低渗稠油油藏CO2表面活性剂复合吞吐开发——以克拉玛依油田五区南上乌尔禾组油藏为例

doi:10.7657/XJPG20220208

摘要/Abstract

摘要：

克拉玛依油田五区南上乌尔禾组油藏为低孔低渗稠油油藏,储集层物性差,注水开发产量递减快,地层能量保持程度低,后油井全面关停。近年来重新压裂复产,初期效果显著,但产量递减率高。为解决油井低产低效的问题,开展CO₂表面活性剂复合吞吐技术研究,并进行提产试验。在增油机理实验的基础上,应用多组分油藏数值模拟技术,对CO₂表面活性剂复合注入方式及参数进行优化;建立了增产油量随不同吞吐周期注入量、注气速度、焖井时间、开采强度等参数变化的响应关系,确定了复合吞吐的最佳注入参数。矿场实施后,单井自喷达240 d,增产原油630 t,补充地层能量、改善流动性的效果显著,可供同类油藏开发参考。

关键词: 克拉玛依油田, 上乌尔禾组, 低渗稠油油藏, CO₂, 表面活性剂, 复合吞吐, 数值摸拟, 采收率

Abstract:

The reservoir in the upper Wuerhe formation, southern Block 5, Karamay oilfield, is a heavy oil reservoir with low porosity and low permeability, indicating poor reservoir physical properties. When it was developed by water injection, the production decreased rapidly, and the formation energy kept low; as a result, all production wells were shut in or suspended. In recent years, some wells have been refractured to resume production and good effects have been gained in the initial stage, but the production declines rapidly. In order to solve the problems of low production and low efficiency of production wells, the CO₂ + surfactant combination huff and puff technology was developed and tested for production enhancement. On the basis of experiment on stimulation mechanism, through multi-component reservoir numerical simulation, the method and parameters for injecting CO₂ + surfactant were optimized. The relationship between the changes of the production increment and the parameters such as injection volume, injection rate, soaking period and production intensity in different cycles of huff and puff were established, and the optimal parameters for injecting CO₂ + surfactant were determined for huff and puff. Field application reveals a natural flow of a sing well for 240 days and an incremental oil production of 630 t. It is concluded that the CO₂ + surfactant combination huff and puff technology can effectively supplement formation energy and improve fluid mobility, which can be used as a reference for the development of similar reservoirs.

Key words: Karamay oilfield, upper Wuerhe formation, low-permeability heavy oil reservoir, CO₂, surfactant, composite huff and puff numerical simulation, recovery rate

中图分类号:

TE384

黄伟强. 低渗稠油油藏CO₂表面活性剂复合吞吐开发——以克拉玛依油田五区南上乌尔禾组油藏为例[J]. 新疆石油地质, 2022, 43(2): 183-187.

HUANG Weiqiang. Development of Low-Permeability Heavy Oil Reservoirs by CO₂ + Surfactant Combination Huff and Puff : A Case Study of Upper Wuerhe Formation Reservoir in Southern Block 5, Karamay Oilfield[J]. Xinjiang Petroleum Geology, 2022, 43(2): 183-187.

图/表 6

表1

表2

图1

图2

图3

图4

参考文献 19

[1]	宋传真, 林长志, 王元庆, 等. 低渗稠油油藏蒸汽-CO₂-化学剂复合吞吐研究[J]. 成都理工大学学报(自然科学版), 2016, 43(3):336-343.
	SONG Chuanzhen, LIN Changzhi, WANG Yuanqing, et al. Study on composite steam stimulation with carbon dioxide and chemical agents of low permeability heavy oil reservoir[J]. Journal of Chengdu University of Technology(Science & Technology Edition), 2016, 43(3):336-343.
[2]	陈德春, 周淑娟, 孟红霞, 等. 陈家庄油田陈373块蒸汽吞吐后转CO₂-化学剂复合吞吐研究[J]. 油气地质与采收率, 2014, 21(6):76-78.
	CHEN Dechun, ZHOU Shujuan, MENG Hongxia, et al. Research on compound stimulation of CO₂-chemical after steam stimulation for Chen373 block[J]. Petroleum Geology and Recovery Efficiency, 2014, 21(6):76-78.
[3]	张娜, 朱元芮, 祝仰文, 等. 基于井筒离散模型的多元热流体吞吐机理[J]. 新疆石油地质, 2020, 41(3):332-336.
	ZHANG Na, ZHU Yuanrui, ZHU Yangwen, et al. Multiple thermal fluid huff-puff mechanism based on discrete wellbore model[J]. Xinjiang Petroleum Geology, 2020, 41(3):332-336.
[4]	彭彩珍, 李超, 杨栋. 低渗透油藏二氧化碳吞吐选井研究[J]. 油气藏评价与开发, 2017, 7(1) :32-35.
	PENG Caizhen, LI Chao, YANG Dong, Well selection of CO₂ huff and puff in low permeability reservoir[J]. Reservoir Evaluation and Development, 2017, 7(1):32-35.
[5]	袁旭军, 叶晓端, 鲍为, 等. 低渗透油田开发的难点和主要对策[J]. 钻采工艺, 2006, 29(4):31-32.
	YUAN Xujun, YE Xiaoduan, BAO Wei, et al. Difficulties and main countermeasures of low permeability oilfield development[J]. Drilling and Production Technology, 2006, 29(4):31-32.
[6]	李相远, 李向良, 郭平, 等. 低渗透稀油油藏二氧化碳吞吐选井标准研究[J]. 油气地质与采收率, 2001, 8(5):66-68.
	LI Xiangyuan, LI Xiangliang, GUO Ping, et al. Study on well selection criterion of CO₂ stimulation in thin oil reservoirs with low permeability[J]. Petroleum Geology and Recovery Efficiency, 2001, 8(5):66-68.
[7]	克林斯M A. 二氧化碳驱油机理及工程设计[M]. 程绍进,译. 北京: 石油工业出版社, 1993.
	COLLINS M A. Carbon dioxide flooding mechanism and engineering design [M]. Translated by CHENG Shaojin. Beijing: Petroleum Industry Press, 1993.
[8]	杨承志, 岳清山, 沈平平. 混相驱提高石油采收率[M]. 北京: 石油工业出版社, 1993.
	YANG Chengzhi, YUE Qingshang, SHEN Pingping. Miscible EOR by miscible flooding[M]. Beijing: Petroleum Industry Press, 1993.
[9]	蒲万芬, 汪洋松, 李龙威, 等. 致密砾岩油藏超临界CO₂吞吐开发可行性[J]. 新疆石油地质, 2021, 42(4):456-461.
	PU Wanfen, WANG Yangsong, LI Longwei, et al. Feasibility of supercritical CO₂ huff-puff development of tight conglomerate reservoirs[J]. Xinjiang Petroloeum Geology, 2021, 42(4):456-461.
[10]	王涛, 姚约东, 李相方, 等. 二氧化碳驱油效果影响因素与分析[J]. 中国石油和化工, 2008, 24:30-33.
	WANG Tao, YAO Yuedong, LI Xiangfang, et al. Influencing factors and analysis of carbon dioxide flooding effect[J]. China Petroleum and Chemical Industry, 2008, 24:30-33.
[11]	吕广忠, 伍增贵, 栾志安, 等. 吉林油田CO₂试验区数值模拟和方案设计[J]. 石油钻采工艺, 2002, 24(4):39-41.
	LV Guangzhong, WU Zenggui, LUAN Zhian, et al. Simulation study to design CO₂ flood plot in Jilin oilfield[J]. Oil Drilling & Production Technology, 2002, 24(4):39-41.
[12]	钱卫明, 余峰, 季翔, 等. 溱潼凹陷复杂断块油藏CO₂吞吐试验[J]. 油气地质与采收率, 2002, 9(2):80-82.
	QIAN Weiming, YU Feng, JI Xiang, et al. Experiments of CO₂ stimulation in the complex fault block oil reservoirs of Qintong sag[J]. Petroleum Geology and Recovery Efficieng, 2002, 9(2):80-82.
[13]	李士伦, 周守信, 杜建芬, 等. 国内外注气提高石油采收率技术回顾与展望[J]. 油气地质与采收率, 2002, 9(2):1-5.
	LI Shilun, ZHOU Shouxin, DU Jianfen, et al. Review and prospects for the development of EOR by gas injection at home and abroad[J]. Petroleum Geology and Recovery Efficiency, 2002, 9(2):1-5.
[14]	谈士海, 周正平, 刘伟, 等. 复杂断块油藏CO₂吞吐试验及效果分析[J]. 石油钻采工艺, 2002, 24(4):56-59.
	TAN Shihai, ZHOU Zhengping, LIU Wei, et al. Experiment and effect analysis of CO₂ huff and puff in complex fault block reservoir[J]. Oil Drilling & Production Technology, 2002, 24(4):56-59.
[15]	杨胜来, 王亮, 何建军, 等. CO₂吞吐增油机理及矿场应用效果[J]. 西安石油大学学报(自然科学版), 2004, 19(6):23-26.
	YANG Shenglai, WANG Liang, HE Jianjun, et al. Oil production enhancing mechanism and field applying result of carbon dioxide huff-puff[J]. Journal of Xi’an Shiyou University(Natural Science Edition), 2004, 19(6):23-26.
[16]	钟立国, 韩大匡, 李莉. 人工压裂低渗透油藏二氧化碳吞吐因素敏感性分析[J]. 大庆石油学院学报, 2009, 33(4):125-129.
	ZHONG Liguo, HAN Dakuang, LI Li. Analysis of the sensitivity of carbon dioxide huff‘n’puff for fractured reservoirs with low permeability[J]. Journal of Daqing Petroleum Institute, 2009, 33(4):125-129.
[17]	张绍辉, 王凯, 王玲, 等. CO₂驱注采工艺的应用与发展[J]. 石油钻采工艺, 2016, 38(6):869-875.
	ZHANG Shaohui, WANG Kai, WANG Ling, et al. Development and application of CO₂ flooding[J]. Oil Drilling & Production Technology, 2016, 38(6):869-875.
[18]	罗二辉, 胡永乐, 李保柱, 等. 中国油气田注CO₂提高采收率实践[J]. 特种油气藏, 2013, 20(2):1-7.
	LUO Erhui, HU Yongle, LI Baozhu, et al. Practices of CO₂ EOR in China[J]. Special Oil & Gas Reservoirs, 2013, 20(2):1-7.
[19]	冉新权, 赵继勇, 何永宏, 等. 超低渗透油藏CO₂驱混相范围确定新方法[J]. 西南石油大学学报, 2011, 33(5):89-93.
	RAN Xinquan, ZHAO Jiyong, HE Yonghong, et al. New method for determining the range of CO₂ miscible drive in the extra-low permeability reservoir[J]. Journal of Southwest Petroleum University, 2011, 33(5):89-93.
