邓伟兵, 等. 底水油藏水平井水平段动用状况预测方法[J]. 新疆石油地质, 2019,40(4):468-472.
	GUO Changyong, XIONG Qiyong, DENG Weibing, et al. Methods to predict horizontal section producing status of horizontal wells in reservoirs with bottom water[J]. Xinjiang Petroleum Geology, 2019,40(4):468-472.
[16]	王智峰. MRC近钻头地质导向系统总体设计与应用[J]. 石油钻采工艺, 2015,37(4):1-4.
	WANG Zhifeng. Overall design and application of MRC near-bit geosteering system[J]. Oil Drilling & Production Technology, 2015,37(4):1-4.
[17]	石洪福. 稠油底水油层水平井分段完井方法及应用[J]. 新疆石油地质, 2020,41(2):232-236.
	SHI Hongfu. A method and application of horizontal well segmentation in heavy oil reservoirs with bottom water[J]. Xinjiang Petroleum Geology, 2020,41(2):232-236.
[18]	段强国. 稠油冷采技术现状及展望[J]. 石化技术, 2018,25(4):265.
	DUAN Qiangguo. Present situation and prospect of heavy oil cold recovery technology[J]. Petrochemical Industry Technology, 2018,25(4):265.
[19]	李惠民. 氮气泡沫酸化工艺技术研究与应用[J]. 科技资讯, 2009,7(19):94.
	LI Huimin. Research and application of nitrogen foam acidizing technology[J]. Science & Technology Information, 2009,7(19):94.
[20]	向湘兴, 陈静, 侯军伟, 等. 克拉玛依油田稠油油藏氮气泡沫驱应用[J]. 新疆石油地质, 2017,38(1):76-80.
	XIANG Xiangxing, CHEN Jing, HOU Junwei, et al. Application of nitrogen foam flooding in heavy oil reservoirs of Karamay oilfield[J]. Xinjiang Petroleum Geology, 2017,38(1):76-80.
