塔里木盆地油气勘探历程与启示

doi:10.7657/XJPG20210303

摘要/Abstract

摘要：

塔里木盆地于1950年正式开启了油气勘探历史。根据勘探重点区域、勘探指导思想、地质认识、勘探对象、技术手段和勘探成果的发展变化,将70年来的勘探历程划分为4个阶段：1950—1983年,盆地边缘山前带“五上五下”艰难探索;1984—1996年,突破台盆区,“六上”塔里木,台盆区碎屑岩勘探取得规模发现;1997—2005年,坚持“四个并举”,强化技术攻关,库车山前勘探取得重大突破;2006年至今,锁定三大阵地战,库车前陆盐下冲断带和台盆区缝洞型碳酸盐岩两大超深层领域全面突破。塔里木盆地在中国最快、最早进入超深层勘探阶段,对其超深层油气富集规律认识和勘探经验进行了总结。受冷盆环境、有效烃源岩发育于盆地早期等因素的控制,超深层仍然可以大规模发育有效储集层,形成连片的大型油气富集带,是值得着重探索的重要领域。在塔里木盆地超深层勘探实践中,持续开展技术攻关和认识创新、先铺开部署三维地震再部署预探井、实行勘探开发一体化生产组织是快速取得规模勘探发现的成功经验。

关键词: 塔里木盆地, 勘探历程, 盐下冲断带, 缝洞型碳酸盐岩, 超深层油气, 勘探经验

Abstract:

After summarizing the petroleum exploration history in the Tarim basin since 1950 from the points of major exploration areas and targets, exploration ideas, geological understandings and exploration technology and achievements, the exploration process for over 70 years in the basin can be divided into 4 stages: (1) Uphill exploration in the piedmont of the margin of the basin from 1950 to 1983; (2) Breakthrough to the cratonic area through conducting 6 times of exploration in the basin, and making many discoveries in cratonic clastic reservoirs from 1984 to 1996; (3) Great breakthrough in Kuqa piedmont area through persisting on “4 equal stresses” and strengthening technical research from 1997 to 2005; (4) Breakthroughs to subsalt thrust belts in the Kuqa foreland basin and to the fractured-vuggy carbonate rocks in ultra-deep exploration areas through focusing on three “battlefields” since 2006. As the first basin targeting ultra-deep exploration in China, it is necessary to summarize the hydrocarbon accumulation laws and exploration experiences. Due to low geothermal gradient and early-deposited effective source rocks, large-scale effective reservoirs may exist and accumulate in ultra-deep layers and large-scale hydrocarbon enrichment zones form. They are potential targets for future exploration, especially in the basin with low geothermal gradient in the central and western parts. The ultra-deep exploration practice in the Tarim basin has proved that persisting on technical research and innovation, conducting 3D seismic survey before drilling wildcat wells, and running integrated exploration and development are successful ways to make fast and large-scale exploration discoveries.

Key words: Tarim basin, exploration history, subsalt thrust belt, fractured-vuggy carbonate rock, ultra-deep oil and gas, exploration experience

中图分类号:

TE132

田军. 塔里木盆地油气勘探历程与启示[J]. 新疆石油地质, 2021, 42(3): 272-282.

TIAN Jun. Petroleum Exploration History and Enlightenment in Tarim Basin[J]. Xinjiang Petroleum Geology, 2021, 42(3): 272-282.

图/表 9

图1

图2

表1

1950—2020年塔里木盆地各勘探时间段基本情况"

时间	勘探重点区域	勘探指导思想	地质认识	勘探对象	技术手段	重要勘探成果
1950— 1983年	库车、塔西南山前带	类比费尔干纳盆地和塔吉克盆地,寻找山前有利目标	西南坳陷、库车坳陷中新生界为最有利领域	地表油苗区和地面构造	重磁电勘探;浅井钻探	依奇克里克油田、柯克亚气田
1984— 1996年	台盆区	在台盆区建立两个根据地,打出两个拳头	台盆区是油气勘探更为现实的切入点和突破口	中浅层、深层构造圈闭	常规数字二维地震	沙参2井、轮南1井、轮南2井、英买1井、塔中1井、轮南油气田群、英买力—牙哈油气田群、东河塘油田、塔中4油田
1997— 2005年	山前带和台盆区并举	“四个并举”	台盆区油气集中在塔北隆起和塔中凸起,前陆区油气集中在山前逆冲构造带和前缘隆起上;纵向上应当逼近主力烃源层,寻找大型原生油气藏	中浅层、深层构造圈闭、岩性圈闭	台盆区三维地震与储集层预测技术、库车山前“直线”二维地震	哈得逊油田、轮古油田、塔中Ⅰ号气田（良里塔格组礁滩体）、克拉2气田、大北气田、迪那2气田、和田河气田
2006年至今	库车坳陷、塔北隆起、塔中凸起	大打库车、塔北、塔中三大阵地战	必须坚持围绕库车山前白垩系—古近系和台盆区奥陶系集中开展勘探部署;油气资源量和储量相对集中在库车坳陷、塔北隆起和塔中凸起	超深层构造圈闭、岩性圈闭	台盆区高密度宽方位三维地震、超深井精确中靶技术;库车山前宽线-大组合二维地震、高精度三维地震、复杂地层超深井钻完井技术	塔中Ⅰ号气田（鹰山组层间岩溶）、哈拉哈塘油田、克拉苏气田、中深1井、轮探1井

表1

图3

表2

图4

图5

图6

图7

参考文献 34

[1]	李建忠, 郑民, 郭秋麟, 等. 第四次油气资源评价[M]. 北京: 石油工业出版社, 2019.
	LI Jianzhong, ZHENG Min, GUO Qiulin, et al. The forth hydrocarbon resources evaluation[M]. Beijing: Petroleum Industry Press, 2019.
[2]	油田石油地质志编写组. 中国石油地质志·新疆油气区:塔里木吐哈及其他主要盆地(卷15下册) [M]. 北京: 石油工业出版社, 1995.
	Compilation Team of Petroleum Annals. Petroleum annals of China· Xinjiang district:Tarim,Turpan-Hami and other major basins (Volume 15,the second half)[M]. Beijing: Petroleum Industry Press, 1995.
[3]	张亘稼, 惠荣. 塔里木盆地油气勘探工作“六上五下”的历程[J]. 西安石油大学学报( 社会科学版), 2017,26(3):19-26.
	ZHANG Genjia, HUI Rong. The “6 on and 5 off” process of oil-gas exploration in Tarim basin[J]. Journal of Xi’an Shiyou University(Social Science Edition) , 2017,26(3):19-26.
[4]	王秋明, 张纪易. 塔里木盆地四十年油气勘探的回顾与展望[J]. 新疆石油地质, 1992,13(4):285-293.
	WANG Qiuming, ZHANG Jiyi. Forty year’s review and prospect for petroleum exploration in Tarim basin[J]. Xinjiang Petroleum Geology, 1992,13(4):285-293.
[5]	康玉柱. 沙参2井高产油气流的发现及今后找油方向[J]. 石油与天然气地质, 1985,6(增刊1):45-46.
	KANG Yuzhu. The discovery of high yield oil-gas flow from Shacan 2 borehole and future directions for oil exploration[J]. Oil and Gas Geology, 1986,6(Supp.1):45-46.
[6]	梁狄刚. 塔里木盆地九年油气勘探历程与回顾[J]. 勘探家, 1998,3(4):59-65.
	LIANG Digang. Course and review of nine-year petroleum exploration in the Tarim basin[J]. Petroleum Explorationist, 1998,3(4):59-65.
[7]	梁狄刚. 塔里木盆地九年油气勘探历程与回顾(续完)[J]. 勘探家, 2000,5(1):52-60.
	LIANG Digang. Course and review of nine-year petroleum exploration in the Tarim basin(continued end)[J]. Petroleum Explorationist, 2000,5(1):52-60.
[8]	梁狄刚. 塔里木盆地轮南—塔河奥陶系油田发现史的回顾与展望[J]. 石油学报, 2008,29(1):153-158.
	LIANG Digang. Review and expectation on the discovery of Ordovician Lunnan-Tahe oilfield,Tarim basin[J]. Acta Petrolei Sinica, 2008,29(1):153-158.
[9]	王招明, 谢会文, 李勇, 等. 库车前陆冲断带深层盐下大气田的勘探和发现[J]. 中国石油勘探, 2013,18(3):1-11.
	WANG Zhaoming, XIE Huiwen, LI Yong, et al. Exploration and discovery of large and deep subsalt gas fields in Kuqa foreland thrust belt[J]. China Petroleum Exploration, 2013,18(3):1-11.
[10]	杨海军, 李勇, 唐雁刚, 等. 塔里木盆地克拉苏盐下深层大气田的发现[J]. 新疆石油地质, 2019,40(1):12-20.
	YANG Haijun, LI Yong, TANG Yan’gang, et al. Discovery of Kelasu subsalt deep large gas field,Tarim basin[J]. Xinjiang Petroleum Geology, 2019,40(1):12-20.
[11]	贾承造. 塔里木盆地构造特征与油气聚集规律[J]. 新疆石油地质, 1999,20(3):177-183.
	JIA Chengzao. Structural characteristics and oil/gas accumulative regularity in Tarim basin[J]. Xinjiang Petroleum Geology, 1999,20(3):177-183.
[12]	贾承造, 魏国齐. 塔里木盆地构造特征与含油气性[J]. 科学通报, 2002,47(增刊):1-8.
	JIA Chengzao, WEI Guoqi. Structural characteristics and oil/gas bearing possibility[J]. Chinese Science Bulletin, 2002,47(Supp.):1-8.
[13]	田军. 塔里木盆地勘探成果与勘探方向[J]. 新疆石油地质, 2019,40(1):1-11.
	TIAN Jun. Petroleum exploration achievements and future targets of Tarim basin[J]. Xinjiang Petroleum Geology, 2019,40(1):1-11.
[14]	韩剑发, 梅廉夫, 杨海军, 等. 塔中Ⅰ号坡折带礁滩复合体大型凝析气田成藏机制[J]. 新疆石油地质, 2008,29(3):323-326.
	HAN Jianfa, MEI Lianfu, YANG Haijun, et al. Hydrocarbon accumulation mechanism of large-sized reef-shoal complex condensate gas field in Tazhong No.1 slope-break zone,Tarim basin[J]. Xinjiang Petroleum Geology, 2008,29(3):323-326.
[15]	贾承造, 王招明, 皮学军, 等. 克拉2气田的发现及勘探技术[J]. 中国石油勘探, 2002,7(1):79-88.
	JIA Chengzao, WANG Zhaoming, PI Xuejun, et al. Discovery of Kela-2 gas field and exploration technology[J]. China Petrleum Exploration, 2002,7(1):79-88
[16]	王招明. 试论库车前陆冲断带构造顶蓬效应[J]. 天然气地球科学, 2013,24(4):671-677.
	WANG Zhaoming. Discussion of ceiling effect in foreland thrust belt of Kuqa depression[J]. Natural Gas Geoscience, 2013,24(4):671-677.
[17]	王招明, 李勇, 谢会文, 等. 库车前陆盆地超深油气地质理论与勘探实践[M]. 北京: 石油工业出版社, 2017.
	WANG Zhaoming, LI Yong, XIE Huiwen, et al. Geological theory and exploration practice of ultra-deep oil and gas in Kuqa foreland basin[M]. Beijing: Petroleum Industry Press, 2017.
[18]	王招明, 杨海军, 潘文庆, 等. 超深缝洞型海相碳酸盐岩油气地质理论与勘探实践[M]. 北京: 石油工业出版社, 2017.
	WANG Zhaoming, YANG Haijun, PAN Wenqing, et al. Geological theory and exploration practice of oil and gas in ultra-deep fissure cavernous marine carbonate rocks[M]. Beijing: Petroleum Industry Press, 2017.
[19]	杨学文, 王招明, 何文渊, 等. 塔里木盆地超深油气勘探实践与创新[M]. 北京: 石油工业出版社, 2019.
	YANG Xuewen, WANG Zhaoming, HE Wenyuan, et al. Exploration practices and innovations of ultra-deep oil and gas in Tarim basin[M]. Beijing: Petroleum Industry Press, 2019.
[20]	杜金虎, 田军, 李国欣, 等. 库车坳陷秋里塔格构造带的战略突破与前景展望[J]. 中国石油勘探, 2019,24(1):16-23.
	DU Jinhu, TIAN Jun, LI Guoxin, et al. Strategic breakthrough and prospect of Qiulitag structural belt in Kuqa depression[J]. China Petroleum Exploration, 2019,24(1):16-23.
[21]	杨海军, 韩剑发, 孙崇浩, 等. 塔中Ⅰ号坡折带礁滩复合体大型油气田勘探理论与技术[J]. 新疆石油地质, 2011,32(3):224-227.
	YANG Haijun, HAN Jianfa, SUN Chonghao, et al. Exploration of reef-flat complex giant oil-gas field in Tazhong No.1 slope break in Tarim basin:theory and technology[J]. Xinjiang Petroleum Geology, 2011,32(3):224-227.
[22]	韩剑发, 张海祖, 于红枫, 等. 塔中隆起海相碳酸盐岩大型凝析气田成藏特征与勘探[J]. 岩石学报, 2012,28(3):769-782.
	HAN Jianfa, ZHANG Haizu, YU Hongfeng, et al. Hydrocarbon accumulation characteristic and exploration on large marine carbonate condensate field in Tazhong uplift[J]. Acta Petrologica Sinica, 2012,28(3):769-782.
[23]	俞仁连. 塔里木盆地塔河油田加里东期古岩溶特征及其意义[J]. 石油实验地质, 2005,27(5):468-472.
	YU Renlian. Characteristics and significance of the Caledonian karst in the Tahe oilfield,the Tarim basin[J]. Petroleum Geology & Experiment, 2005,27(5):468-472.
[24]	王招明, 杨海军, 齐英敏, 等. 塔里木盆地古城地区奥陶系天然气勘探重大突破及其启示[J]. 天然气工业, 2014,34(1):1-9.
	WANG Zhaoming, YANG Haijun, QI Yingmin, et al. Ordovician gas exploration breakthrough in the Gucheng lower uplift of the Tarim basin and its enlightenment[J]. Natural Gas Industry, 2014,34(1):1-9.
[25]	王招明, 谢会文, 陈永权, 等. 塔里木盆地中深1井寒武系盐下白云岩原生油气藏的发现与勘探意义[J]. 中国石油勘探, 2014,19(2):1-13.
	WANG Zhaoming, XIE Huiwen, CHEN Yongquan, et al. Discovery and exploration of Cambrian subsalt dolomite original hydrocarbon reservoir at Zhongshen-1 well in Tarim basin[J]. China Petroleum Exploration, 2014,19(2):1-13.
[26]	杨海军, 陈永权, 田军, 等. 塔里木盆地轮探1 井超深层油气勘探重大发现与意义[J]. 中国石油勘探, 2020,25(2):62-72.
	YANG Haijun, CHEN Yongquan, TIAN Jun, et al. Great discovery and its significance of ultra-deep oil and gas exploration in Well Luntan-1 of the Tarim basin[J]. China Petroleum Exploration, 2020,25(2):62-72.
[27]	杜金虎, 王招明, 雷刚林, 等. 柯东1风险探井的突破及其战略意义[J]. 中国石油勘探, 2011,16(2):1-5.
	DU Jinhu, WANG Zhaoming, LEI Ganglin, et al. A discovery in Well Kedong-1 and its exploration significance[J]. China Petroleum Exploration, 2011,16(2):1-5.
[28]	朱光有, 曹颖辉, 闫磊, 等. 塔里木盆地8000m以深超深层海相油气勘探潜力与方向[J]. 天然气地球科学, 2018,29(6):755-772.
	ZHU Guangyou, CAO Yinghui, YAN Lei, et al. Petroleum exploration potential and favorable areas of ultra-deep marine strata deeper than 8 000 meters in Tarim basin[J]. Natural Gas Geoscience, 2018,29(6):755-772.
[29]	胡文瑞, 鲍敬伟, 胡滨. 全球油气勘探进展与趋势[J]. 石油勘探与开发, 2013,40(4):409-413.
	HU Wenrui, BAO Jingwei, HU Bin. Trend and progress in global oil and gas exploration[J]. Petroleum Exploration and Development, 2013,40(4):409-413.
[30]	张光亚, 马锋, 梁英波, 等. 全球深层油气勘探领域及理论技术进展[J]. 石油学报, 2015,36(9):1 156-1 166.
	ZHANG Guangya, MA Feng, LIANG Yingbo, et al. Domain and theory-technology progress of global deep oil & gas exploration[J]. Acta Petrolei Sinica, 2015,36(9):1 156-1 166.
[31]	孙龙德, 邹才能, 朱如凯, 等. 中国深层油气形成、分布与潜力分析[J]. 石油勘探与开发, 2013,40(6):641-650.
	SUN Longde, ZOU Caineng, ZHU Rukai, et al. Formation,distribution and potential of deep hydrocarbon resources in China[J]. Petroleum Exploration and Development, 2013,40(6):641-650.
[32]	杜金虎, 支东明, 李建忠, 等. 准噶尔盆地南缘高探1 井重大发现及下组合勘探前景展望[J]. 石油勘探与开发, 2019,46(2):205-215.
	DU Jinhu, ZHI Dongming, LI Jianzhong, et al. Major breakthrough of Well Gaotan 1 and exploration prospects of lower assemblage in southern margin of Junggar basin,NW China[J]. Petroleum Exploration and Development, 2019,46(2):205-215.
[33]	张本健, 方进, 尹宏, 等. 高产水平井的突破与四川盆地深层常规气藏巨大的勘探开发潜力[J]. 天然气工业, 2019,39(12):1-9.
	ZHANG Benjian, FANG Jin, YIN Hong, et al. A breakthrough in high-yield horizontal gas wells and great exploration and development potential in deep conventional gas reservoirs in the Sichuan basin[J]. Natural Gas Industry, 2019,39(12):1-9.
[34]	庞雄奇, 林会喜, 郑定业, 等. 中国深层和超深层碳酸盐岩油气藏形成分布的基本特征与动力机制及发展方向[J]. 地质力学学报, 2020,26(5):673-695.
	PANG Xiongqi, LIN Huixi, ZHENG Dingye, et al. Basic characteristics,dynamic mechanism and development direction of the formation and distribution of deep and ultra-deep carbonate reservoirs in China[J]. Journal of Geomechanics, 2020,26(5):673-695.

时间	阶段	五上原因	主要勘探区域	主要勘探工作	勘探发现	五下原因
1950— 1954年	一上一下	苏联援建,中苏石油公司成立	喀什凹陷和库车坳陷	地质普查、详查;重磁电勘探;浅井钻探		目的层埋藏深,交通不便,勘探重点在北疆
1956— 1959年	二上二下	中苏石油公司移交中方,成立新疆石油管理局,组建库车大队	扩展到阿克苏—柯坪地区、莎车—皮山地区和玛扎塔格山前	地质普查、详查;重磁力概查;航磁普查;地震;库车地区钻探	1958年发现依奇克里克油田	支援大庆会战,撤销塔里木矿务局
1964— 1967年	三上三下	塔里木作为三线建设重点,勘探力量重返南疆	库车坳陷、塔北隆起、巴楚凸起、塔东隆起	地质普查;地震;有利构造钻探;参数井钻探		勘探工作停顿
1970— 1973年	四上四下	加强三线建设,重新组建了南疆石油勘探会战指挥部	盆地西南部、库车坳陷	地质普查、详查;地震;克拉托构造钻探		钻探效果不佳,勘探队伍调离
1975— 1983年	五上五下	塔西南发现多处油苗,决定加速塔里木盆地勘探	库车坳陷—巴楚凸起西部—西南坳陷一带的“马蹄形探区”	地质详查;地震;航磁;大规模钻井	1977年发现柯克亚气田	“马蹄形”会战失利,勘探重点转移到北疆
