Development Tendency of Geological Theory of Total Petroleum System: Insights From the Discovery of Mahu Large Oil Province

doi:10.7657/XJPG20210101

Abstract

Abstract:

Petroleum system is a basic tool for strategic oil and gas exploration and the geological theory of petroleum system needs to be extended with the development of unconventional petroleum geology theory. Based on the review of the evolution of petroleum system theory and the analysis of its development tendency, the paper studies the discovery history of the large oil province of Mahu. The research results show that the discovery of the Mahu large oil province represents a microcosm of the development of petroleum system theory. The large oil province of Mahu where all kinds of reservoirs can be found has the basic conditions of source-reservoir coupling, providing empirical evidences for the establishment of the total petroleum system theory. Taking Mahu sag as a case, there are possibly four directions for the exploration of total petroleum system–from outer-source to inner-source, from conventional resources to unconventional resources, from shallow strata to deep ones, and from single traps to continuous geological bodies.

Key words: Junggar basin, Mahu sag, total petroleum system, petroleum system, large oil province, unconventional oil and gas

CLC Number:

TE122.32

TANG Yong, CAO Jian, HE Wenjun, SHAN Xiang, LIU Yin, ZHAO Kebin. Development Tendency of Geological Theory of Total Petroleum System: Insights From the Discovery of Mahu Large Oil Province[J]. Xinjiang Petroleum Geology, 2021, 42(1): 1-9.

Figures/Tables 8

Fig. 1.

Fig. 2.

Fig. 3.

Fig. 4.

Fig. 5.

Fig. 6.

Table 1

Fig. 7.

References 30

[1]	汪时成, 周庆凡 . 含油气系统概念的由来及内涵[J]. 石油与天然气地质, 2000,21(3):279-282.
	WANG Shicheng, ZHOU Qingfan . Origin and intension of concept in petroleum system[J]. Oil & Gas Geology, 2000,21(3):279-282.
[2]	何登发, 赵文智, 雷振宇 , 等. 中国叠合型盆地复合含油气系统的基本特征[J]. 地学前缘, 2000,7(3):23-37.
	HE Dengfa, ZHAO Wenzhi, LEI Zhenyu , et al. Characteristics of composite petroleum systems of superimposed basins in China[J]. Earth Science Frontiers, 2000,7(3):23-37.
[3]	赵文智, 何登发, 池英柳 , 等. 中国复合含油气系统的基本特征与勘探技术[J]. 石油学报, 2001,22(1):6-13.
	ZHAO Wenzhi, HE Dengfa, CHI Yingliu , et al. Major characteristics and exploration technology of multi-source petroleum systems in China[J]. Acta Petrolei Sinica, 2001,22(1):6-13.
[4]	赵文智, 何登发, 范土芝 . 含油气系统术语、研究流程与核心内容之我见[J]. 石油勘探与开发, 2002,29(2):1-7.
	ZHAO Wenzhi, HE Dengfa, FAN Tuzhi . The study on terminology, technological process and kernel content for petroleum system[J]. Petroleum Exploration and Development, 2002,29(2):1-7.
[5]	MAGOON L B . The play that complements the petroleum system:a new exploration equation[J]. The Oil & Gas Journal, 1995,93(40):85-87.
[6]	赵文智, 张光亚, 汪泽成 . 复合含油气系统的提出及其在叠合盆地油气资源预测中的作用[J]. 地学前缘, 2005,12(4):458-467.
	ZHAO Wenzhi, ZHANG Guangya, WANG Zecheng . On the concept of composite petroleum systems and its application to the prediction of oil and gas resources in superimposed basins[J]. Earth Science Frontiers, 2005,12(4):458-467.
[7]	POLLASTRO R M . Total petroleum system assessment of undiscovered resources in the giant Barnett shale continuous (unconventional) gas accumulation, Fort Worth basin, Texas[J]. AAPG Bulletin, 2007,91(4):551-578.
[8]	邹才能, 董大忠, 王社教 , 等. 中国页岩气形成机理、地质特征及资源潜力[J]. 石油勘探与开发, 2010,37(6):641-653.
	ZOU Caineng, DONG Dazhong, WANG Shejiao , et al. Geological characteristics, formation mechanism and resource potential of shale gas in China[J]. Petroleum Exploration and Development, 2010,37(6):641-653.
[9]	邹才能, 杨智, 张国生 , 等. 常规-非常规油气“有序聚集”理论认识及实践意义[J]. 石油勘探与开发, 2014,41(1):14-25.
	ZOU Caineng, YANG Zhi, ZHANG Guosheng , et al. Conventional and unconventional petroleum “orderly accumulation”:concept and practical significance[J]. Petroleum Exploration and Development, 2014,41(1):14-25.
[10]	JIA Chengzao, ZHENG Min, ZHANG Yongfeng . Some key issues on the unconventional petroleum systems[J]. Petroleum Research, 2016,1(2):113-122.
[11]	贾承造 . 论非常规油气对经典石油天然气地质学理论的突破及意义[J]. 石油勘探与开发, 2017,44(1):1-11.
	JIA Chengzao . Breakthrough and significance of unconventional oil and gas to classical petroleum geological theory[J]. Petroleum Exploration and Development, 2017,44(1):1-11.
[12]	胡朝元, 廖曦 . 成油系统概念在中国的提出及其应用[J]. 石油学报, 1996,17(1):10-16.
	HU Chaoyuan, LIAO Xi . The concept of petroleum system raised in China and its application[J]. Acta Petrolei Sinica, 1996,17(1):10-16.
[13]	DOW W . Application of oil-correlation and source-rock data to exploration in Williston basin[J]. AAPG Bulletin, 1974,58(7):1 253-1 262.
[14]	PERRODON A, MASSE P . Subsidence, sedimentation and petroleum systems[J]. Journal of Petroleum Geology, 1984,7(1):5-25.
[15]	PERRODON A . Petroleum systems:models and applications[J]. Journal of Petroleum Geology, 1992,15(2):319-325.
[16]	DEMAISON G, HUIZINGA B J . Genetic classification of petroleum systems[J]. AAPG Bulletin, 1991,75(10):1 626-1 643.
[17]	DEMAISON G . The generative basin concept[C]//DEMAISON G, MURRIS R J (Eds.). Petroleum geochemistry and basin evaluation. AAPG Memoir, 1984(35):1-14.
[18]	MEISSNER F F, WOODWARD J, CLAYTON J L. Stratigraphic relationships and distribution of source rocks in the Greater Rocky mountain region [C]//WOODWARD J, MEISSNER F F, CLAYTON J L (Eds.). Hydrocarbon source rocks of the Greater Rocky mountain region. Denver:Rocky Mountain Association of Geologists, 1984: 1-34.
[19]	ULMISHEK G. Stratigraphic aspects of petroleum resource assessmen [C]//RICE D D (Eds.). Oil and gas assessment(SG21):methods and applications. Oklahoma:AAPG Studies in Geology, 1986: 59-68.
[20]	胡朝元 . 生油区控制油气田分布:中国东部陆相盆地进行区域勘探的有效理论[J]. 石油学报, 1982,3(2):9-13.
	HU Chaoyuan . Source bed controls hydrocarbon habitat in continental basins, east China[J]. Acta Petrolei Sinica, 1982,3(2):9-13.
[21]	贾承造, 邹才能, 杨智 , 等. 陆相油气地质理论在中国中西部盆地的重大进展[J]. 石油勘探与开发, 2018,45(4):546-560.
	JIA Chengzao, ZOU Caineng, YANG Zhi , et al. Significant progress of continental petroleum geology theory in basins of central and western China[J]. Petroleum Exploration and Development, 2018,45(4):546-560.
[22]	MAGOON L B. The petroleum system:a classification scheme for research, exploration, and resource assessment [C]//MAGOON L B (Eds.). Petroleum systems of the United States. Washington:United States Government Printing Office, 1988: 2-15.
[23]	MAGOON L B, DOW W G. The petroleum system [C]//MAGOON L B, DOW W G (Eds.). The petroleum system:from source to trap. Tulsa:American Association of Petroleum Geologists, 1994: 3-24.
[24]	赵文智, 何登发, 瞿辉 , 等. 复合含油气系统中油气运移流向研究的意义[J]. 石油学报, 2001,22(4):7-12.
	ZHAO Wenzhi, HE Dengfa, QU Hui , et al. Study on the pathways of hydrocarbon migration of the composite petroleum system[J]. Acta Petrolei Sinica, 2001,22(4):7-12.
[25]	MAGOON L B, SCHMOKER J W . The total petroleum system:the natural fluid network that constrains the assessment unit[J]. US Geological Survey World Petroleum Assessment, 2000.
[26]	WANDREY C J, LAW B E, SHAH H A . Patala-nammal composite total petroleum system, Kohat-Potwar geologic province, Pakistan[J]. US Geological Survey Bulletin, 2004,22(8):1-20.
[27]	LAW B E, CURTIS J B . Introduction to unconventional petroleum systems[J]. AAPG Bulletin, 2002,86(11):1 851-1 852.
[28]	ZOU Caineng, YANG Zhi, DONG Dazhong , et al. The characteristics and significance of conventional and unconventional Sinian-Silurian gas systems in the Sichuan basin, central China[J]. Marine and Petroleum Geology, 2015,64(3):386-402.
[29]	唐勇, 郭文建, 王霞田 , 等. 玛湖凹陷砾岩大油区勘探新突破及启示[J]. 新疆石油地质, 2019,40(2):127-137.
	TANG Yong, GUO Wenjian, WANG Xiatian , et al. A new breakthrough in exploration of large conglomerate oil province in Mahu sag and its implications[J]. Xinjiang Petroleum Geology, 2019,40(2):127-137.
[30]	杨迪生, 肖立新, 阎桂华 , 等. 准噶尔盆地南缘四棵树凹陷构造特征与油气勘探[J]. 新疆石油地质, 2019,40(2):138-144.
	YANG Disheng, XIAO Lixin, YAN Guihua , et al. Structural characteristics and petroleum exploration in Sikeshu sag, southern margin of Junggar basin[J]. Xinjiang Petroleum Geology, 2019,40(2):138-144.

资源类型	成藏位置	成藏方式	运聚动力	储集层岩性	孔隙直径/μm	临界喉道半径/nm	渗流方式	分布特征	分布位置
常规油气	远源	浮力成藏	浮力	砂砾岩含砾砂岩	>10.0	>100	达西流	单体式集合式	断裂带及斜坡区
致密油气	近源	活塞式成藏	浮力、生烃压力	粉砂质白云岩白云质粉砂岩	0.5~10.0	50~100	非达西流	准连续式	斜坡区
页岩油气	源内	源内滞留成藏	生烃压力	白云质泥岩白云质页岩	<0.5	<50	非达西流	连续式	凹陷区
