CO2溶解度实验及预测模型

doi:10.7657/XJPG20250313

摘要/Abstract

摘要：

CO₂溶解度是影响低渗、致密油藏注CO₂提高采收率和深盐水层CO₂埋存效果的重要参数。基于高温高压可视化相态反应釜的CO₂溶解实验明确了地层温度和压力、地层水矿化度和多相流体饱和度变化对原油-地层水体系中CO₂溶解度的影响，并通过拟合实验结果建立地层温度及压力下原油-地层水体系CO₂溶解度预测模型。结果表明：原油-地层水体系中，CO₂溶解度受压力和流体类型影响较大，压力和含油饱和度越高，越有利于CO₂溶解，地层水矿化度和温度均能小幅度影响CO₂在地层水中的溶解度；CO₂在原油中的溶解呈现出多阶段溶解特征，并随含油饱和度的增大大幅增加；随着油水两相体系中含水饱和度的增大，CO₂溶解度迅速降低，且伴随温度的升高，CO₂溶解度小幅降低。基于CO₂溶解度实验拟合得到CO₂溶解度预测模型，油水两相体系中的CO₂溶解度可分别采用CO₂在原油、地层水中的溶解度对油水两相饱和度加权得到，模型计算结果与实验结果一致性较高。

关键词: CO₂溶解度, 原油-地层水体系, 地层水矿化度, 含油饱和度, 预测模型

Abstract:

CO₂ solubility is a critical parameter impacting the effects of CO₂ injection for enhanced oil recovery (EOR) in low-permeability/tight reservoirs and CO₂ storage in deep saline aquifers. By using a high-temperature, high-pressure visualized phase reactor, CO₂ dissolution experiments were conducted to investigate the influences of formation temperature/pressure, formation water salinity, and multiphase fluid saturation on solubility of CO₂ in crude oil-formation water systems. A prediction model for CO₂ solubility in crude oil-formation water systems under formation temperature and formation pressure was developed by fitting experimental data. The results show that in crude oil-formation water systems, CO₂ solubility is strongly influenced by pressure and fluid type, and higher pressure and oil saturation can promote CO₂ dissolution. Both formation water salinity and temperature have minor impacts on solubility of CO₂ in formation water. CO₂ dissolution in crude oil exhibits multistage behaviors, and the CO₂ solubility increases significantly with the increase of oil saturation. Moreover, CO₂ solubility declines rapidly with increasing water saturation in oil-water systems and decreases slightly with increasing temperature. The solubility prediction model, derived from the fitting of experimental data, calculates CO₂ solubility in two-phase systems via saturation-weighted contributions of the solubility in oil and water phases and the results show high consistency with the experimental results.

Key words: CO₂ solubility, crude oil-formation water system, formation water salinity, oil saturation, prediction model

中图分类号:

TE341

杨宏楠, 乐平, 范伟, 张维, 汪周华, 李丹宸. CO₂溶解度实验及预测模型[J]. 新疆石油地质, 2025, 46(3): 360-366.

YANG Hongnan, YUE Ping, FAN Wei, ZHANG Wei, WANG Zhouhua, LI Danchen. CO₂ Solubility Experiments and Prediction Model[J]. Xinjiang Petroleum Geology, 2025, 46(3): 360-366.

图/表 11

图1

表1

表2

图2

图3

图4

图5

表3

CO2-地层水体系CO2溶解度预测模型参数取值"

i	$A i$	$B i$	$C i$
0	1.163 0	0.965 0	1.280 0
1	-16.630 0	-0.272 0	-10.757 0
2	111.073 0	0.092 3	52.696 0
3	-376.859 0	-0.100 8	-222.395 0
4	524.889 0	0.099 8	462.672 0

表3

图6

图7

图8

参考文献 31

[1]	周守为, 朱军龙. 助力“碳达峰、碳中和”战略的路径探索[J]. 天然气工业, 2021, 41(12):1-8.
	ZHOU Shouwei, ZHU Junlong. Exploration of ways to helping“carbon peak and neutrality”strategy[J]. Natural Gas Industry, 2021, 41(12):1-8.
[2]	邹才能, 薛华庆, 熊波, 等. “碳中和”的内涵、创新与愿景[J]. 天然气工业, 2021, 41(8):46-57.
	ZOU Caineng, XUE Huaqing, XIONG Bo, et al. Connotation,innovation and vision of“carbon neutral”[J]. Natural Gas Industry, 2021, 41(8):46-57.
[3]	袁士义, 马德胜, 李军诗, 等. 二氧化碳捕集、驱油与埋存产业化进展及前景展望[J]. 石油勘探与开发, 2022, 49(4):828-834. doi: 10.11698/PED.20220212
	YUAN Shiyi, MA Desheng, LI Junshi, et al. Progress and prospects of carbon dioxide capture,EOR-utilization and storage industrialization[J]. Petroleum Exploration and Development, 2022, 49(4):828-834.
[4]	YUE Ping, LIU Feng, YANG Kai, et al. Micro-displacement and storage mechanism of CO₂ in tight sandstone reservoirs based on CT scanning[J]. Energies, 2022, 15(17):1-16.
[5]	YUE Ping, ZHANG Rujie, SHENG J J, et al. Study on the influential factors of CO₂ storage in low permeability reservoir[J]. Energies, 2022, 15(1):1-10.
[6]	LIU Feng, SHEN Jiawei, YUE Ping, et al. Experimental and numerical simulation analysis of factors affecting CO₂ geological storage and enhanced oil recovery in extra-low permeability[J]. Energy & fuels, 2023, 20:15855-15866.
[7]	苏金长, 刘斌, 李儒广. CCUS-EOR过程中油气体系相间传质特征[J]. 新疆石油地质, 2024, 45(5):590-594.
	SU Jinchang, LIU Bin, LI Ruguang. Interphase mass transfer in the petroleum system during CCUS-EOR process[J]. Xinjiang Petroleum Geology, 2024, 45(5):590-594.
[8]	汤勇, 刘梦云, 秦佳正, 等. 基于物质的量平衡的气藏CO₂埋存潜力评估方法[J]. 石油钻采工艺, 2023, 45(2):197-202.
	TANG Yong, LIU Mengyun, QIN Jiazheng, et al. A evaluation method of CO₂ sequestration potential in gas reservoirs based on mole balance[J]. Oil Drilling & Production Technology, 2023, 45(2):197-202.
[9]	宋平, 崔晨光, 张记刚, 等. 玛湖凹陷上乌尔禾组强敏感油藏CO₂同步吞吐试验[J]. 新疆石油地质, 2024, 45(3):355-361.
	SONG Ping, CUI Chenguang, ZHANG Jigang, et al. Simultaneous CO₂ huff-n-puff test in highly sensitive reservoirs in upper Wuerhe formation,Mahu sag[J]. Xinjiang Petroleum Geology, 2024, 45(3):355-361.
[10]	王春兰, 王毅杰, 刘文臣, 等. 溶气原油CO₂溶解度预测模型[J]. 石油与天然气化工, 2024, 53(4):36-43.
	WANG Chunlan, WANG Yijie, LIU Wenchen, et al. Prediction model of carbon dioxide solubility in crude oil[J]. Chemical Engineering of Oil & Gas, 2024, 53(4):36-43.
[11]	侯大力, 罗平亚, 王长权, 等. 高温高压下CO₂在水中溶解度实验及理论模型[J]. 吉林大学学报(地球科学版), 2015, 45(2):564-572.
	HOU Dali, LUO Pingya, WANG Changquan, et al. Experimental research and theoretical model for CO₂ solubility in water under high temperature and high pressure[J]. Journal of Jilin University(Earth Science Edition), 2015, 45(2):564-572.
[12]	金旸钧, 陈乃安, 盛溢, 等. 地质封存条件下CO₂在模拟盐水层溶液中的溶解度研究[J]. 油气藏评价与开发, 2019, 9(3):77-81.
	JIN Yangjun, CHEN Nai’an, SHENG Yi, et al. Study on the solubility of CO₂ in simulated saline solution under geological storage condition[J]. Reservoir Evaluation and Development, 2019, 9(3):77-81.
[13]	KAVOUSI A, TORABI F, CHAN C W, et al. Experimental measurement and parametric study of CO₂ solubility and molecular diffusivity in heavy crude oil systems[J]. Fluid Phase Equilibria, 2014, 371:57-66.
[14]	DUAN Zhenhao, SUN Rui. An improved model calculating CO₂ solubility in pure water and aqueous NaCl solutions from 273 to 533 K and from 0 to 2000 bar[J]. Chemical Geology, 2003, 193:257-271.
[15]	AHMADI P, CHAPOY A. CO₂ solubility in formation water under sequestration conditions[J]. Fluid Phase Equilibria, 2018, 463:80-90.
[16]	薛海涛, 卢双舫, 付晓泰. 甲烷、二氧化碳和氮气在油相中溶解度的预测模型[J]. 石油与天然气地质, 2005, 26(4):444-449.
	XUE Haitao, LU Shuangfang, FU Xiaotai. Forecasting model of solubility of CH₄,CO₂ and N₂ in crude oil[J]. Oil & Gas Geology, 2005, 26(4):444-449.
[17]	李靖. 高温高压高含CO₂天然气在地层水中溶解度理论研究[D]. 成都: 西南石油大学, 2017.
	LI Jing. Theoretical study on solubility of high CO₂ content natural gas in formation water at high temperature and high pressure[D]. Chengdu: Southwest Petroleum University, 2017.
[18]	王一丁. 分子动力学模拟H₂、N₂和CO₂在水和苯中溶解度的对比研究[D]. 吉林: 吉林大学, 2024.
	WANG Yiding. Comparative study of the solubility of H₂,N₂ and CO₂ in water and benzene using molecular dynamics simulations[D]. Jilin: Jilin University, 2024.
[19]	ROSTAMI A, ARABLOO M, KAMARI A, et al. Modeling of CO₂ solubility in crude oil during carbon dioxide enhanced oil recovery using gene expression programming[J]. Fuel, 2017, 210:768-782.
[20]	龙震宇, 王长权, 石立红, 等. 基于KRR优化算法的油水系统中CO₂溶解度模型[J]. 吉林大学学报(地球科学版), 2022, 52(1):194-201.
	LONG Zhenyu, WANG Changquan, SHI Lihong, et al. CO₂ solubility model of oil-water system based on KRR optimization algorithm[J]. Journal of Jilin University(Earth Science Edition), 2022, 52(1):194-201.
[21]	龙震宇, 王长权, 石立红, 等. 基于核岭回归算法的地层水中CO₂溶解度模型研究[J]. 西安石油大学学报(自然科学版), 2023, 38(1):95-101.
	LONG Zhenyu, WANG Changquan, SHI Lihong, et al. Study on CO₂ solubility model in formation water based on kernel ridge regression algorithm[J]. Journal of Xi’an Shiyou University (Natural Science Edition), 2023, 38(1):95-101.
[22]	严巡, 王长权, 袁肖肖, 等. 利用BP人工神经网络预测盐水中CO₂的溶解度[J]. 中国科技论文, 2017, 12(24):2831-2834.
	YAN Xun, WANG Changquan, YUAN Xiaoxiao, et al. Prediction of solubility of CO₂ in brine water by BP artificial neural network[J]. China Sciencepaper, 2017, 12(24):2831-2834.
[23]	严巡, 孙敬, 刘德华, 等. 基于径向基神经网络的盐水中CO₂溶解度模型[J]. 数学的实践与认识, 2019, 49(18):147-152.
	YAN Xun, SUN Jing, LIU Dehua, et al. Prediction of dissolution of CO₂ in brine based on RBF neural network[J]. Mathematics in Practice and Theory, 2019, 49(18):147-152.
[24]	卞小强, 熊伟, 蔺嘉昊, 等. 基于G^E混合规则的统计缔合流体方程预测CO₂在水中的溶解度[J]. 石油化工, 2019, 48(10):1035-1039.
	BIAN Xiaoqiang, XIONG Wei, LIN Jiahao, et al. Prediction of the solubility of carbon dioxide in water using statistical associating fluid equation of state based on the G^E mixing rule[J]. Petrochemical Technology, 2019, 48(10):1035-1039.
[25]	周建堂, 康丽侠, 杨立国, 等. 基于G^E混合规则的SRK-CPA状态方程预测CO₂在地层水中的溶解度[J]. 石油化工, 2021, 50(12):1274-1279. doi: 10.3969/j.issn.1000-8144.2021.12.007
	ZHOU Jiantang, KANG Lixia, YANG Liguo, et al. Prediction of the solubility of CO₂ in formation water using SRK-CPA equation based on G^E mixing rule[J]. Petrochemical Technology, 2021, 50(12):1274-1279. doi: 10.3969/j.issn.1000-8144.2021.12.007
[26]	李曼平, 李玉杰, 杨金峰, 等. 黄3区CO₂驱技术研究与现场试验[J]. 石油化工应用, 2020, 39(5):71-75.
	LI Manping, LI Yujie, YANG Jinfeng, et al. Research and on-site testing of CO₂ flooding technology in Huang-3 area[J]. Petrochemical Industry Application, 2020, 39(5):71-75.
[27]	魏鸿坤, 王健, 王丹翎, 等. 高盐低渗透油藏CO₂泡沫微观尺度耐盐性及调驱效果[J]. 新疆石油地质, 2024, 45(6):703-710.
	WEI Hongkun, WANG Jian, WANG Danling, et al. Microscale salt tolerance and profile control of CO₂ foam in high-salinity,low-permeability reservoirs[J]. Xinjiang Petroleum Geology, 2024, 45(6):703-710.
[28]	CHANG Yih-bor, COATS BK, NOLEN JS. A compositional model for CO₂ floods including CO₂ solubility in water[C]. Texas:SPE Permian Basin Oil & Gas Recovery Conference, 1998.
[29]	宁华中. CO₂溶解度计算模型及测试方法研究[D]. 成都: 西南石油大学, 2016.
	NING Huazhong. Research on the calculation model and testing method of CO₂ solubility[D]. Chengdu: Southwest Petroleum University, 2016.
[30]	MEHROTRA A K, PATIENCE G S, SVRCEK W Y. Calculation of gas solubility in Wabasca bitumen[J]. Journal of Canadian Petroleum Technology, 1989, 28(3):81-83.
[31]	CHUNG F T H, JONES R A, BURCHFIELD T E. Recovery of viscous oil under high pressure by CO₂ displacement:A laboratory study[C]. Tianjin:SPE Society of Petroleum Engineers, 1988.

碳数	原油物质的量分数/%	碳数	原油物质的量分数/%	碳数	原油物质的量分数/%
C₁	0	C₁₃	3.49	C₂₅	0.71
C₂	0	C₁₄	3.64	C₂₆	0.67
C₃	0.33	C₁₅	3.26	C₂₇	0.63
C₄	3.82	C₁₆	2.60	C₂₈	0.63
C₅	6.46	C₁₇	2.33	C₂₉	0.51
C₆	7.05	C₁₈	2.17	C₃₀	0.54
C₇	10.62	C₁₉	1.90	C₃₁	0.58
C₈	9.90	C₂₀	1.22	C₃₂	0.49
C₉	8.49	C₂₁	1.13	C₃₃	0.36
C₁₀	6.82	C₂₂	0.99	C₃₄	0.28
C₁₁	5.73	C₂₃	0.94	C₃₅	0.44
C₁₂	4.34	C₂₄	0.78	C36⁺	6.04

流体体系	矿化度/ （g·L^-1）	温度/℃	压力/MPa	含水饱和度/%
CO₂- 地层水	0、40、80	70、84、100	5、10、15、20、25、30、35、40、45、50
CO₂-原油		55、70、84、100	10、13、15、20、25、30、35、40、45、50
CO₂-油水两相		70、84	10、13、15、20、25、30、35、40、45、50	30、50、70
