Mineral Features of Chlorite and Laumontite and Their Impacts on Reservoir Physical Properties: A Case Study of Lower Wuerhe Formation in Western Luliang Uplift, Junggar Basin

doi:10.7657/XJPG20250102

Abstract

Abstract:

In order to enhance the understanding of mineral features of chlorite and laumontite in the lower Wuerhe formation of Permian in the western Luliang uplift, Junggar Basin, the chemical composition, occurrence states, and impacts on reservoir physical properties were studied by means of thin section, electron probe and X-ray diffraction. It is found that the chlorite has an trioctahedral crystal structure and occurs in three states: pore lining, particle coating, and pore filling. It is classified as an iron-magnesium transitional type, richer in magnesium. Fe replacing Mg mainly occurs in the octahedrons, with the Al/(Al+Mg+Fe) ratio ranging from 0.25 to 0.37. The forming of chlorite is attributed to the alteration of argillaceous rocks and the transformation of mafic rocks, with substantial material input from the hydrolytic dissolution of tuffaceous volcanic materials and the interconversion of clay minerals. Laumontite occurs in three states: crystal aggregate, filling, and replacement. The laumontite in crystal aggregate state is surrounded by numerous debris, which promotes the formation of laumontite. The laumontite in filling state coexists with chlorite, calcite and other minerals, which compete with them for material sources, partially inhibiting the formation of laumontite. The laumontite in replacement state is mainly formed by the replacement of feldspar and debris, resulting in high Si/Al ratio and good acid resistance, which allow the laumontite to be not easily dissolved. Chlorite and laumontite have dual effects on reservoir physical properties. Chlorite can significantly improve reservoir physical properties, resulting in the formation of high-quality reservoirs. In contrast, the effect of laumontite on reservoir properties is limited. With the increase of burial depth, the lower Wuerhe formation presents a variation in diagenetic environment from alkaline to weakly acidic and then to alkaline, with a relatively closed diagenetic system.

Key words: Junggar Basin, Luliang uplift, lower Wuerhe formation, chlorite, laumontite, occurrence state, reservoir physical property

CLC Number:

TE122.21

NIU Jun, WANG Cong, LIANG Fei. Mineral Features of Chlorite and Laumontite and Their Impacts on Reservoir Physical Properties: A Case Study of Lower Wuerhe Formation in Western Luliang Uplift, Junggar Basin[J]. Xinjiang Petroleum Geology, 2025, 46(1): 13-21.

Figures/Tables 10

Fig. 1.

Fig. 2.

Fig. 3.

Table 1.

Fig. 4.

Fig. 5.

Fig. 6.

Table 2.

Fig. 7.

Fig. 8.

References 28

[1]	李峰, 姜振学, 肖中尧, 等. 塔里木盆地满东1致密气藏成因机制[J]. 天然气地球科学, 2014, 25(10):1568-1576. doi: 10.11764/j.issn.1672-1926.2014.10.1568
	LI Feng, JIANG Zhenxue, XIAO Zhongyao, et al. Genetic mechanism of Mandong 1 tight gas reservoir in Tarim Basin[J]. Natural Gas Geoscience, 2014, 25(10):1568-1576. doi: 10.11764/j.issn.1672-1926.2014.10.1568
[2]	卞保力, 吴和源, 李娜, 等. 准噶尔盆地玛湖凹陷东斜坡中二叠统扇三角洲储层特征与成因[J]. 新疆地质, 2017, 35(3):306-312.
	BIAN Baoli, WU Heyuan, LI Na, et al. Characteristics and origin of the middle Permian fan-delta reservoir in eastern slope area of Mahu sag,Junggar Basin[J]. Xinjiang Geology, 2017, 35(3):306-312.
[3]	瞿建华, 钱海涛, 李鹏, 等. 玛湖凹陷百口泉组砾岩自生绿泥石成因及其对储集层物性的影响[J]. 新疆石油地质, 2017, 38(5):519-523.
	QU Jianhua, QIAN Haitao, LI Peng, et al. Genesis of authigenic chlorite and its influence on reservoir physical properties in conglomerates of Baikouquan formation,Mahu sag[J]. Xinjiang Petroleum Geology, 2017, 38(5):519-523.
[4]	雷海艳, 樊顺, 鲜本忠, 等. 玛湖凹陷二叠系下乌尔禾组沸石成因及溶蚀机制[J]. 岩性油气藏, 2020, 32(5):102-112.
	LEI Haiyan, FAN Shun, XIAN Benzhong, et al. Genesis and corrosion mechanism of zeolite of lower Wuerhe formation of Permian in Mahu sag[J]. Lithologic Reservoirs, 2020, 32(5):102-112.
[5]	乔江华. 碎屑岩中的自生绿泥石及其对储层影响研究[J]. 辽宁化工, 2019, 48(2):143-147.
	QIAO Jianghua. Chlorite in clastic rocks and its influence on reservoirs[J]. Liaoning Chemical Industry, 2019, 48 (2):143-147.
[6]	郭晖, 纪宝强, 杨森, 等. 准噶尔盆地环玛湖凹陷二叠系砂砾岩储层沸石类胶结物的形成及石油地质意义[J]. 石油学报, 2022, 43(3):341-354. doi: 10.7623/syxb202203002
	GUO Hui, JI Baoqiang, YANG Sen, et al. Formation of zeolite cement in Permian sandy conglomerate reservoir in the circum-Mahu sag,Junggar Basin and its petroleum geological significance[J]. Acta Petrolei Sinica, 2022, 43(3):341-354.
[7]	何登发, 张磊, 吴松涛, 等. 准噶尔盆地构造演化阶段及其特征[J]. 石油与天然气地质, 2018, 39(5):845-861.
	HE Dengfa, ZHANG Lei, WU Songtao, et al. Tectonic evolution stages and features of the Junggar Basin[J]. Oil & Gas Geology, 2018, 39(5):845-861.
[8]	钱海涛, 尤新才, 魏云, 等. 玛东地区百口泉组地层新认识及油气勘探意义[J]. 西南石油大学学报(自然科学版), 2020, 42(2):27-36.
	QIAN Haitao, YOU Xincai, WEI Yun, et al. The new understanding and exploration significance in Triassic Baikouquan formation of eastern Mahu sag[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 2020, 42(2):27-36.
[9]	邹妞妞, 张大权, 姜杨, 等. 准噶尔玛东地区下乌尔禾组储层成岩作用与孔隙演化[J]. 地质科技情报, 2015, 34(1):42-48.
	ZOU Niuniu, ZHANG Daquan, JIANG Yang, et al. Diagenesis and porosity evolution of Permian lower Urho formation reservoir in the Madong area,Junggar Basin[J]. Geological Science and Technology Information, 2015, 34(1):42-48.
[10]	王剑, 靳军, 张宝真, 等. 玛湖凹陷东斜坡区下乌尔禾组砂砾岩储层孔隙形成机理及优势储层成因分析[J]. 科学技术与工程, 2015, 15(23):136-142.
	WANG Jian, JIN Jun, ZHANG Baozhen, et al. Pore formation mechanism and genesis of advantage reservoir of Permian lower Urho formation glutenite reservoir in the Madong area,Junggar Basin[J]. Science Technology and Engineering, 2015, 15(23):136-142.
[11]	张永波, 佟莹, 王东学, 等. 准噶尔盆地玛湖凹陷东斜坡夏子街组油气成藏条件及下步勘探方向[J]. 大庆石油地质与开发, 2022, 41(4):12-19.
	ZHANG Yongbo, TONG Ying, WANG Dongxue, et al. Hydrocarbon accumulation conditions and future exploration direction of Xiazijie formation in east slope of Mahu sag in Junggar Basin[J]. Petroleum Geology & Development in Daqing, 2022, 41(4):12-19.
[12]	曾淑明, 张艳, 韩润生, 等. 滇西南翁孔坝铜多金属矿床绿泥石特征及其地质意义[J]. 矿床地质, 2023, 42(4):828-844.
	ZENG Shuming, ZHANG Yan, HAN Runsheng, et al. Characteristics and geological significance of chlorite in the Wengkongba copper polymetallic deposit,southwest Yunnan[J]. Mineral Deposit, 2023, 42(4):828-844.
[13]	刘强, 赵葵东, 刘国奇, 等. 赣南草桃背铀矿床中绿泥石地球化学特征及成矿指示意义[J]. 高校地质学报, 2022, 28(6):874-893.
	LIU Qiang, ZHAO Kuidong, LIU Guoqi, et al. Geochemical characteristics and metallogenic indications of chlorite in Caotaobei uranium deposit in southern Jiangxi province[J]. Journal of Geology of China Universities, 2022, 28(6):874-893.
[14]	ZANG W, FYFE W S. Chloritization of the hydrothermally altered bedrock at the Igarape Bahia gold deposite,Carajas,Brazil[J]. Mineralium Deposita, 1995, 30(1):30-38.
[15]	XIE Xiaogong, BYERLY G R, FERRELL R E. Ⅱb trioctahedral chlorite from the Barberton greenstone belt:Crystal structure and rock composition constraints with implications to geothermometry[J]. Contributions to Mineralogy and Petrology, 1997, 126(3):275-291.
[16]	潘春蓉, 牟平, 钟福军, 等. 南岭中段黄沙铀矿区绿泥石成因及其与铀成矿关系[J]. 中国地质, 2020, 47(2):348-361.
	PAN Chunrong, MOU Ping, ZHONG Fujun, et al. Genesis of chlorite in the Huangsha uranium deposit,middle part of Nanling and relationship with uranium mineralization[J]. Geology in China, 2020, 47(2):348-361.
[17]	刘松岩, 张达, 杨明建, 等. 熊耳山矿集区蒿坪沟Ag-Au多金属矿床绿泥石特征及其找矿意义[J]. 地质力学学报, 2024, 30(1):129-146.
	LIU Songyan, ZHANG Da, YANG Mingjian, et al. Characteristics of chlorite from the Haopinggou Ag-Au polymetallic deposit in the Xiong’ershan ore concentration area and its exploration implications[J]. Journal of Geomechanics, 2018, 30(1):129-146.
[18]	张伟, 张寿庭, 曹华文, 等. 滇西小龙河锡矿床中绿泥石矿物特征及其指示意义[J]. 成都理工大学学报(自然科学版), 2014, 41(3):318-328.
	ZHANG Wei, ZHANG Shouting, CAO Huawen, et al. Characteristics of chlorite minerals from Xiaolonghe tin deposit in west Yunnan,China and their geological implications[J]. Journal of Chengdu University of Technology(Science & Technology Edition), 2014, 41(3):318-328.
[19]	张霞, 林春明, 陈召佑. 鄂尔多斯盆地镇泾区块上三叠统延长组砂岩中绿泥石矿物特征[J]. 地质学报, 2011, 85(10):1659-1671.
	ZHANG Xia, LIN Chunming, CHEN Zhaoyou. Characteristics of chlorite minerals from Upper Triassic Yanchang formation in the Zhenjing area,Ordos Basin[J]. Acta Geologica Sinica, 2011, 85 (10):1659-1671.
[20]	祁利祺, 张晓童, 张浩宇, 等. 阜东斜坡区齐古组自生绿泥石的赋存状态与影响因素[J]. 岩石矿物学杂志, 2023, 42(6):826-837.
	QI Liqi, ZHANG Xiaotong, ZHANG Haoyu, et al. The occurrence status and influencing factors of autogenic chlorite in the Qigu formation of the Fudong slope area[J]. Acta Petrologica et Mineralogica, 2023, 42(6):826-837.
[21]	田建锋, 高永利, 张蓬勃, 等. 鄂尔多斯盆地合水地区长7致密油储层伊利石成因[J]. 石油与天然气地质, 2013, 34(5):700-707.
	TIAN Jianfeng, GAO Yongli, ZHANG Pengbo, et al. Genesis of illite in Chang 7 tight oil reservoir in Heshui area,Ordos Basin[J]. Oil & Gas Geology, 2013, 34(5):700-707.
[22]	田建锋, 喻建, 张志国. 砂岩中碱性溶蚀研究进展[J]. 地质科技通报, 2022, 41(5):83-93.
	TIAN Jianfeng, YU Jian, ZHANG Zhiguo. Advance in alkaline dissolution of sandstone[J]. Bulletin of Geological Science and Technology, 2022, 41(5):83-93.
[23]	郭沫贞, 寿建峰, 徐洋, 等. 准噶尔盆地中拐—西北缘地区二叠系沸石胶结物分布与控制因素[J]. 石油学报, 2016, 37(6):695-705. doi: 10.7623/syxb201606001
	GUO Mozhen, SHOU Jianfeng, XU Yang, et al. Distribution and controlling factors of Permian zeolite cement in Zhongguai-northwest margin of Junggar Basin[J]. Acta Petrolei Sinica, 2016, 37(6):695-705. doi: 10.7623/syxb201606001
[24]	况昊, 周元东, 刘豪, 等. 沙湾凹陷砂砾岩沸石胶结物与碎屑颗粒粘结差异成因分析[J]. 新疆石油地质, 2024, 45(2):163-171.
	KUANG Hao, ZHOU Yuandong, LIU Hao, et al. Genesis of differential bonding between zeolite cements and clastic particles in sandy conglomerates in Shawan sag,Junggar Basin[J]. Xinjiang Petroleum Geology, 2024, 45(2):163-171.
[25]	张雪花, 黄思静, 兰叶芳, 等. 浊沸石溶解过程的热力学计算及地质意义[J]. 岩性油气藏, 2011, 23(2):64-69.
	ZHANG Xuehua, HUANG Sijing, LAN Yefang, et al. Thermodynamic calculation of laumontite dissolution and its geological significance[J]. Lithologic Reservoirs, 2011, 23(2):64-69.
[26]	丁波, 刘红旭, 李平, 等. 伊犁蒙其古尔铀矿床含矿层砂岩中高岭石形成机制及与铀成矿关系[J]. 地质学报, 2019, 93(8):2020-2036.
	DING Bo, LIU Hongxu, LI Ping, et al. The genetic mechanism of kaolinite in ore-bearing sandstone in the Mengqigur uranium deposit,Yili,and its relation with uranium mineralization[J]. Acta Geologica Sinica, 2019, 93(8):2020-2036.
[27]	况昊, 周润驰, 王钧民, 等. 玛湖凹陷与沙湾凹陷上乌尔禾组储集层差异及成因[J]. 新疆石油地质, 2023, 44(1):18-24.
	KUANG Hao, ZHOU Runchi, WANG Junmin, et al. Differences and genesis of upper Wuerhe formation reservoirs in Mahu sag and Shawan sag[J]. Xinjiang Petroleum Geology, 2023, 44(1):18-24.
[28]	王涛, 张生银, 魏璞, 等. 沸石类矿物成因及其对储层储集性能的影响[J]. 岩性油气藏, 2022, 34(1):175-186.
	WANG Tao, ZHANG Shengyin, WEI Pu, et al. Genesis of zeolite minerals and its influences on reservoir performances[J]. Lithologic Reservoirs, 2022, 34(1):175-186.

井名	测点	产状	含量测试结果/%
井名	测点	产状	SiO₂	Al₂O₃	MgO	FeO	Na₂O	CaO	K₂O	MnO	TiO₂	NiO	合计
XY2井	18-1	孔隙充填式	31.04	16.37	20.55	18.16	0.03	0.40	0.02	0.61	0.03	0.06	87.27
XY2井	18-7	孔隙充填式	30.84	15.42	20.69	17.56	0.03	0.42	0.03	0.58	0.02	0.09	85.68
YB4井	61-3	颗粒包膜式	30.57	18.04	18.98	18.10	0.01	0.47	0.01	0.27	0.05	0	86.50
	61-9	孔隙衬里式	30.15	12.72	17.67	23.52	0.09	0.29	0	0.42	0.05	0.16	85.07
	61-11	颗粒包膜式	33.87	14.29	31.31	6.42	0.05	0.42	0.03	0.12	0	0.04	86.55
	61-12	颗粒包膜式	32.23	20.84	18.10	17.54	0.06	0.40	0.04	0.25	0.05	0	89.51
M218井	59-3	孔隙衬里式	29.82	19.39	14.82	21.36	0.03	0.40	0.06	0.25	0	0.03	86.16
Y001井	21-3	孔隙衬里式	29.56	15.48	23.28	19.55	0	0.45	0.04	0.52	0	0.04	88.92

井名	测点	产状	含量测试结果/%											Si/Al
井名	测点	产状	SiO₂	Al₂O₃	MgO	FeO	Na₂O	CaO	K₂O	TiO₂	NiO	MnO	合计	Si/Al
YB4井	61-1	连晶状	57.48	21.20	0.04	0.04	0.29	10.25	0.06	0.02	—	—	89.38	2.16
	61-2	连晶状	53.56	20.56	—	0.04	0.17	11.09	0.02	0.02	0.02	0.02	85.50	2.08
	61-4	连晶状	53.91	20.64	0.04	0.06	0.24	10.81	0.07	0.03	—	—	85.80	2.08
	65-5	连晶状	53.61	20.37	—	—	0.05	10.43	0.05	0.02	0.04	—	84.57	2.10
	65-7	连晶状	52.58	20.52	0.04	0.05	0.07	10.85	0.03	—	—	0.02	84.16	2.04
	65-4	充填状	52.06	20.63	—	0.07	—	11.30	—	0.03	—	—	84.09	2.01
	65-6	充填状	56.44	20.72	0.05	0.14	0.21	10.38	0.06	—	—	0.02	88.02	2.17
	68-2	充填状	54.32	20.19	—	0.12	0.28	10.49	0.08	—	—	—	85.48	2.14
	68-6	充填状	53.77	20.98	0.06	0.12	0.02	11.21	—	—	—	—	86.16	2.04
XY2井	18-4	交代状	53.10	20.23	—	0.13	0.25	10.38	0.10	0.03	—	—	84.22	2.09
XY2井	18-5	交代状	53.20	19.39	0.02	0.03	0.52	10.11	0.14	—	0.02	—	83.43	2.19
Y001井	21-1	交代状	54.10	20.03	0.05	—	0.30	10.27	0.17	—	0.04	—	84.96	2.15
Y001井	21-2	交代状	53.32	19.53	—	0.08	0.32	10.43	0.12	—	0.02	—	83.82	2.17
