陆相页岩储集层岩石力学特性及能量演化特征

doi:10.7657/XJPG20230412

新疆石油地质 ›› 2023, Vol. 44 ›› Issue (4): 472-478.doi: 10.7657/XJPG20230412

陆相页岩储集层岩石力学特性及能量演化特征

甘仁忠^1a(), 熊健²(), 彭妙^1b, 刘向君², 梁利喜², 丁乙²

1.中国石油新疆油田分公司 a.勘探事业部,b.科技管理部，新疆克拉玛依 834000
2.西南石油大学油气藏地质及开发工程国家重点实验室，成都 610500

收稿日期:2022-05-21 修回日期:2022-06-30 出版日期:2023-08-01 发布日期:2023-08-01
通讯作者: 熊健（1986-），男，湖北荆州人，研究员，博士，岩石物理和岩石力学，（Tel）13880093092（E-mail）361184163@qq.com E-mail:ganrzh@petrochina.com.cn;361184163@qq.com
作者简介:甘仁忠(1981-)，男，青海互助人，高级工程师，油气勘探，(Tel)13519912281(E-mail)ganrzh@petrochina.com.cn
基金资助:
国家自然科学基金(42272190);四川省自然科学基金青年科学基金(2022NSFSC1065);中国石油科技创新基金(2023DQ02-0101)

Rock Mechanical Properties and Energy Evolution of Continental Shale Reservoirs

GAN Renzhong^1a(), XIONG Jian²(), PENG Miao^1b, LIU Xiangjun², LIANG Lixi², DING Yi²

1. PetroChina Xinjiang Oilfield Company, a. Exploration Department, b. Science and Technology Management Department, Karamay, Xinjiang 834000, China
2. State Key Laboratory of Reservoir Geology and Development Engineering, Southwest Petroleum University, Chengdu, Sichuan 610500, China

Received:2022-05-21 Revised:2022-06-30 Online:2023-08-01 Published:2023-08-01

摘要/Abstract

摘要：

以准噶尔盆地吉木萨尔凹陷芦草沟组陆相页岩储集层为研究对象，岩性分别为白云岩、泥质白云岩、白云质泥岩、白云质粉砂岩和粉砂岩，通过室内力学实验，研究了陆相页岩储集层岩石力学特性及能量演化规律。结果表明，陆相页岩储集层不同岩性岩石力学特性存在较明显差异，白云岩、白云质粉砂岩、粉砂岩、泥质白云岩和白云质泥岩的抗压强度分别为112.09 MPa、98.20 MPa、85.98 MPa、81.28 MPa和58.30 MPa;随着围压增大，陆相页岩储集层岩石脆性减弱，延性增强;陆相页岩储集层不同岩性岩样在峰值强度处的能量大小不同，反映不同岩性岩样间存在较强的非均质性，此外，三轴压缩条件下，相同岩性岩石弹性能、耗散能和总能量都大于单轴压缩条件。

关键词: 准噶尔盆地, 吉木萨尔凹陷, 芦草沟组, 陆相页岩, 储集层, 岩石力学特性, 能量演化, 破坏模式

Abstract:

The continental shale reservoirs in the Lucaogou formation of the Jimsar sag in the Junggar basin are lithologically composed of dolomite, argillaceous dolomite, dolomitic mudstone, dolomitic siltstone, and siltstone. The mechanical properties and energy evolution of the continental shale were investigated through laboratory mechanical experiments. The results show that there are significant differences in the rock mechanical properties of different lithologies within the shale reservoir. The compressive strengths of dolomite, dolomitic siltstone, siltstone, argillaceous dolomite and dolomitic mudstone are 112.09 MPa, 98.20 MPa, 85.98 MPa, 81.28 MPa and 58.30 MPa, respectively. With the increase of confining pressure, the brittleness of the rock samples of the continental shale reservoirs decreases and the ductility increases. The rock samples with different lithologies have different energy levels at the peak strength, indicating strong heterogeneity. Furthermore, the total energy, elastic energy and dissipated energy of the rocks with same lithologies under triaxial compression are higher than those under uniaxial compression.

Key words: Junggar basin, Jimsar sag, Lucaogou formation, continental shale, reservoir, rock mechanical property, energy evolution, failure mode

中图分类号:

TE21

甘仁忠, 熊健, 彭妙, 刘向君, 梁利喜, 丁乙. 陆相页岩储集层岩石力学特性及能量演化特征[J]. 新疆石油地质, 2023, 44(4): 472-478.

GAN Renzhong, XIONG Jian, PENG Miao, LIU Xiangjun, LIANG Lixi, DING Yi. Rock Mechanical Properties and Energy Evolution of Continental Shale Reservoirs[J]. Xinjiang Petroleum Geology, 2023, 44(4): 472-478.

图/表 5

参考文献 27

[1]	邹才能, 潘松圻, 赵群. 论中国“能源独立”战略的内涵、挑战及意义[J]. 石油勘探与开发, 2020, 47(2):416-426. doi: 10.11698/PED.2020.02.21
	ZOU Caineng, PAN Songqi, ZHAO Qun. On the connotation,challenge and significance of China’s “energy independence” strategy[J]. Petroleum Exploration and Development, 2020, 47(2):416-426.
[2]	薛庆, 刘明明, 程承, 等. 中国天然气进口规模与结构仿真研究[J]. 石油科学通报, 2021, 6(2):315-328.
	XUE Qing, LIU Mingming, CHENG Cheng, et al. Simulation study on the scale and structure of China’s natural gas import[J]. Petroleum Science Bulletin, 2021, 6(2):315-328.
[3]	焦方正, 邹才能, 杨智. 陆相源内石油聚集地质理论认识及勘探开发实践[J]. 石油勘探与开发, 2020, 47(6):1 067-1 078.
	JIAO Fangzheng, ZOU Caineng, YANG Zhi. Geological theory and exploration & development practice of hydrocarbon accumulation inside continental source kitchens[J]. Petroleum Exploration and Development, 2020, 47(6):1 067-1 078.
[4]	范谭广, 徐雄飞, 范亮, 等. 三塘湖盆地二叠系芦草沟组页岩油地质特征与勘探前景[J]. 中国石油勘探, 2021, 26(4):125-136.
	FAN Tanguang, XU Xiongfei, FAN Liang, et al. Geological characteristics and exploration prospect of shale oil in Permian Lucaogou formation,Santanghu basin[J]. China Petroleum Exploration, 2021, 26(4):125-136.
[5]	余佩蓉, 郑国庆, 孙福泰, 等. 玛湖凹陷风城组页岩油藏水平井压裂裂缝扩展模拟[J]. 新疆石油地质, 2022, 43(6):750-756.
	YU Peirong, ZHENG Guoqing, SUN Futai, et al. Simulation on fracture propagation during hydraulic fracturing in horizontal wells in shale reservoirs of Fengcheng formation,Mahu sag[J]. Xinjiang Petroleum Geology, 2022, 43(6):750-756.
[6]	李晶晶, 孙国翔, 刘琦, 等. 吉木萨尔凹陷芦一段页岩储集层孔隙结构及敏感性[J]. 新疆石油地质, 2021, 42(5):541-547.
	LI Jingjing, SUN Guoxiang, LIU Qi, et al. Pore structure and sensitivity of shale reservoir in Lu 1 member of Jimsar sag[J]. Xinjiang Petroleum Geology, 2021, 42(5):541-547.
[7]	张辉, 杨海军, 尹国庆, 等. 地质工程一体化关键技术在克拉苏构造带高效开发中的应用实践[J]. 中国石油勘探, 2020, 25(2):120-132. doi: 10.3969/j.issn.1672-7703.2020.02.012
	ZHANG Hui, YANG Haijun, YIN Guoqing, et al. Application practice of key technologies of geology-engineering integration in efficient development in Kelasu structural belt[J]. China Petroleum Exploration, 2020, 25(2):120-132.
[8]	石林, 史璨, 田中兰, 等. 中石油页岩气开发中的几个岩石力学问题[J]. 石油科学通报, 2019, 4(3):223-232.
	SHI Lin, SHI Can, TIAN Zhonglan, et al. Several rock mechanics problems in the development of shale gas in PetroChina[J]. Petroleum Science Bulletin, 2019, 4(3):223-232.
[9]	李逸凡, 李洪奎, 陈国栋, 等. 论山东胶东金矿形成的挤压-伸展构造环境[J]. 大地构造与成矿学, 2019, 43(6):1 117-1 132.
	LI Yifan, LI Hongkui, CHEN Guodong, et al. On the compression-extensional tectonic environment and gold mineralization in the Jiaodong area,Shandong province[J]. Geotectonica et Metallogenia, 2020, 43(6):1 117-1 132.
[10]	刘文博, 孙博一, 陈雷, 等. 一种基于弹性能释放率的岩石新型统计损伤本构模型[J]. 水文地质工程地质, 2021, 48(1):88-95.
	LIU Wenbo, SUN Boyi, CHEN Lei, et al. A statistical damage constitutive rock model based on elastic energy release rate[J]. Hydrogeology & Engineering Geology, 2021, 48(1):88-95.
[11]	翟明磊, 郭保华, 李冰洋, 等. 岩石节理分级剪切加载-蠕变-卸载的能量与变形特征[J]. 岩土力学, 2018, 39(8):2 865-2 872.
	ZHAI Minglei, GUO Baohua, LI Bingyang, et al. Energy and deformation characteristics of rock joints under multi-stage shear loading-creep-unloading conditions[J]. Rock and Soil Mechanics, 2018, 39(8):2 865-2 872.
[12]	袁余洋, 李虎, 王瑛, 等. 页岩岩相类型对裂缝形成及演化的影响研究:以黔西北地区龙马溪组为例[J]. 地质科学, 2021, 56(1):82-97.
	YUAN Yuyang, LI Hu, WANG Ying, et al. Study on the influence of lithofacies types on the formation and evolution of fracture:A case study of Longmaxi formation in northwest Guizhou[J]. Chinese Journal of Geology, 2021, 56(1):82-97.
[13]	熊健, 张茜, 梁利喜, 等. 四川盆地龙马溪组页岩断裂韧性特征与预测方法[J]. 地下空间与工程学报, 2019, 15(增刊2):541-547.
	XIONG Jian, ZHANG Qian, LIANG Lixi, et al. Prediction method and characteristics of the fracture toughness of Longmaxi formation shale in Sichuan basin[J]. Chinese Journal of Underground Space and Engineering, 2019, 15(Supp.2):541-547.
[14]	梁利喜, 庄大琳, 刘向君, 等. 龙马溪组页岩的力学特性及破坏模式研究[J]. 地下空间与工程学报, 2017, 13(1):108-116.
	LIANG Lixi, ZHUANG Dalin, LIU Xiangjun, et al. Study on mechanical properties and failure modes of Longmaxi shale[J]. Chinese Journal of Underground Space and Engineering, 2017, 13(1):108-116.
[15]	李泽华, 邓鹏, 杨春和, 等. 碳酸盐岩储层力学特性及可压性评价研究[J]. 广西大学学报(自然科学版), 2019, 44(5):1 450-1 460.
	LI Zehua, DENG Peng, YANG Chunhe, et al. Experimental study on mechanical properties and fracability evaluation of carbonate reservoirs[J]. Journal of Guangxi University(Natural Science Edition), 2019, 44(5):1 450-1 460.
[16]	高阳, 王英伟, 王玉多, 等. 吉木萨尔凹陷芦草沟组致密储集层岩石力学特征[J]. 新疆石油地质, 2016, 37(2):158-162.
	GAO Yang, WANG Yingwei, WANG Yuduo, et al. Rock mechanics characteristics of Lucaogou tight oil reservoir in Jimusaer sag,Junggar basin[J]. Xinjiang Petroleum Geology, 2016, 37(2):158-162.
[17]	李庆辉, 李少轩. 超深层砂岩储层岩石力学特性实验研究[J]. 岩石力学与工程学报, 2021, 40(5):948-957.
	LI Qinghui, LI Shaoxuan. Experimental study on mechanical properties of ultra-deep sandstone[J]. Chinese Journal of Rock Mechanics and Engineering, 2021, 40(5):948-957.
[18]	夏遵义, 马海洋, 房堃. 渤海湾盆地沾化凹陷陆相页岩储层岩石力学特征及可压裂性研究[J]. 石油实验地质, 2019, 41(1):134-141.
	XIA Zunyi, MA Haiyang, FANG Kun. Rock mechanical properties and fracability of continental shale in Zhanhua sag,Bohai Bay basin[J]. Petroleum Geology & Experiment, 2019, 41(1):134-141.
[19]	马德鹏, 周岩, 刘传孝, 等. 不同卸围压速率下煤样卸荷破坏能量演化特征[J]. 岩土力学, 2019, 40(7):2 645-2 652.
	MA Depeng, ZHOU Yan, LIU Chuanxiao, et al. Energy evolution characteristics of coal failure in triaxial tests under different unloading confining pressure rates[J]. Rock and Soil Mechanics, 2019, 40(7):2 645-2 652.
[20]	张志镇, 高峰. 3种岩石能量演化特征的试验研究[J]. 中国矿业大学学报, 2015, 44(3):416-422.
	ZHANG Zhizhen, GAO Feng. Experimental investigations on energy evolution characteristics of coal,sandstone and granite during loading process[J]. Journal of China University of Mining & Technology, 2015, 44(3):416-422.
[21]	王跃鹏, 刘向君, 梁利喜. 鄂尔多斯盆地延长组张家滩陆相页岩各向异性及能量演化特征[J]. 岩性油气藏, 2019, 31(5):149-160.
	WANG Yuepeng, LIU Xiangjun, LIANG Lixi. Anisotropy and energy evolution characteristics of Zhangjiatan continental shale of Yanchang formation in Ordos basin[J]. Lithologic Reservoirs, 2019, 31(5):149-160.
[22]	陈子全, 何川, 董唯杰, 等. 北疆侏罗系与白垩系泥质砂岩物理力学特性对比分析及其能量损伤演化机制研究[J]. 岩土力学, 2018, 39(8):2 873-2 885.
	CHEN Ziquan, HE Chuan, DONG Weijie, et al. Physico-mechanical properties and its energy damage evolution mechanism of the Jurassic and Cretaceous argillaceous sandstone in northern Xinjiang[J]. Rock and Soil Mechanics, 2018, 39(8):2 873-2 885.
[23]	蒋景东, 陈生水, 徐婕, 等. 不同含水状态下泥岩的力学性质及能量特征[J]. 煤炭学报, 2018, 43(8):2 217-2 224.
	JIANG Jingdong, CHEN Shengshui, XU Jie, et al. Mechanical properties and energy characteristics of mudstone under different containing moisture states[J]. Journal of China Coal Society, 2018, 43(8):2 217-2 224.
[24]	李天斌, 陈子全, 陈国庆, 等. 不同含水率作用下砂岩的能量机制研究[J]. 岩土力学, 2015, 36(增刊2):229-236.
	LI Tianbin, CHEN Ziquan, CHEN Guoqing, et al. An experimental study of energy mechanism of sandstone with different moisture contents[J]. Rock and Soil Mechanics, 2015,36(Supp. 2):229-236.
[25]	侯志强, 王宇, 刘冬桥, 等. 层状大理岩破裂过程力学特性与能量演化各向异性研究[J]. 采矿与安全工程学报, 2019, 36(4):794-804.
	HOU Zhiqiang, WANG Yu, LIU Dongqiao, et al. Investigation of the anisotropic mechanical behaviors and energy evolution during uniaxial deformation of interbedded marble[J]. Journal of Mining & Safety Engineering, 2019, 36(4):794-804.
[26]	蒋宜勤, 柳益群, 杨召, 等. 准噶尔盆地吉木萨尔凹陷凝灰岩型致密油特征与成因[J]. 石油勘探与开发, 2015, 42(6):741-749.
	JIANG Yiqin, LIU Yiqun, YANG Zhao, et al. Characteristics and origin of tuff-type tight oil in Jimusar depression,Junggar basin,NW China[J]. Petroleum Exploration and Development, 2015, 42(6):741-749.
[27]	温韬. 不同围压下龙马溪组页岩能量、损伤及脆性特征[J]. 工程地质学报, 2019, 27(5):973-979.
	WEN Tao. Energy evolution laws and brittle property of shale Longmaxi formation under different confining pressures[J]. Journal of Engineering Geology, 2019, 27(5):973-979.
