沉积岩致密油藏压裂裂缝导流能力及产能模型

doi:10.7657/XJPG20230408

摘要/Abstract

摘要：

为明确不同类型沉积岩储集层压裂开发后导流能力的变化规律，通过开展浊积岩、滩坝砂、砂砾岩等沉积岩压裂后导流能力测试实验，分析了岩性与导流能力之间的关系，构建了导流能力模型。将导流能力模型引入主裂缝压力控制方程，得到主裂缝压力解析解;应用分布式体源方法建立了水平井多段压裂产能预测半解析模型。将新产能预测模型应用于大庆长垣外围朝阳沟油田致密油藏，数值模拟模型、不考虑岩性产能模型和考虑岩性产能新模型的计算误差分别为6.5%、22.7%和4.6%，新的模型侧重于不同沉积岩岩性对产能的影响，提高了致密油藏产能预测精度。

关键词: 朝阳沟油田, 致密油藏, 多段压裂, 岩性分析, 长期导流能力, 产能模型, 水平井开发, 体源法

Abstract:

In order to clarify the variation in the conductivity of different types of sedimentary rocks after fracturing, post-frac conductivity tests were conducted on the sedimentary rocks such as turbidite, beach-bar sandstone, and sandy conglomerate to identify the relationship between lithology and conductivity, and a conductivity model was constructed. The conductivity model was then incorporated into the primary fracture pressure control equation to obtain an analytical solution for primary fracture pressure. A semi-analytical model for predicting the productivity of multi-stage fractured horizontal wells was developed by using the distributed volume source method. The new productivity model was applied to the tight oil reservoirs in the Chaoyanggou oilfield in the periphery of Changyuan, Daqing. It is found that the calculation errors from a numerical model, a productivity model without considering lithology and the new productivity model considering lithology are 6.5%, 22.7% and 4.6%, respectively. The new model focuses on the impact of different sedimentary rock lithologies on productivity, which can improve the accuracy of productivity prediction for tight oil reservoirs.

Key words: Chaoyanggou oilfield, tight oil reservoir, multi-stage fracturing, lithology analysis, long-term conductivity, productivity model, horizontal well development, volume source method

中图分类号:

TE33

王小兵, 胡炎射, 李森, 陈敏, 王路, 朱晨阳. 沉积岩致密油藏压裂裂缝导流能力及产能模型[J]. 新疆石油地质, 2023, 44(4): 442-449.

WANG Xiaobing, HU Yanshe, LI Sen, CHEN Min, WANG Lu, ZHU Chenyang. Models for Conductivity and Productivity of Hydraulic Fractures in Tight Oil Reservoirs in Sedimentary Rocks[J]. Xinjiang Petroleum Geology, 2023, 44(4): 442-449.

图/表 11

表1

图1

图2

图3

表2

图4

表3

图5

图6

图7

表4

参考文献 28

[1]	REN Junjie, GAO Yangyang, ZHENG Qiao, et al. Pressure transient analysis for a finite-conductivity fractured vertical well near a leaky fault in anisotropic linear composite reservoirs[J]. Journal of Energy Resources Technology, 2020, 142(7):073002. doi: 10.1115/1.4046456
[2]	MUTHER T, FAHAD I S, DAHAGHI A K, et al. Socio-inspired multi-cohort intelligence and teaching-learning-based optimization for hydraulic fracturing parameters design in tight formations[J]. Journal of Energy Resources Technology, 2022, 144(7):073201. doi: 10.1115/1.4052182
[3]	WANG Wendong, SHAHVALI M, SU Yuliang. Analytical solutions for a quad-linear flow model derived for multistage fractured horizontal wells in tight oil reservoirs[J]. Journal of Energy Resources Technology, 2017, 139(1):012905. doi: 10.1115/1.4033860
[4]	OBINNA E D, HASSAN D. Characterizing tight oil reservoirs with Dual and Triple-Porosity models[J]. Journal of Energy Resources Technology, 2016, 138(3):032801. doi: 10.1115/1.4032520
[5]	LIN Hun, ZHOU Xiang, CHEN Yulong, et al. Investigation of the factors influencing the flowback ratio in shale gas reservoirs:A study based on experimental observations and numerical simulations[J]. Journal of Energy Resources Technology, 2021, 143(11):113201. doi: 10.1115/1.4049605
[6]	HE Youwei, QIAO Yu, QIN Jiazheng, et al. A novel method to enhance oil recovery by inter-fracture injection and production through the same multi-fractured horizontal well[J]. Journal of Energy Resources Technology, 2022, 144(4):043005. doi: 10.1115/1.4051623
[7]	MURPHY H D, LAWTON R G. Downhole measurements of thermal conductivity in geothermal reservoirs[J]. Journal of Energy Resources Technology, 1977, 99(4):607-611.
[8]	宿晓岑, 巩磊, 高帅, 等. 陇东地区长7段致密储集层裂缝特征及定量预测[J]. 新疆石油地质, 2021, 42(2):161-167.
	SU Xiaocen, GONG Lei, GAO Shuai, et al. Characteristics and quantitative prediction of fractures of tight reservoir in Chang 7 member in Longdong area[J]. Xinjiang Petroleum Geology, 2021, 42(2):161-167.
[9]	PRASUN S, WOJTANOWICZ K. Stabilized water-cut in carbonate naturally fractured reservoirs with bottom water with an implication in well spacing design for recovery optimization[J]. Journal of Energy Resources Technology, 2020, 142(3):033003. doi: 10.1115/1.4045922
[10]	ASADI M B, AMERI M J, ZENDEHBOUDI S. Determination of performance of multiple-fracture horizontal well by incorporating fracture-fluid leakoff[J]. SPE Reservoir Evaluation & Engineering, 2018, 21(4):907-926.
[11]	WARREN J, ROOT P, ROOT J. The behavior of naturally fractured reservoirs[J]. Society of Petroleum Engineers Journal, 1963, 3(3):245-255. doi: 10.2118/426-PA
[12]	WANG Chengwen, WANG Yanji, KURU E, et al. A new low-damage drilling fluid for sandstone reservoirs with low-permeability:Formulation,evaluation,and applications[J]. Journal of Energy Resources Technology, 2021, 143(5):053004. doi: 10.1115/1.4048510
[13]	宋俊强, 李晓山, 王硕, 等. 致密油藏压裂水平井产量预测[J]. 新疆石油地质, 2022, 43(5):580-586.
	SONG Junqiang, LI Xiaoshan, WANG Shuo, et al. Production prediction of fractured horizontal wells in tight oil reservoirs[J]. Xinjiang Petroleum Geology, 2022, 43(5):580-586.
[14]	HOU Xuejun, ZHANG Xiaohui, GUO Boyun, et al. Mathematical modeling of fluid flow to unconventional oil wells with radial fractures and its testing with field data[J]. Journal of Energy Resources Technology, 2019, 141(7):1-8.
[15]	JIANG Yousi, DAHI-TALEGHANI A. Modified extended finite element methods for gas flow in fractured reservoirs:A pseudo-pressure approach[J]. Journal of Energy Resources Technology, 2018, 140(7):073101. doi: 10.1115/1.4039327
[16]	GHAMDI A L, AYALA B N, LUIS F H. Evaluation of transport properties effect on the performance of gas-condensate reservoirs using compositional simulation[J]. Journal of Energy Resources Technology, 2017, 139(3):032910. doi: 10.1115/1.4035905
[17]	董鹏, 陈志明, 于伟. 压裂后页岩油藏多裂缝直井产能模型:以鄂尔多斯盆地页岩油井为例[J]. 大庆石油地质与开发, 2022, 41(1):155-165.
	DONG Peng, CHEN Zhiming, YU Wei. Study on productivity model for multiple‐fracture vertical well in shale oil reservoirs after fractured:A case of shale oil wells in Ordos basin[J]. Petroleum Geology & Oilfield Development in Daqing, 2022, 41(1):155-165.
[18]	HOFMANN H, BABADAGLI T, ZIMMERMANN G. Numerical simulation of complex fracture network development by hydraulic fracturing in naturally fractured ultra tight formations[J]. Journal of Energy Resources Technology, 2014, 136(4):042905. doi: 10.1115/1.4028690
[19]	YANG Jun, WANG Xiangzeng, YANG Yongzhao, et al. An empirical model to estimate sweep efficiency of a surfactant-alternating-gas foam process in heterogeneous reservoirs[J]. Journal of Energy Resources Technology, 2019, 141(12):122902. doi: 10.1115/1.4043861
[20]	LIU Guangfeng, MENG Zhan, LI Xuejiao, et al. Experimental and numerical evaluation of water control and production increase in a tight gas formation with polymer[J]. Journal of Energy Resources Technology, 2019, 141(10):102903. doi: 10.1115/1.4043392
[21]	DEJAM M, HASSANZADEH H, CHEN Zhangxin, et al. Semi-analytical solutions for a partially penetrated well with wellbore storage and skin effects in a double-porosity system with a gas cap[J]. Transport in Porous Media, 2013, 100(2):159-192. doi: 10.1007/s11242-013-0210-6
[22]	VALKO P, AMINI S. The method of distributed volumetric sources for calculating the transient and pseudosteady-state productivity of complex well-fracture configurations[R]. SPE Hydraulic Fracturing Technology Conference,Society of Petroleum Engineers, 2007.
[23]	AMINI S, VALKO P P. Using distributed volumetric sources to predict production from multiple-fractured horizontal wells under non-Darcy-flow conditions[R]. SPE Journal, 2010.
[24]	马亮亮. 非均质致密油藏压裂水平井产能预测模型[J]. 大庆石油地质与开发, 2022, 41(4):168-174.
	MA Liangliang. Productivity prediction model for fractured horizontal well in heterogeneous tight oil reservoirs[J]. Petroleum Geology & Oilfield Development in Daqing, 2022, 41(4):168-174.
[25]	ASADI M B, DEJAM M, ZENDEHBOUDI S. Semi-analytical solution for productivity evaluation of a multi-fractured horizontal well in a bounded dual-porosity reservoir[J]. Journal of Hydrology, 2020, 581:124288. doi: 10.1016/j.jhydrol.2019.124288
[26]	HE Yongming, CHEN Xinchao, ZHANG Yue, et al. Modeling interporosity flow functions and shape factors in low-permeability naturally fractured reservoir[J]. Journal of Petroleum Science and Engineering, 2017, 156:110-117. doi: 10.1016/j.petrol.2017.05.006
[27]	WANG Lu, YANG Shenglai, MENG Zhan, et al. Time-dependent shape factors for fractured reservoir simulation:Effect of stress sensitivity in matrix system[J]. Journal of Petroleum Science and Engineering, 2018, 163:556-569. doi: 10.1016/j.petrol.2018.01.020
[28]	RANJBAR E, HASSANZADEH H. Matrix-fracture transfer shape factor for modeling flow of a compressible fluid in dual-porosity media[J]. Advances in Water Resources, 2011, 34(5):627-639. doi: 10.1016/j.advwatres.2011.02.012

岩性		石英含量	长石含量	岩屑含量
砂砾岩	粉细砂岩	35.1	34.3	30.6
	含砾砂岩	18.9	30.4	50.7
	砾质砂岩	20.8	25.4	53.8
	砾状砂岩	19.3	22.4	58.3
浊积岩		33.4	38.1	28.5
滩坝砂		68.9	11.4	19.7
